2011 HONDA ODYSSEY Owners Manual

Audio
Turn the interf ace dial to ‘‘Audio,’’
then press ENTER on the interf ace
selector. Turn the dial to select the
language you want f or DVD audio,
then press ENTER on the interf ace
selector. The languages that appear
on the screen are limited to the
language choicesavailable on Subtitle
Turn the interf ace dial to ‘‘Subtitle,’’
then press ENTER on the interf ace
selector. Turn the dial to select the
language you want f or subtitles, then
press ENTER on the interf ace
selector. The languages that appear
on the screen are limited to the
language choices
available on Turn the interf ace dial to ‘‘Repeat,’’
then press ENTER on the interf ace
selector. Select the icon in the center
( ) to repeat the current chapter,
theiconontheright( )to
repeat the current title, or select
OFF to turn of f repeat. If your DVD
does not support titles or chapters,
you cannot use this f eature. RepeatRear Entertainment System422
10/07/17 10:30:33 31TK8600_427
the DVD.
the DVD.
2011 Odyssey

Auto Play
Turn the interf ace dial to ‘‘Auto Play,’’
then press ENTER on the interf ace
selector. Select ON to play the DVD
automatically, or select OFF to play
the DVD manually.To return f ront panel control to the
f ront audio system, press the REAR
SOURCE button. You will hear a
beep and the indicator in the button
goes of f . The indicator also goes of f
automatically when you do not
operate the rear entertainment
system f or 20 seconds.
To turn on the rear entertainment
system f rom the rear control panel,
press the (power) button. Use
the FM/AM button, XM button,
CD/CDL or CD/HDD button, or
DVD/AUX button to select the
entertainment source. The selected
source will be shown in the display.
Make sure the rear control operation
has not been disabled. When the
f ront audio system is of f or the f ront
panel’s Rear Power is of f , the rear
control panel cannot be turned on.
Rear Entertainment System
To Return to Front Audio
Controls
Using the Rear Control Panel
Features
423
10/07/17 10:30:40 31TK8600_428
2011 Odyssey

424
10/07/17 10:30:33 31TK8600_427
Rear Entertainment SystemPress the FM/AM button to listen to
the radio.
Press the MENU button to display
theAudioMenuontheoverhead
screen. You can enter the
highlighted f unction by pressing the
ENTER button. These f unctions
have the same features as those of
the f ront audio system. You can
press and hold either side ( or)of theTUNE/SKIPbarto
skip (seek) up/down, and press
either side ( or ) of the
TUNE/SKIP bar to tune up/down.
To Play the Radio f rom the Rear
Control Panel
Press the XM button to listen to the
XM Radio. You can press either side
(or)oftheTUNE/SKIP
bar to scroll up/down and select
channels within a category (in
CATEGORY mode), or to scroll up/
down and select f rom among all
available channels (in CH mode).
Press the MENU button to display
theaudiomenuontheoverhead
screen. You can enter the
highlighted f unction by pressing the
ENTER button. These f unctions
have the same features as those of
the f ront audio system.
Pressing and holding the TITLE/
SCROLL button f or 5 seconds
enables you to switch between
search modes.
To Play the XM Radio f rom the
Rear Control Panel
OVERHEAD SCREEN REAR CONTROL PANEL
On vehicles with navigation system On vehicles without navigation system
2011 Odyssey

Usethe,,,orbutton to highlight Repeat,
Random, or Scan on the screen. You
can enter the highlighted f unction by
pressing the ENTER button. These
functions have the same features as
those of the f ront audio system.
When the TITLE/SCROLL button is
pressed, the title scrolls. When it is
pushed again, scrolling stops. Pressthe buttontoskiptothe
beginning of the next chapter. Press
the button to return to the
beginning of the current chapter.
Press the button again quickly
to go to the previous chapter.
To move rapidly within a chapter,
press and hold the or
button. The system will
continue to move through the
chapter. Press the button to
move forward, or the button to
move backward. Release the button
when the system reaches the point
you want.
ToselectthemenuontheDVD,
press the MENU button. Use the , , , and button
to move to the desired menu
selection, then press the ENTER
button to enter your selection.
The video screen is f or use by rear
seat passengers only. The driver and
f ront seat passenger should not try
to view the screen while driving.
Open the overhead screen by pulling
down the bottom edge of the screen
until it locks into place when f ully
extended. If you pull down the
screen too far forward, past the
second detent, the display will turn
off. Push the screen up to the second
or first detent to turn the display
back on. To close the screen, push it
up until it locks into place when f ully
closed.
Press the button when you
want to pause the DVD. Press this
button again to go back to PLAY.
To Play a Disc, CD L ibrary, HDD,
USB, or iPod
from the Rear
Control Panel To Play a DVD from the Rear
Control Panel
Rear Entertainment System
Features
425
10/07/17 10:30:58 31TK8600_430
2011 Odyssey

Top Menu
When you press the TITLE/
SCROLL button while a DVD is
playing, the current status of title,
chapter, elapsed time, angle, subtitle,
audio, and sound characteristics are
displayed. To return to the DVD
video screen, press the TITLE/
SCROLL button again. When you press the MENU button
while a DVD is playing, the DVD
Menu appears. The menu options
are TOP MENU, MENU, PLAY
MODE, SEARCH/NUMINPUT,
REPEAT, PAUSE/PLAY, and STOP.
When you select ‘‘TOP MENU,’’ the
screen changes to the DVD’s title
menu. This menu also appears when
you press the MENU button while a
DVD is not playing. To go back to
play, press the MENU or CANCEL
button.
To go to your selected menu, use the ,,,orbuttonto
highlight the icon and press the
ENTER button. To return to the
DVD video screen, select RETURN.
TITLE/SCROLL Button
MENU Button
Rear Entertainment System426
10/07/17 10:31:08 31TK8600_431
2011 Odyssey

ÛÝ
Menu
Play Mode
To change the Audio setting,
highlight ‘‘Audio’’ f rom the play
mode menu with the orbutton. A submenu of dubbed
languages appears. You can select
another language by pressing the or button. The sound
characteristics (Dolby Digital,
LPCM, MPEG Audio, dts) recorded
with the selected language is also
displayed next to the language.
When you select ‘‘MENU’’ with the
, , , or button,
the screen changes to the DVD’s
title menu. When you select ‘‘PLAY MODE’’
with the , , , or
button, you can change the
DVD’s Audio, Subtitle or Angle
setting.‘‘Audio’’
CONT INUED
Rear Entertainment System
Features
427
10/07/17 10:31:19 31TK8600_432
2011 Odyssey

Ý
Û ÛÝ
‘‘Subtitle’’
‘‘Angle’’
The selectable languages vary f rom
DVD to DVD, and this f eature may
notbeavailableonsomeDVDs.
To change the DVD’s subtitle,
highlight ‘‘Subtitle’’ f rom the play
mode menu with the orbutton. You can see the
available subtitles with the or button.
To go back to play, press the MENU
or CANCEL button.
To change the view angle, highlight
‘‘Angle’’ f rom the play mode menu
with the or button. You
can see the available angle options
with the or button.
To go back to play, press the MENU
or CANCEL button. To go back to play, press the MENU
or CANCEL button. If there are no multiple angles
available on the DVD, you cannot
change f rom ‘‘Angle 1.’’Rear Entertainment System428
10/07/17 10:31:27 31TK8600_433
2011 Odyssey

Search
Highlight ‘‘SEARCH’’ with theor button to select ‘‘Title,’’
‘‘Chapter,’’ or ‘‘NumInput’’ and press
ENTER. With ‘‘Title’’ highlighted, use the
or buttontojumptoyour
desired title and press the ENTER
button. When ‘‘Chapter’’ is
highlighted, f ollow the same
procedure f or the chapter search. A numerical command can be issued
to a DVD by inputting a three digit
number, and a button number can be
selected on the screen.
Highlight ‘‘NumInput’’ with the
or button. Press the
ENTERbuttontogotothe
NumInput selection screen. NumInput
‘‘Title/Chapter Search’’
CONT INUED
Rear Entertainment System
Features
429
10/07/17 10:31:38 31TK8600_434
2011 Odyssey
