If you have a f lat tire, the low tire
pressure indicator will come on.
Replace the flat tire with the
compact spare tire (see page ).
Each wheel (except the compact
sparetirewheel)isequippedwitha
tire pressure sensor. You must use
TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.The low tire pressure indicator or
the TPMS indicator will go off, after
several miles (kilometers) driving,
when you replace the spare tire with
the specif ied regular tire equipped
with the tire pressure monitor sensor.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
After you replace the flat tire with
thecompactsparetire,thelowtire
pressure indicator stays on. This is
normal; the system is not monitoring
the spare tire pressure. Manually
check the spare tire pressure to be
sure it is correct. Af ter several miles
(kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low tire
pressure indicator goes of f . Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low while driving, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator to come
on.
655
On Touring models
Changing a T ire with T PMSTire Pressure Monitoring System (TPMS)574
10/07/17 10:51:38 31TK8600_579
2011 Odyssey

Driving on a signif icantly under
inf lated tire causes the tire to
overheat and can lead to tire failure.
Underinf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
CONT INUED
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure/
TPMS Indicator
Driving
575
10/07/17 10:51:45 31TK8600_580
2011 Odyssey

Refer to page for tire inflation
guidelines.
If there is a problem with the TPMS,
this indicator begins to f lash. It stops
flashing after approximately 1
minute, then stays on. You will also
see a ‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ).Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when cold, and
set to the recommended inf lation
pressure as specif ied on the tire
information label and in the owner’s
manual (see page ).
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
The TPMS can misinterpret the tire
pressure because of dif f erences in
air temperature. For example, if you
check and f ill your tires in a warm
area, then drive in extremely cold
weather, the tire pressure will be
lowerthanmeasuredandcouldbe
underinf lated and cause the low tire
pressure/TPMS indicator to come
on.Or,if youcheckandadjustyour
tire pressure in cooler conditions,
and drive into extremely hot
conditions, the tires may become
overinf lated. However, the low tire
pressure/TPMS indicator will not
come on if the tires are overinf lated.
91
642
643
655
Tire Pressure Monitoring System (TPMS)576
10/07/17 10:51:51 31TK8600_581
2011 Odyssey

CONT INUED
If there is a problem with the TPMS,
you will see the above message on
the multi-information display.
Also, the low tire pressure/TPMS
indicator begins to f lash, then stays
on (see page ).If you see this message, the system
is of f and is not monitoring the tire
pressures. Have the system checked
by your dealer as soon as possible.
If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page ). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
When you restart the vehicle with
thecompactsparetire,theTPMS
system message will also be
displayed on the multi-inf ormation
display after several miles
(kilometers) driving. If you have a f lat tire, the low tire
pressure/TPMS indicator will come
on. Replace the flat tire with the
compact spare tire (see page ).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct.
573 571 655
Tire Pressure Monitoring System (TPMS)
TPMS System Failure
Changing a Tire with TPMS
Driving
577
10/07/17 10:52:00 31TK8600_582
2011 Odyssey

This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare
tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
a qualif ied technician.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.If the low tire pressure/TPMS
indicator and the low tire position on
the low tire pressure monitor do not
go out af ter inf lating the tires to the
specified values, have your dealer
check the system as soon as possible.
As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Tire Pressure Monitoring System (TPMS)578
10/07/17 10:52:06 31TK8600_583
2011 Odyssey

If the system detects vehicles in
adjacent lanes, it automatically
illuminates the appropriate indicator
to provide assistance when you
change lanes. It is not a substitute
for visual confirmation that it is safe
to change lanes.
The blind spot inf ormation system
(BSI) is designed to assist you when
you are changing lanes.
On Touring Elite and Canadian Touring
models
Blind Spot Inf ormation System (BSI)
Driving
579
Failure to visually confirm that it
is safe to change lanes before
doing so may result in a crash
and serious injury or death.
Do not rely only on the blind
spot information system when
changing lanes.
Always look in your mirrors, to
either side of your vehicle, and
behind you for other vehicles
before changing lanes.
10/07/17 10:52:11 31TK8600_584
2011 Odyssey

A: Approximately 1.6 f t. (0.5 m)
B: Approximately 10 f t. (3 m)
C: Approximately 10 f t. (3 m)
BSI system is designed to detect
vehicles in specif ied alert zones
adjacent to your vehicle, particularly
in harder to see areas commonly
known as ‘‘blind spots.’’When BSI detects a vehicle in an
alert zone, a BSI alert indicator
comes on near the corresponding
outside rearview mirror.
While your vehicle is moving
f orward at a speed between 6 mph
(10 km/h) and 100 mph (160 km/h),
the BSI alert indicator comes on
under either of the f ollowing
conditions:
The system will not alert you to all
vehicles in blind spot zones (such as
vehicles you have just passed which
youshouldalreadybeawareof)
unless it remains in the alert zone f or
approximately 2 or more seconds.
While the system is on, BSI is active
whenever the shif t lever is in the D
or D4 position.
Another vehicle overtakes you,
entering the alert zone from
behind, at a speed that dif f ers
f rom your vehicle’s speed by no
more than 31 mph (50 km/h).
You pass a vehicle at a speed that
differs from that vehicle’s speed
by no more than 12 mph (20
km/h). The indicator comes on
approximately 2 seconds af ter the
vehicle enters the alert zone.Blind Spot Inf ormation System (BSI)BSI System Operation580A B
CALERT
ZONE
10/07/17 10:52:19 31TK8600_585
2011 Odyssey

CONT INUED
Blind Spot Inf ormation System (BSI)
Driving
581
MULTI-INFORMATION DISPLAYBSI ALERT INDICATOR RIGHT SIDE
LEFT SIDE
BSI INDICATOR
BSI OFF BUTTON
