The selected setting will be
highlighted in blue f or 1 second, and
the screen returns to the play mode
in the selected setting.Appearance
You can change the color of the
menu screen to white, black, blue,
brown, or red. It can be also
synchronized with the front
navigation system. Rotate the
interface dial to the setting you want,
then press the ENTER button. To change the personal surround
setting, highlight ‘‘Personal
Surround’’ f rom the setup menu with
the interf ace dial and press the
ENTER button. The ef f ect selection
appears. Personal SurroundUltrawide Rear Entertainment System462
10/07/17 10:36:13 31TK8600_467
2011 Odyssey

CONT INUED
Select ‘‘Music,’’ ‘‘Cinema,’’ or ‘‘Voice’’
by turning the interf ace dial, and
enter your selection by pressing the
ENTER button.
If you select ‘‘Of f ,’’ there will be no
special sound ef f ect.Language
You can change the display language
to English, French, or Spanish.
Rotate the interface dial to the
setting you want, then press the
ENTER button.
There are three selectable menus:
‘‘Language Settings,’’ ‘‘Dynamic
Range,’’ and ‘‘Angle Mark.’’ When you press the MENU button
on the rear control panel when a
DVD is not playing, the ‘‘INITIAL
SETTINGS’’ menu is displayed. INIT IA L SET T INGS Menu
Ultrawide Rear Entertainment System
Features
463
10/07/17 10:36:22 31TK8600_468
2011 Odyssey

ÝÛ
To select the language used in the
DISC menus, select ‘‘Menu
Language’’ by pressing the or
button.
Select the desired language by
turning the interf ace dial, and then
pressing the ENTER button.
Because the priority language is
determined by each disc you insert,
you might not be able to set a
selected item. To return to the stop or previous
screen, press the CANCEL button. When you select ‘‘Language
Settings’’ with the interf ace dial, the
menu shown above appears. Menu Language
The selectable languages are,
English, French, Spanish, Arabic,
German, Italian, Dutch, Chinese,
Korean, Thai, Japanese or others.
If you want another language than
those listed, you need to enter the
code number of the desired language.
Select ‘‘other,’’ and press the ENTER
button. The display changes as
showninthenextcolumn.
INIT IA L SET T INGS (L anguage)Ultrawide Rear Entertainment System464
10/07/17 10:36:32 31TK8600_469
2011 Odyssey

If you select ‘‘No,’’ and press the
ENTER button, the display returns
to the initial screen of the ‘‘Language
Settings’’ menu.If you select ‘‘Yes,’’ the display
changes to the language code input
mode. Select the f irst digit using the
interf ace dial, and press the ENTER
button to enter it. Repeat this until all
f our digits are f illed. Press the
button on the control panel to
enter the new language code. If you made a mistake entering a
number digit, press the button
on the control panel. Then select and
enter the correct digit as described.
The display returns to the initial
‘‘Language Settings’’ menu screen.
CONT INUED
Ultrawide Rear Entertainment System
Features
465
10/07/17 10:36:40 31TK8600_470
2011 Odyssey

ÝÛÝÛ
Audio Language
You can select the dubbed language
bef ore playing DVDs.
Select ‘‘Audio Language’’ by pressing
the or button.
Follow the same instructions you
used to set the menu language.
You can select the subtitle language
bef ore playing DVDs.
Select ‘‘Subtitle Language’’ by
pressing the or button. Subtitle Language
Follow the same instructions you
used to set the menu language.Dynamic Range
‘‘Dynamic Range’’ reduces the
dif f erences between the loud and
quiet sound levels throughout the
disc. When this is on, the louder
sounds are lowered, and quieter
sounds are increased.
Ultrawide Rear Entertainment System466
10/07/17 10:36:48 31TK8600_471
2011 Odyssey

Select the ‘‘Dynamic Range’’ by
turning the interf ace dial.
To turn ‘‘Dynamic Range’’ on or of f ,
select ‘‘ON’’ or ‘‘OFF’’ by turning the
interf ace dial, and then press the
ENTER button.You can set the system to display or
not display this angle mark. Select the ‘‘Angle Mark’’ by turning
the interf ace dial. If you want the
angle mark to be displayed, select
‘‘ON’’ by turning the interf ace dial,
and then press the ENTER button.
Angle Mark
When you switch to another angle
while playing a DVD, the angle mark
is displayed in the lower right corner
of the screen.
Ultrawide Rear Entertainment System
Features
467
ANGLE MARK
10/07/17 10:36:56 31TK8600_472
2011 Odyssey

468
10/07/17 10:30:33 31TK8600_427
Ultrawide Rear Entertainment SystemThere are various types of DVDs
available. Some of them are not
compatible with your system.
The DVD player in your rear
entertainment system can play
DVDs and CDs bearing the above
marks on their packages or jackets.Those packages or jackets should
also bear the designation of ‘‘1’’ or
‘‘ALL’’ region. DVD-ROMs cannot be
played in this system.
This product incorporates copyright
protection technology that is
protected by U.S. patents and other
intellectual property rights.
Use of this copyright protection
technology must be authorized by
Macrovision, and is intended f or
home and other limited viewing uses
only unless otherwise authorized by
Macrovision. The DVD player can also play discs
recorded in MP3/WMA/AAC
f ormats and DTS CDs.
The tips on how to handle and
protect DVDs are basically the same
as those f or compact discs. Ref er to
‘‘Protecting Your CDs’’ on page .352
Playable DVDs
Protecting DVDsÌ
Manuf actured under license under
U.S. Patent ’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents
issued & pending. DTS and t h e
trademarks and DTS Digital
All Rights Reserved. Reverse engineering or disassembly
is prohibited. the Symbol are registered
S u r r o u n d a n d t h e D T S l o g o s a r e
trademarks of DTS, Inc. Product
includes software.
DTS, Inc.
Manuf actured under license f rom
Dolby Laboratories. Dolby, Pro
Logic, and the double- D symbol are
trademarks of Dolby Laboratories.
2011 Odyssey

Error Message Cause
Insert a dif f erent disc. If the new
disc plays, there is a problem with
the f irst disc. If the error message
cycle repeats and you cannot clear it,
take your vehicle to a dealer. Theaudiosystemwilltrytoplaythe
disc. If there is still a problem, the
error message will reappear. Press
the eject button, and pull out the disc. If you see an error message in the
display while playing a disc, press
the eject button. After ejecting the
disc, check it for damage or
deformation. If there is no damage,
insert the disc again. Thechartontherightexplainsthe
error messages you may see in the
display while playing a disc. Solution
FOCUS Error
Mechanical Error
High Temperature
Invalid region code
DVD format not
supported
Mechanical ErrorPress the disc eject button, and remove the disc.
Check for an error indication. Insert the disc
again. If the code does not disappear, consult
your dealer.
Will disappear when the temperature returns to
normal.
The disc is not playable in this unit. Eject the
disc, and insert a disc compatible with this
system.
Press the EJECT button and pull out the disc.
Check the disc for serious damage, signs of
deformation, excessive scratches, and/or dirt
(see page
353). Insert the disc again. If the code
does not disappear, or the disc cannot be
removed, consult your dealer. Do not try to
force the disc out of the player.
On vehicles with navigation systemDVD Player Error Messages
Ultrawide Rear Entertainment System
Features
469
DISC ERROR
MECH ERROR HEAT ERRORREGION ERR
UNSUPPORTED
PUSH EJECTBAD DISC
PLEASE CHECK
OWNERS MANUAL
