2011 HONDA ODYSSEY Owners Manual

Check the condition of the wiper
blades at least every 6 months.
Replace them if you f ind signs of
cracking in the rubber, and areas
that are getting hard or if they leave
streaks and unwiped areas when
used.Raise the wiper arm of f the
windshield. Raise the driver’s side
first, then the passenger’s side.Disconnect the blade assembly
from the wiper arm:
To replace a f ront wiper blade:
Press and hold the lock tab.
Slide the blade assembly toward
the lock tab until it releases f rom
the wiper arm.
When replacing a wiper blade,
make sure not to drop the wiper
blade or wiper arm down on the
windshield.
2.
1.Wiper Blades638
WIPER ARMS LOCK TAB
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and the arms.
10/07/17 10:59:44 31TK8600_643
2011 Odyssey

Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.Slide the new wiper blade into the
holder until the tabs lock.
Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Lower the wiper arm down against
the windshield, the passenger’s
side first, then the driver’s side.
3. 4. 5.
6.
7.
CONT INUED
Wiper Blades
Maint enance
639
BLADE
BLADE
REINFORCEMENT
10/07/17 10:59:51 31TK8600_644
2011 Odyssey

Pull one end of the blade out f rom
the holder.
Slide the blade out of the holder.
To replace a rear wiper blade:
Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.
Raise the wiper arm of f the rear
window.
Disconnect the blade assembly
f rom the wiper arm by pivoting the
blade assembly upward.
1.
2.
3.
4.
Wiper Blades640
BLADE
REINFORCEMENT
WIPER ARM
10/07/17 10:59:59 31TK8600_645
2011 Odyssey

Slide the new blade into the wiper
arm. Make sure it is engaged in
the slot along its f ull length.
Insert both ends of the blade into
theholder.Makesuretheyare
secure.Install the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Lower the wiper arm against the
windshield.
5.
6.
7.
Wiper Blades
Maint enance
641
10/07/17 11:00:06 31TK8600_646
2011 Odyssey

Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort.Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.
Clean the wheels as you would the
rest of the exterior. Wash them with
thesamesolution,andrinsethem
thoroughly.
Aluminum alloy wheels have a
protective clear-coat that keeps the
aluminum f rom corroding and
tarnishing. Cleaning the wheels with
harsh chemicals (including some
commercial wheel cleaners) or a stif f
brush can damage the clear-coat. To
clean the wheels, use a mild
detergent and a sof t brush or sponge.
The tire pressure monitoring system
(TPMS) warns you when a tire
pressure is low. See page or
f or more inf ormation. 572
574
If equipped
Inf lation Guidelines
Tires
Wheels
Wheels, Tires642
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
10/07/17 11:00:15 31TK8600_647
2011 Odyssey

CONT INUED
Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
Use a gauge to measure the air
pressure in each tire at least once a
month. Even tires that are in good
condition may lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf /cm ) per
month. Remember to check the
sparetireatthesametime.
Check the air pressures when the
tires are cold. This means the
vehicle has been parked f or at least 3
hours, or driven less than 1 mile (1.6
km). Add or release air, if needed, to
match the recommended cold tire
pressures.If you check air pressures when the
tires are hot (driven f or several
miles/kilometers), you will see
readings 4 to 6 psi (30 to 40 kPa, 0.3
to 0.4 kgf/cm ) higher than the cold
readings. This is normal. Do not let
air out to match the recommended
cold air pressure. The tire will be
underinf lated.
The following chart shows the
recommended cold tire pressures f or
most normal and high-speed driving
conditions.
Youshouldgetyourowntire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier f or you to tell if a
pressure loss is due to a tire problem
and not due to a variation between
gauges.
While tubeless tires have some
ability to self -seal if they are
punctured, you should look closely
for punctures if a tire starts losing
pressure. The compact spare tire pressure is:
Tire Size Cold Tire Pressure for
Normal Driving
Tire Size Cold Tire Pressure for Normal Driving
Front:
Rear: Front:
Rear:
Touring models
LX, EX, EX-L models
Tires
Recommended T ire Pressures
Maint enance
643
60 psi (420 kPa , 4.2 kgf/cm
)
33 psi (230 kPa ,
2.3 kgf/cm
)
33 psi (230 kPa ,
2.3 kgf/cm)
P235/60R18 102T 35 psi (240 kPa ,
2.4 kgf/cm)
35 psi (240 kPa ,
2.4 kgf/cm)
P235/65R17 103T
10/07/17 11:00:28 31TK8600_648
2011 Odyssey

A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators. Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire.
For convenience, the recommended
tire sizes and cold tire pressures are
on a label on the driver’s doorjamb.
For additional inf ormation about
your tires, see page .
We strongly recommend that you do
not drive faster than the posted
speed limits and conditions allow. If
you ever drive in a sanctioned
competitive event at sustained high
speeds (over 99 mph or 160 km/h),
be sure to adjust the cold tire
pressuresasshownbelow.If youdo
not, excessive heat can build up and
cause sudden tire f ailure.
Excessive tread wear. Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord. Bumps or bulges in the tread or
side of the tire. Replace the tire if
youfindeitherof theseconditions.
Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:
690
Cold Tire Pressure
Tire Size Tire Size Cold Tire Pressure
Front:
Rear: Front:
Rear:
LX, EX, EX-L models
Touring modelsTiresHigh Speed Driving
T ire Inspection644
INDICATOR LOCATION MARKS
TREAD WEAR INDICATOR
P235/65R17 103T 33 psi (230 kPa ,
2.3 kgf/cm
)
35 psi (240 kPa , 2.4 kgf/cm) P235/60R18 102T
36 psi (250 kPa ,
2.5 kgf/cm
)
35 psi (240 kPa ,
2.4 kgf/cm)
10/07/17 11:00:41 31TK8600_649
2011 Odyssey

To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the inf ormation display or multi-
inf ormation display (depending on
models). Move the tires to the
positions shown in the diagram each
time they are rotated. If you
purchase directional tires, rotate
only f ront-to-back.
In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
The service lif e of your tires is
dependent on many f actors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inf lation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).
The last f our digits of the TIN (tire
identif ication number) are f ound on
the sidewall of the tire and indicate
the date of manufacture (See
on page ).
In addition to your regular
inspections and inf lation pressure
maintenance, it is recommended that
you have annual inspections
perf ormed once the tires reach f ive
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.
692
On all models except LX
Tires
Tire Rotation
T ire Maintenance
Tire Service Lif e
Tire
Labeling
Maint enance
645
Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)Front
Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only genuine Honda wheel weights f or
balancing.
10/07/17 11:00:50 31TK8600_650
