2010.5 PEUGEOT 5008 Owners Manual

57
2. Air fl ow adjustment
 Turn the dial from position 1
to position 5 to obtain a com-
fortable air fl ow.
Windscreen, side windows
and front-rear footwells. Footwells, front-rear
(closing the vents increases
the fl ow to the footwells).
Central, side and rear vents.

 Turn the dial from blue
(cold) to red (hot) to adjust
the temperature to your re-
quirements.
Windscreen and side windows.
1. Temperature adjustment
The air distribution can be
adapted by placing the dial in
an intermediate position.
The air conditioning can only operate
with the engine running. 4. Air intake/Air recirculation
The intake of exterior air limits misting
of the windscreen and side windows.
The recirculation of interior air insulates
the passenger compartment from exte-
rior odours and smoke.
Return to exterior air intake as soon as
possible to prevent deterioration of the
air quality and demisting performance.

 If you place the air fl ow
control in position 0 (de-
activation of the system),
the temperature is no
3. Air distribution adjustment
 Press the button to recir-
culate the interior air. The
indicator lamp comes on to
confi rm this.

 Press the button again to permit the
intake of exterior air. The indicator
lamp goes off to confi rm this.
longer maintained at a comfortable
level. However, a slight fl ow of air,
due to the movement of the vehicle,
can still be felt.

58
Demisting/defrosting
The control button is located
on the air conditioning system
control panel.
REAR SCREEN DEMIST/DEFROST

 Switch off the demist/de-
frost of the rear screen and
door mirrors as soon as it
is no longer necessary as
lower current consumption
results in reduced fuel con-
sumption.
Switching on
The rear screen demist/defrost can only
operate when the engine is running.

 Press this button to demist/defrost
the rear screen and the door mirrors.
The indicator lamp associated with
the button comes on.
Switching off
The demist/defrost switches off auto-
matically to prevent an excessive con-
sumption of current.

 It is possible to stop the demist/de-
frost operation before it is switched off
automatically by pressing the button
again. The indicator lamp associated
with the button switches off.
5. Air conditioning On/Off
The air conditioning is de-
signed to operate effectively in
all seasons, with the windows
closed.
It enables you to:
- lower the temperature, in summer,
- increase the effectiveness of the demisting in winter, above 3 °C.
Switching on

 Press the "A/C" button, the button's
indicator lamp comes on.
The air conditioning does not operate
when the air fl ow adjustment control 2
is in position " 0 ".
The marking on the control
panel indicates the position of
the controls to quickly demist
or defrost the windscreen and
side windows:

 place the air intake control 4 in the
"Exterior air intake" position (indica-
tor lamp off),

 place the air distribution dial 3 in the
"Windscreen position",

 place the air fl ow dial 2 in position 5
(maximum),

 place the temperature dial 1 in the
red position (hot). Switching off

 Press the "A/C" button again, the
button's indicator lamp goes off.
Switching off may affect comfort levels
(humidity, condensation).

58
Demisting/defrosting
The control button is located
on the air conditioning system
control panel.
REAR SCREEN DEMIST/DEFROST

 Switch off the demist/de-
frost of the rear screen and
door mirrors as soon as it
is no longer necessary as
lower current consumption
results in reduced fuel con-
sumption.
Switching on
The rear screen demist/defrost can only
operate when the engine is running.

 Press this button to demist/defrost
the rear screen and the door mirrors.
The indicator lamp associated with
the button comes on.
Switching off
The demist/defrost switches off auto-
matically to prevent an excessive con-
sumption of current.

 It is possible to stop the demist/de-
frost operation before it is switched off
automatically by pressing the button
again. The indicator lamp associated
with the button switches off.
5. Air conditioning On/Off
The air conditioning is de-
signed to operate effectively in
all seasons, with the windows
closed.
It enables you to:
- lower the temperature, in summer,
- increase the effectiveness of the demisting in winter, above 3 °C.
Switching on

 Press the "A/C" button, the button's
indicator lamp comes on.
The air conditioning does not operate
when the air fl ow adjustment control 2
is in position " 0 ".
The marking on the control
panel indicates the position of
the controls to quickly demist
or defrost the windscreen and
side windows:

 place the air intake control 4 in the
"Exterior air intake" position (indica-
tor lamp off),

 place the air distribution dial 3 in the
"Windscreen position",

 place the air fl ow dial 2 in position 5
(maximum),

 place the temperature dial 1 in the
red position (hot). Switching off

 Press the "A/C" button again, the
button's indicator lamp goes off.
Switching off may affect comfort levels
(humidity, condensation).

59
On entering the vehicle, if the
interior temperature is much
colder or warmer than the
comfort value, there is no need to
change the value displayed in order
to obtain the comfort required more
quickly. The system corrects the dif-
ference in temperature automatically
and as quickly as possible.
The air conditioning only operates when
the engine is running. The driver and front passenger
can each adjust the tempera-
ture to their requirements.

 Turn control 2 or 3 to the left or to
the right respectively to decrease or
increase this value.
A setting around the value 21 provides
optimum comfort. However, depend-
ing on your requirements, a setting
between 18 and 24 is normal.
You are advised to avoid a left/right set-
ting difference of more than 3. 4. Automatic visibility programme
The automatic comfort pro-
gramme may not be suffi cient
to quickly demist or defrost
the windscreen and side win-
dows (humidity, several pas-
sengers, ice, etc.).

 In this case, select the automatic
visibility programme.
The system automatically controls the
air conditioning, the air fl ow and the air
intake and provides optimum distribu-
tion of the ventilation to the windscreen
and side windows.
Automatic operation

 Press the "AUTO" button.
The indicator lamp on the
button comes on.
DUAL-ZONE DIGITAL AIR CONDITIONING
We recommend the use of this mode:
it permits automatic and optimised ad-
justment of all of the functions, passen-
ger compartment temperature, air fl ow,
air distribution and air recirculation, in
accordance with the comfort value that
you have chosen.
This system is designed to operate
effectively in all seasons, with the
windows closed. The value indicated on the display cor-
responds to a level of comfort and not
to a temperature in degrees Celsius or
Fahrenheit.

 To switch it off, press the "visibility"
button again or press the "AUTO"
button, the indicator lamp in the but-
ton goes off or the indicator lamp on
the "AUTO" button comes on.
1. Automatic comfort programme
2-3. Driver-passenger side
adjustment When the engine is cold, to
prevent too great a distribu-
tion of cold air, the air fl ow will
reach its optimum level gradually.
In cold weather, it favours the distri-
bution of warm air to the windscreen,
side windows and footwells only.

60
Manual operation
If you wish, you can make a different
choice from that offered by the system
by changing a setting. The other func-
tions will still be controlled automatically.

 Pressing the "AUTO" button returns
the system to completely automatic
operation.
 Press this button to switch
off the air conditioning. 6. Air distribution adjustment

 Press one or more but-
tons to direct the air fl ow
towards:
7. Air fl ow adjustment
 Turn this control to the left
to decrease the air fl ow or
to the right to increase the
air fl ow.
5. Air conditioning On/Off
- the windscreen and side windows (demisting or defrosting),
- the windscreen, the side windows and the vents,
- the windscreen, the side windows, the vents and the footwells,
- the vents and the footwells,
- the vents,
- the footwells,
- the windscreen, the side windows and the footwells.
The air fl ow indicator lamps, between
the two fans, come on progressively
according to the value requested.
For maximum cooling or heat-
ing of the passenger compart-
ment, it is possible to exceed
the minimum value 14 or the maximum
value 28.

 Turn control 2 or 3 to the left un-
til "LO" (low) is displayed or to
the right until "HI" (high) is dis-
played. Switching the system off could result in
discomfort (humidity, condensation).

 Press this button again to return to
automatic operation of the air con-
ditioning. The indicator lamp in the

"A/C" button comes on.

61
Switching the system off

 Turn the air fl ow control to the left
until all of the indicator lamps go off.
This action switches off all of the func-
tions of the system.
Temperature related comfort is no lon-
ger guaranteed but a slight fl ow of air,
due to the movement of the vehicle, can
still be felt.

 Turn the air fl ow dial to the right or
press the "AUTO" button to reacti-
vate the system with the values set
before it was switched off.
Avoid driving for prolonged
periods with the system off.
9. Rear ventilation (Rear)

 Press this button to allow
the air to circulate towards
the rear. The temperature
will be equal to the left-hand
comfort value for the rear
left passengers and equal
to the right-hand comfort
value for the rear right pas-
sengers. The indicator lamp
in the button comes on.
8. Air recirculation

 Press this button to recir-
culate the interior air. The
indicator lamp comes on.
Air recirculation enables the passenger
compartment to be isolated from exte-
rior odours and smoke.

 As soon as possible, press this but-
ton again to return to the intake of
exterior air, and avoid misting. The
lamp in the button goes off.

62
FRONT SEATS
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
Forwards-backwards adjustment

 Raise the control and slide the seat
forwards or backwards. Driver's or passenger's seat height
adjustment

 Pull the control upwards to raise
or push it downwards to lower, as
many times as necessary, to obtain
the position required. Seat back angle adjustment

 Push the control rearwards.
Manual adjustments

63
DRIVER'S ELECTRIC SEAT
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
Forwards-backwards adjustment

 Push the control forwards or rear-
wards to slide the seat. Seat cushion height and angle
adjustment

 Tilt the rear part of the control up-
wards or downwards to obtain the
required height.

 Tilt the front part of the control up-
wards or downwards to obtain the
required angle. Seat back angle adjustment

 Tilt the control forwards or rearwards
to adjust the angle of the seat back. The electrical functions of the
driver's seat are active ap-
proximately one minute after
opening the front door. They are de-
activated approximately one minute
after the ignition is switched off and
in economy mode.
To reactivate them, switch on the
ignition.
