2010.5 PEUGEOT 5008 Owners Manual

PRACTICAL INFORMATION
199
TOWING THE VEHICLE
Procedure for having your vehicle towed
or for towing another vehicle using a re-
movable towing eye.
Access to the tools Towing your vehicle

 On the front bumper, unclip the cover
by pressing at the bottom.

 Screw the towing eye in fully.

 Install the towing bar.

 Switch on the hazard warning lamps
on the towed vehicle.
 On the rear bumper, unclip the cover
by pressing at the bottom.

 Screw the towing eye in fully.

 Install the towing bar.

 Switch on the hazard warning lamps
on the towed vehicle.
Towing another vehicle
The towing eye is installed under the
left-hand concertina board, in the boot
interior trim.
To gain access to it:

 open the boot,

 raise the concertina board,

 remove the towing eye from the
holder. When towing with all four
wheels on the ground, always
use a towing bar.
When towing with only two wheels on
the ground, always use professional
lifting equipment.
When towing with the engine off,
there is no longer any braking or
steering assistance.

 Place the gear lever in neu-
tral (position N on the elec-
tronic gear control gearbox
or automatic gearbox).
Failure to observe this special condi-
tion could result in damage to certain
braking components and the absence
of braking assistance the next time
the engine is started.

PRACTICAL INFORMATION
200
TOWING A TRAILER, A CARAVAN, ETC.
Your vehicle is primarily designed for
transporting people and luggage, but it
may also be used for towing a trailer. Driving advice
The maximum towed load on a long in-
cline depends on the gradient and the
ambient temperature.
In all cases, keep a check on the coolant
temperature.
Side wind

 Take into account the increased
sensitivity to side wind.
Cooling
Towing a trailer on a slope increases
the temperature of the coolant.
As the fan is electrically controlled, its
cooling capacity is not dependent on
the engine speed.

 To lower the engine speed, reduce
your speed. Braking
Towing a trailer increases the braking
distance.
Tyres

 Check the tyre pressures of the towing
vehicle and of the trailer, observing the
recommended pressures.
Lighting

 Check the electrical lighting and sig-
nalling on the trailer.
The rear parking sensors will
be deactivated automatically if
a genuine PEUGEOT towbar
is used.
 If the warning lamp and
the STOP warning lamp
come on, stop the vehicle
and switch off the engine
as soon as possible.
Towbar suitable for the attachment of a
trailer or caravan with additional lighting
and signalling.
Distribution of loads

 Distribute the load in the trailer so
that the heaviest items are as close
as possible to the axle and the nose
weight approaches the maximum
permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load
must be reduced by 10 % for every
1 000 metres of altitude.
Refer to the "Technical Data" section for
details of the weights and towed loads
which apply to your vehicle.
Driving with a trailer subjects the towing
vehicle to more signifi cant stress and
the driver must take particular care.
We recommend the use of
genuine PEUGEOT towbars
and their harnesses that have
been tested and approved from the
design stage of your vehicle, and that
the fi tting of the towbar is entrusted
to a PEUGEOT dealer.
If the trailer is not fi tted by a PEUGEOT
dealer, it is imperative that it is
fi tted using the vehicle's electrical pre-
equipment, in accordance with the
manufacturer's instructions.

PRACTICAL INFORMATION
201
FITTING ROOF BARS Maximum authorised weight
on the roof rack, for a loading
height not exceeding 40 cm
(with the exception of bicycle
carriers): 65 kg.
If the height exceeds 40 cm, adapt
the speed of the vehicle to the pro-
fi le of the road to avoid damaging the
roof bars and the fi xings on the roof.
Be sure to refer to national legislation
in order to comply with the regula-
tions for transporting objects that are
longer than the vehicle.
When fi tting transverse roof bars, use
the four quick-fi t fi xings provided for this
purpose:

 lift the concealing fl aps,

 open the fi xing covers on each bar
using the key,

 put each fi xing in place and lock
them on the roof one by one,

 close the fi xing covers on each bar
using the key.
If your vehicle is fi tted with
roof fi nishers, do not use them
for carrying loads. VERY COLD CLIMATE SCREEN
Removable protective screen which
prevents the accumulation of snow at
the radiator cooling fan.
Before fi tting or removing the screen,
ensure that the engine is off and cool-
ing fan has stopped. It is recommended
that the screen be fi tted and removed
by a PEUGEOT dealer.

 Offer up one of the three screens to
the front of the lower section of the
front bumper (do not use the upper
ventilation grille position).

 Press on the edges A to engage its
fi xing clips.

 Press on the middle at B to com-
plete the engagement of the fi xing
clips.

 Repeat the operation for the other
two screens.
Fitting

PRACTICAL INFORMATION
201
FITTING ROOF BARS Maximum authorised weight
on the roof rack, for a loading
height not exceeding 40 cm
(with the exception of bicycle
carriers): 65 kg.
If the height exceeds 40 cm, adapt
the speed of the vehicle to the pro-
fi le of the road to avoid damaging the
roof bars and the fi xings on the roof.
Be sure to refer to national legislation
in order to comply with the regula-
tions for transporting objects that are
longer than the vehicle.
When fi tting transverse roof bars, use
the four quick-fi t fi xings provided for this
purpose:

 lift the concealing fl aps,

 open the fi xing covers on each bar
using the key,

 put each fi xing in place and lock
them on the roof one by one,

 close the fi xing covers on each bar
using the key.
If your vehicle is fi tted with
roof fi nishers, do not use them
for carrying loads. VERY COLD CLIMATE SCREEN
Removable protective screen which
prevents the accumulation of snow at
the radiator cooling fan.
Before fi tting or removing the screen,
ensure that the engine is off and cool-
ing fan has stopped. It is recommended
that the screen be fi tted and removed
by a PEUGEOT dealer.

 Offer up one of the three screens to
the front of the lower section of the
front bumper (do not use the upper
ventilation grille position).

 Press on the edges A to engage its
fi xing clips.

 Press on the middle at B to com-
plete the engagement of the fi xing
clips.

 Repeat the operation for the other
two screens.
Fitting

PRACTICAL INFORMATION
202
Removal Do not forget to remove the
very cold climate screen:
- when the ambient tempera-
ture exceeds 10 °C,
- when towing,
-
at speeds above 75 mph (120 km/h).
Depending on the model, the clips point
either to the left or to the right.

 Pass your fi ngers through the upper
grille location.


From behind, push the clips in the opposite
direction then pull the part towards you.

 Start with the upper screen 1 , then
the centre screen 2 and fi nish with
the lower screen 3 .

PRACTICAL INFORMATION
203
"Multimedia":
audio systems, amplifi ers, satellite navi-
gation systems, Bluetooth hands-free
system, CD changer, speakers, DVD
player, USB Box, front and rear parking
sensors, additional Bluetooth wireless
headphones, Bluetooth audio head-
phones mains charger. Installation of radio
communication
transmitters
Before installing on your vehicle
any after-market radio communica-
tion transmitter with external aerial,
we recommend that you contact a
PEUGEOT dealer.
The PEUGEOT dealer network will give
you the specifi cation for transmitters
which can be fi tted (frequency, maxi-
mum power, aerial position, specifi c in-
stallation requirements), in line with the
Vehicle Electromagnetic Compatibility
Directive (2004/104/EC).
"Protection":
mats * , boot tray, luggage net, coat hanger
fi xed on head restraint, stainless steel or
carbon door sills.
* To avoid any risk of jamming of the pedals:
- ensure that the mat is positioned and secured correctly,
- never fi t one mat on top of another.
ACCESSORIES
A wide range of accessories and genu-
ine parts is offered by the PEUGEOT
dealer network.
These accessories and parts have been
tested and approved for reliability and
safety.
They are all adapted to your vehicle and
benefi t from PEUGEOT's recommenda-
tion and warranty.
"Safety and security":
anti-theft alarm, window etching, wheel
security bolts, fi rst aid kit, warning tri-
angle, high visibility vest, stolen vehi-
cle tracking system, dog guard, snow
chains.
"Style":
seat covers compatible with lateral air-
bags, leather gear lever knob, foglamps,
door defl ectors, spoiler, styling strips,
alloy wheels, trims, chrome-plated door
handle shells. Depending on the legislation
in force in the country, it may
be compulsory to have a high
visibility safety vest, warning triangle
and spare bulbs and fuses available
in the vehicle.
The fi tting of electrical equip-
ment or accessories which
are not recommended by
PEUGEOT may result in a failure of
your vehicle's electronic system and
excessive electrical consumption.
Please note this specifi c warning. You
are advised to contact a PEUGEOT
representative to be shown the range
of recommended equipment and
accessories.
"Transport solutions":
For leisure pursuits: roof bars, bicycle
carrier on towbar, bicycle carrier on roof
bars, ski carrier, roof box, booster seats
and child seats, side blinds, under shelf
storage.
Trailer towbar, which must be fi tted by a
PEUGEOT dealer.
You can also obtain cleaning and main-
tenance products (exterior and interior),
products for topping up (screenwash
fl uid...) and refi lls (sealant cartridge
for the temporary puncture repair kit...)
from PEUGEOT dealers.

TECHNICAL DATA
204

ENGINES AND GEARBOXES

Petrol
engine
1.6 litre 16V VTi

120 hp
1.6 litre 16V THP
156 hp

Gearbox Manual
(5-speed) Manual
(6-speed) Automatic
(6-speed)
Cubic capacity (cc) 1 598 1 598
Bore x stroke (mm) 77 x 85.8 77 x 85.8
Max power: EU standard (kW) 88 115
Max power engine speed (rpm) 6 000 6 000
Max torque: EU standard (Nm) 160 240
Max torque engine speed (rpm) 4 250 1 400
Fuel Unleaded Unleaded
Catalytic converter yes yes

OIL CAPACITIES (in litres)

Engine (with fi lter replacement) 4.25 4.25
Gearbox - Final drive - -

TECHNICAL DATA
206

ENGINES AND GEARBOXES

Diesel engine
1.6 litre Turbo HDi


110 hp
2 litre Turbo HDi
150 hp
2 litre Turbo HDi
163 hp

Gearbox Manual
(6-speed)
Electronic gear control (6-speed) Manual
(6-speed) Automatic
(6-speed)
Cubic capacity (cc) 1 560 1 997
Bore x stroke (mm) 75 x 88.3 85 x 88
Max power: EU standard (kW) 82 110/120
Max power engine speed (rpm) 4 000 3 750
Max torque: EU standard (Nm) 270 320/340
Max torque engine speed (rpm) 1 750 2 000
Fuel Diesel Diesel
Catalytic converter yes yes
Particle emission fi lter yes yes

OIL CAPACITIES (in litres)

Engine (with fi lter replacement) 3.75 -
Gearbox - Final drive - -
