2010.5 PEUGEOT 5008 Owners Manual

159
Stopping the vehicle
Before switching off the engine, you
can engage position P or N to place the
gearbox in neutral.
In both cases, apply the parking brake
to immobilise the vehicle, unless it is
programmed to automatic mode.
Operating fault
When the ignition is on, the
lighting of this warning lamp,
accompanied by an audible
signal and a message in the
multifunction screen, indicates
a gearbox malfunction.
In this case, the gearbox switches to
back-up mode and is locked in 3rd gear.
You may feel a substantial knock when
changing from P to R and from N to R .
This will not cause any damage to the
gearbox.
Do not exceed 60 mph (100 km/h), local
speed restrictions permitting.
Have it checked by a PEUGEOT dealer.
This warning lamp may also come on if
a door is opened.
You risk damaging the gearbox:
Manual operation

 Select position M for sequential
changing of the six gears.

 Push the lever towards the + sign to
change up a gear.

 Pull the lever towards the - sign to
change down a gear.

D disappears and the gears
engaged appear in succes-
sion in the instrument panel.
If the lever is not in posi-
tion P , when the driver's
door is opened or approxi-
mately 45 seconds after the ignition
is switched off, an audible signal is
heard and a message appears.

 Return the lever to position P ; the
audible signal stops and the mes-
sage disappears.
It is only possible to change from one
gear to another if the vehicle speed and
engine speed permit; otherwise, the
gearbox will operate temporarily in au-
tomatic mode.
Invalid value during manual
operation
This symbol is displayed if a
gear is not engaged correctly
(selector between two posi-
tions).
It is possible to change from position D
(automatic) to position M (manual) at
any time.
When the vehicle is stationary or mov-
ing very slowly, the gearbox selects
gear M1 automatically.
The sport and snow programmes do not
operate in manual mode.
If the engine speed is too low or too
high, the gear selected fl ashes for a few
seconds, then the actual gear engaged
is displayed.
- if you press the accelerator and
brake pedals at the same time,
- if you force the lever from posi- tion P to another position when
the battery is fl at.
To reduce fuel consumption when
stationary for long periods with the
engine running (traffi c jam...), posi-
tion the gear lever at N and apply
the parking brake, unless it is pro-
grammed in automatic mode.

160
VISUAL AND AUDIBLE FRONT AND/OR REAR PARKING SENSORS
System consisting of four proximity sen-
sors, installed in the front and/or rear
bumper.
It detects any obstacle (person, vehicle,
tree, barrier...) located behind the vehi-
cle, however, it will not be able to detect
obstacles located immediately below
the bumper. The parking sensors are
switched on :
- by engaging reverse gear,
- at a speed below 6 mph (10 km/h) in forward gear.
This is accompanied by an audible sig-
nal and display of the vehicle on the
multifunction screen.
An object, such as a stake, a
roadworks cone or any other
similar object may be detected
at the start of the manoeuvre but may
no longer be detected when the ve-
hicle moves nearer to it. The proximity information is indicated by:
- an audible signal which becomes
more rapid as the vehicle approach-
es the obstacle,
- a diagram on the multifunction screen, with blocks which move
closer to the vehicle.
The obstacle is located in relation to the
emission of the audible signal by the
speakers; front or rear and right or left.
When the distance between the vehicle
and the obstacle is less than approxi-
mately thirty centimetres, the audible
signal becomes continuous and/or the
"Danger" symbol appears, depending
on the multifunction screen version.

161
The parking sensor system
cannot, in any circumstances,
replace the need for vigilance
and responsibility on the part
of the driver.
The parking sensors are
switched off :
- when you exit reverse gear,
- when the speed is higher than 6 mph (10 km/h) in forward gear,
- when the vehicle has been station- ary for more than three seconds in
forward gear. Deactivation Operating fault
The system will be deacti-
vated automatically when a
trailer is being towed or when
a bicycle carrier is fi tted (vehicle fi t-
ted with a towbar or bicycle carrier
recommended by PEUGEOT).
Reactivation

 Press button A again, the warning
lamp switches off, the system is re-
activated.

 Press button A , the warning lamp
comes on, the system is fully deacti-
vated. In bad weather or in winter, en-
sure that the sensors are not
covered with mud, ice or snow.
When reverse gear is engaged, an
audible signal (long beep) indicates
that the sensors may be dirty.
When the vehicle is being driven at
a speed below approximately 6 mph
(10 km/h), certain sources of noise
(motorcycles, lorries, pneumatic
drills, ...) may trigger the parking sen-
sor audible signals. If an operating fault occurs,
this warning lamp is displayed
on the instrument panel and/
or a message appears on
the multifunction screen, ac-
companied by an audible signal (short
beep), when reverse gear is engaged.
Consult a PEUGEOT dealer.

162
PARKING SPACE SENSORS
After measuring the parking space avail-
able between two vehicles or obstacles,
this system gives you information on:
- the possibility of fi tting into a free space, depending on the dimen-
sions of your vehicle and the dis-
tances needed for manoeuvring,
- the level of diffi culty of the manoeuvre to be performed.
The system does not measure spaces
which are clearly much smaller or larger
than the size of the vehicle.
Displays on the instrument panel
The parking space sensor
function warning lamp can
have three different states:
- off: the function is not selected,
- on fi xed : the function is selected
but the conditions for measurement
are not yet met (direction indicator
not operating, speed too high) or the
measurement phase has ended,
- fl ashing: measurement is in prog-
ress or the message is being dis-
played. You can activate the "parking space
sensor" function by pressing button
A .
The fi xed illumination of the warning
lamp indicates that the function is
selected.

163
Operation
You have identifi ed a parking space:


Press button A to activate the function.

 Activate the direction indicator on
the side where the space is to be
measured.

 During the measuring, go forward
the length of the space, at a speed
less than 12 mph (approximately
20 km/h), to prepare for your ma-
noeuvre.
The system then measures the size of the space.

 The system informs you of the
level of diffi culty of the manoeuvre
via a message on the multifunction
screen accompanied by an audible
signal. The function displays the following
types of message:

Parking possible

Parking diffi cult

Parking not advised The function deactivates itself automati-
cally:
- when you engage reverse gear,
- when you switch off the ignition,
- fi ve minutes after activation of the
function or after the last measure-
ment operation,
- if the vehicle speed exceeds the threshold of 45 mph (approximately
70 km/h) for one minute.
- The function remains avail-able after each measure-
ment and so can measure
a number of places succes-
sively.
- In bad weather or in winter, ensure that the sensors are
not covered by dirt, or by ice or
snow.
- The parking space sensor function deactivates the front parking sen-
sors during the space measuring
phase when you are in forward
gear.
If there is a malfunction, have the
system checked by a PEUGEOT
dealer. If the lateral distance between
your vehicle and the parking
space is too great, the system
may not operate.

CHECKS
165
BONNET

 Push the exterior safety catch B to
the left and raise the bonnet.

 Unclip the stay C from its housing.

 Fix the stay in the notch to hold the
bonnet open. Closing

 Take the stay out of the support
notch.

 Clip the stay in its housing.

 Lower the bonnet and release it at
the end of its travel.

 Pull on the bonnet to check that it is
secured correctly.
Opening

 Open the front left door.

 Pull the interior bonnet release le-
ver A , located at the bottom of the
door aperture. The location of the interior
bonnet release lever prevents
opening of the bonnet while
the front left door is closed.
When the engine is hot, handle the
exterior safety catch and the bonnet
stay with care (risk of burns).

CHECKS
166
RUNNING OUT OF FUEL (DIESEL)
If your vehicle is fi tted with an HDI en-
gine, the fuel system must be primed if
you run out of fuel; refer to the engine
compartment view on the "Diesel en-
gine" page.
If the engine does not start fi rst time,
don't keep trying.
Operate the priming pump again, then
the starter motor. 1.6 litre Turbo HDI engine

 Fill the fuel tank with at least fi ve litres
of diesel.

 Open the bonnet.

 If necessary, unclip the styling cover
for access to the priming pump.

 Squeeze and release the priming
pump repeatedly until resistance is
felt (there may be resistance at the
fi rst press).

 Operate the starter until the engine
starts (if the engine does not start at the
fi rst attempt, wait around 15 seconds
before trying again).

 If the engine does not start after a
few attempts, operate the priming
pump again then start the engine.

 Clip the styling cover back in place.

 Close the bonnet. 2 litre Turbo HDI engine

 Fill the fuel tank with at least fi ve litres
of Diesel.

 Open the bonnet.

 Unclip the style cover for access to
the priming pump.

 Slacken the bleed screw.

 Squeeze and release the priming
pump repeatedly until fuel appears
in the transparent pipe with the
green connector.

 Retighten the bleed screw.

 Operate the starter until the engine
starts.

 Put the style cover back in position
and clip it in place.

 Close the bonnet.

CHECKS
167
PETROL ENGINES
The various caps and covers allow access for checking the levels of the various fl uids and for replacing certain components.

1. Power steering reservoir.

2. Screenwash and headlamp wash
reservoir.

3. Coolant reservoir.
4. Brake fl uid reservoir.

5. Battery/Fuses.

6. Fusebox.
7. Air fi lter.

8. Engine oil dipstick.

9. Engine oil fi ller cap.
