2009 RENAULT TWINGO Engine And Peripherals Workshop Manual

17B-30
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
D4F, and 780 or 782
17B
aUnclip the intercooler air inlet pipe from the turbo-
charger in the direction of the arrow (5) .
aDisconnect the intercooler air inlet pipe from the tur-
bocharger.
aMove aside the intercooler air inlet pipe.
aDisconnect the petrol vapour rebreathing pipe from:
-the inlet distributor (7) ,
-the air filter unit air outlet pipe (8) .
aUnclip the petrol vapour rebreathing pipe.
aRemove the petrol vapour rebreathing pipe.Note:
If the clip (6) is removed from the heat resistant
protector, the latter must be replaced.
122389

17B-31
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
D4F, and 780 or 782
17B
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aRemove the dipstick.
aDisconnect:
-the oil vapour rebreathing pipe from the inlet dis-
tributor (9) ,
-the injector rail electrical wiring connector (10) ,
-the injector rail fuel supply pipe (11) .aRemove:
-the injector rail bolts (12) ,
-the « injector rail - injector » assembly by pulling it
gently.
aDisconnect the injector electrical wiring connectors.
aRemove the electrical wiring from the « injector rail -
injector » assembly.
aRemove:
-the clips (13) from the injectors,
-the injectors (14) .
122389
122388
WARNING
To avoid any corrosion or damage, protect the
areas on which fuel is likely to r un.
120955
101492

17B-32
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
D4F, and 780 or 782
17B
REFITTING
I - REFITTING PREPARATION OPERATION
aparts always to be replaced: injector clip on in-
jector rail.
aparts always to be replaced: injector seal.
II - REFITTING OPERATION FOR PART
CONCERNED
aRefit:
-the injectors with new seals,
-new clips on the injectors,
-the injector rail - injector electrical wiring.
aConnect the connectors of the electrical wiring to the
injectors.
aRefit:
-the « injector rail - injector » assembly,
-the « injector rail - injector » assembly bolts.
aTorque tighten the injector rail - injector bolts (4.5
N.m).
aConnect:
-the fuel supply pipe on the injector rail,
-the electrical wiring connector to the injector rail,
-the oil vapour rebreathing pipe on the inlet distribu-
tor.
aRefit the dipstick.
III - FINAL OPERATION
aFit the petrol vapour rebreathing pipe.
aClip on the petrol vapour rebreathing pipe.
aConnect the petrol vapour rebreathing pipe to:
-the air outlet pipe of the air filter unit,
-the inlet distributor.aPush the clip of the intercooler air inlet pipe in the di-
rection of the arrow (15) .
aConnect the intercooler air inlet pipe on the turbo-
charger.
aRefit the bolt of the intercooler air inlet pipe on the
throttle valve.
aFit the air filter unit air inlet pipe.
aConnect:
-the air filter unit air inlet pipe on the air filter unit
cover,
-the battery (see ) (80A, Battery).
122666

17B-33
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
K4M
17B
REMOVAL
I - REMOVAL PREPARATION OPERATION
aDisconnect the battery (see ) (80A, Battery).
aRemove:
-the windscreen wiper arms (see Windscreen wip-
er arm: Removal - Refitting) (85A, Wiping -
Washing),
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the scoop under the scuttle panel grille (see Scoop
under the scuttle panel grille: Removal - Refit-
ting) (56A, Exterior equipment).a
aDisconnect the fuel supply pipe (1) from the injector
rail.
aInsert the blanking plugs.
aRemove the inlet distributor (see 12A, Fuel mixture,
Inlet distributor: Removal - Refitting, page 12A-
29) . Tightening torquesm
injector rail bolts10 N.m
IMPORTANT
Wear leaktight gloves (Nitrile type) for this opera-
tion.
IMPORTANT
During this oper ation, be sure to:
-refrain from smoking or bringing red hot objects
close to the working area,
-be careful of fuel splashes when disconnecting the
union.
IMPORTANT
Wear goggles with side protectors for this opera-
tion.
131767
WARNING
To avoid any corrosion or damage, protect the
areas on which fuel is likely to r un.

17B-34
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
K4M
17B
II - REMOVAL OPERATION
aDisconnect the connector (2) from each injector.
aUnclip the wiring on the injector rail.
aRemove:
-the « injector rail - injector » assembly bolts (3) ,
-the « injector rail - injector » assembly.
aRemove:
-the clip (4) from each injector,
-the injectors (5) from the injector rail.REFITTING
I - REFITTING PREPARATION OPERATION
aparts always to be replaced: injector clip on in-
jector rail.
aAlways replace the injector seals.
aRefit:
-new seals on the injectors,
-the injectors on the injector rail,
-new clips on each injector.
II - REFITTING OPERATION
aRefit the « injector rail - injector » assembly.
aClip the wiring on the injector rail.
aConnect the connector on each injector.
aTorque tighten in order the injector rail bolts (10
N.m).
III - FINAL OPERATION
aRefit the inlet distributor (see 12A, Fuel mixture, In-
let distributor: Removal - Refitting, page 12A-29)
.
aRemove the blanking plugs.
aConnect the fuel supply pipe union on the injector
rail.
132390
128397
132390

17B-35
PETROL INJECTION
Injector rail - Injectors: Removal - Refitting
K4M
17B
aRefit:
-the scoop under the scuttle panel grille (see Scoop
under the scuttle panel grille: Removal - Refit-
ting) (56A, Exterior equipment),
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the windscreen wiper arms (see Windscreen wip-
er arm: Removal - Refitting) (85A, Wiping -
Washing).
aConnect the battery (see ) (80A, Battery).

19A-1
COOLING
Engine cooling system: Specifications
D4F or D7F or K4M or K9K
19A
Vehicles in the current range have cooling systems
with the following basic specifications:
-hermetically-sealed pressurised circuit (with expan-
sion bottle valve),
-circuit using only type « D » fluid,
-passenger compartment heating system equipped
with a « heater matrix » type radiator located under
the dashboard which helps to cool the engine.
Coolant quantities
Special notes:
-protection down to - 25˚C ±± ± ±
2 for cold and temperate
countries,
-protection down to - 40˚C ±± ± ±
2 for "extreme cold" coun-
tries.
Thermostat opening temperaturesEngine Quantity
(litres)Grade
D7F 800 5.5
Only use coolant
GLACEOL RX
(type D) D4F 772 5.5
K9K 740 5.7
D4F 780 5.7
D4F 782 5.7
K4M 854 5.7
Engine Star t o f
opening (˚C)Fully open (˚C)
D7F89 99
D4F89 99 ±± ± ±
2
K9K83 ±± ± ±
395
K4M89 101

19A-2
COOLING
Engine cooling system: Check
19A
Expansion bottle cap valve rating:
I - CHECKING THE COOLING SYSTEM USING THE
TOOL (MOT. 1700)
a1 - Checking the expansion bottle cap valve
aUse the cooling system filling and diagnostic tool
(Mot. 1700). Consult the user's manual for this tool
(see Cooling system filling and diagnostic tool:
Use) (Technical Note 3857A, 19A, Cooling).
2 - Checking the sealing of the cooling circuit
aUse the cooling system filling and diagnostic tool
(Mot. 1700). Consult the user's manual for this tool
(see Cooling system filling and diagnostic tool:
Use) (Technical Note 3857A, 19A, Cooling).
II - CHECKING THE COOLING SYSTEM USING THE
TOOL (MS. 554-07)
a Special tooling required
Mot. 1700Fault finding and filling -
bleeding the cooling circuit.
Ms. 554-07Instr ument for testing the
cooling circuit and the expan-
sion bottle valve. Contains
caps 554-01, 554-04, 554-06
IMPORTANT
When working in the engine compartment, take
care as the radiator fan(s) may start up unexpect-
edly (risk of being cut).
To avoid any risk of serious burns when the engine
is hot:
-do not open the expansion bottle cap,
-do not drain the cooling system,
-do not open the bleed screw(s).
Note:
There are two procedures for checking the cooling
system:
-the procedure using the (Mot. 1700)
-the procedure using the (Ms. 554-07)
Expansion bottle cap with
...Valve rating
... a brown circle1.2 bar
... a yellow marking1.4 bar
... a white marking1.6 bar
... a grey marking1.8 bar
WARNING
If the coolant is leaking from the expansion bottle
cap, replace the valve.
107138
WARNING
If the coolant is leaking from the expansion bottle
cap, replace the valve.
