2009 RENAULT TWINGO Engine And Peripherals Workshop Manual

11A-20
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
D4F or D7F, and AIR CONDITIONING or STANDARD HEATING
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
aRemove:
-the engine undertray,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection).
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) .II - OPERATION FOR REMOVAL OF PART
CONCERNED
aRemove the flywheel protector.
aFit the immobilising tool (1) (Mot. 582-01). Special tooling required
Mot. 582-01Flywheel locking tool.
Tightening torquesm
crankshaft accessories
pulley bolt40 N.m + 75˚ ±± ± ±
6
D4F, and 772 – D7F
120407
120408

11A-21
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
D4F or D7F, and AIR CONDITIONING or STANDARD HEATING
11A
aLock the flywheel by inserting a large flat-blade
screwdriver into the gearbox aperture.
aRemove:
-the accessories pulley bolt (2) ,
-the accessories pulley.
REFITTING
I - REFITTING PREPARATION OPERATION
aClean the crankshaft accessories pulley V-grooves
with a brush to prevent any deposits.aparts always to be replaced: Accessories belt,
parts always to be replaced: Accessories belt
tensioning roller,
parts always to be replaced: Accessories ten-
sioning roller bolt (to be replaced by the hexagonal
head bolt, part no. 77 03 101 075),
parts always to be replaced: Crankshaft acces-
sories pulley bolts.
aparts always to be replaced: Accessories belt,
parts always to be replaced: Crankshaft acces-
sories pulley bolts.
II - REFITTING OPERATION FOR PART
CONCERNED
aRefit the crankshaft accessories pulley using a new
bolt.
aTorque tighten the crankshaft accessories pulley
bolt (40 N.m + 75˚ ±± ± ±
6).
aRemove the large flat screwdriver from the opening
in the gearbox.
aRemove the immobilising tool (Mot. 582-01).
aRefit the flywheel protector.
III - FINAL OPERATION
aRefit:
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) , D4F, and 780 or 782
122665
WARNING
Only use brushes with plastic or non-corrosive
metal (brass) bristles.
AIR CONDITIONING
STANDARD HEATING
D4F, and 780 or 782
D4F, and 772 – D7F

11A-22
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
D4F or D7F, and AIR CONDITIONING or STANDARD HEATING
11A
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the engine undertray.

11A-23
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
C44, and K9K
11A
PARTS AND CONSUMABLES FOR THE
REPAIR WORK
aParts always to be replaced:
-accessories belt,
-accessories belt auto tensioner,
-accessories belt auto tensioner bolt.
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift ( (see Vehicle:
Towing and lifting) ).aDisconnect the battery ( (see Battery: Removal -
Refitting) ).
aRemove:
-the front right-hand wheel ( (see Wheel: Removal
- Refitting) ),
-the front right-hand wheel arch liner ( (see Front
wheel arch liner: Removal - Refitting) ),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) ,
-the accessories belt auto tensioner.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aRemove:
-the crankshaft position sensor (see 13B, Diesel in-
jection, Crankshaft position sensor: Removal -Refitting, page 13B-15) , Tightening torquesm
crankshaft accessories
pulley bolt80 Nm
19656

11A-24
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
C44, and K9K
11A
-the crankshaft accessories pulley bolt (1) , locking
the flywheel using a flat screwdriver at the point of
the crankshaft position sensor,
-the crankshaft accessories pulley (2) .
REFITTING
I - REFITTING PREPARATIONS OPERATION
aIf reusing the crankshaft accessories pulley, clean
the pulley V-grooves with a brush to eliminate any
deposits.
II - REFITTING OPERATION FOR PART
CONCERNED
aRefit:
-the crankshaft accessories pulley,
-the crankshaft accessories pulley bolt.
aTorque tighten the crankshaft accessories pulley
bolt (80 Nm), locking the flywheel using a flat screw-
driver at the point of the crankshaft position sensor.
aRefit the crankshaft position sensor (see 13B, Die-
sel injection, Crankshaft position sensor: Re-
moval - Refitting, page 13B-15) .
III - FINAL OPERATION.
aRefit:
-the new accessories belt auto tensioner,
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) .
aRefit:
-the front right-hand wheel arch liner ( (see Front
wheel arch liner: Removal - Refitting) ),
-the front right-hand wheel ( (see Wheel: Removal
- Refitting) ).
aConnect the battery ( (see Battery: Removal - Re-
fitting) ).

11A-25
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
K4M
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
aDisconnect the battery (see Battery: Removal - Re-
fitting) (80A, Battery).
aRemove:
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the engine undertray,
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the headlights (see Halogen headlight: Removal
- Refitting) (80B, Headlights),
-the bonnet catch (see Bonnet lock: Removal -
Refitting) (52A, Non-side opening element mecha-
nisms),
-the front upper cross member (see Front upper
cross member: Removal - Refitting) (42A, Upper
front structure),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) .II - REMOVAL OPERATION
aRemove:
-the bolt (1) from the crankshaft accessories pulley
by locking the flywheel using a screwdriver,
-the crankshaft accessories pulley.
REFITTING
I - REFITTING PREPARATION OPERATION
aparts always to be replaced: Crankshaft acces-
sories pulley bolts. Tightening torquesm
crankshaft accessories
pulley bolts120 N.m + 95˚
±± ± ±
10˚
IMPORTANT
Wear cut-resistant gloves during the operation.
WARNING
Do not r un the engine without the accessories belt
to avoid damaging the crankshaft accessories pul-
ley.
133106
14487

11A-26
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
K4M
11A
aUse a brush to remove any deposits from the crank-
shaft accessories pulley V grooves.
II - REFITTING OPERATION
aRefit the crankshaft accessories pulley.
aTighten to torque and angle the crankshaft acces-
sories pulley bolts (120 N.m + 95˚ ±± ± ±
10˚) by locking
the engine flywheel using a flat-blade screwdriver.
III - FINAL OPERATION
aRefit:
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) .
-the front upper cross member (see Front upper
cross member: Removal - Refitting) (42A, Upper
front structure),
-the bonnet catch (see Bonnet lock: Removal -
Refitting) (52A, Non-side opening element mecha-
nisms),
-the headlights (see Halogen headlight: Removal
- Refitting) (80B, Headlights),
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the engine undertray,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
aConnect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).

11A-27
TOP AND FRONT OF ENGINE
Timing belt: Removal - Refitting
D7F, and 800
11A
PARTS AND CONSUMABLES FOR THE
REPAIR WORK
aParts always to be replaced:
-the timing belt,
-the tensioning roller,
-the accessories pulley bolt.
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) .
aDisconnect the battery ( (see Battery: Removal -
Refitting) ).
aRemove:
-the front right-hand wheel arch liner (see) (see ) ,
-the front right-hand wheel ( (see Wheel: Removal
- Refitting) ),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-3) ,-the accessories pulley (see 11A, Top and front of
engine, Crankshaft accessories pulley: Remov-
al - Refitting, page 11A-20) ,
-the rear suspended engine mounting (see 19D,
Engine mounting, Lower engine tie-bar: Re-
moval - Refitting, page 19D-18) .
aSet up the engine support tool (Mot. 1379) (1) .
aTighten the bolt (2) to pre-stress the engine stand.
aRemove the right-hand suspended engine mounting
(see 19D, Engine mounting, Right-hand sus-
pended engine mounting: Removal - Refitting,
page 19D-13) . Special tooling required
Mot. 1379Engine suppor t tool for cylin-
der head oper ations.
Mot. 1054TDC setting pin.
Mot. 1386Tool for pre-tensioning the
timing belt.
Mot. 1135-01Timing belt tensioner.
Mot. 1715Belt tension checking tool
(frequency indicator).
Mot. 1505Belt tension setting tool (fre-
quency meter)
Equipment required
torque wrench
Tightening torquesm
tensioning roller nut50 N.m
upper timing cover bolts33 N.m
10267
