2008 MERCEDES-BENZ ML63AMG Owner's Manual

528 Technical data
Fuels, coolants, lubricants
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which
provides:

Corrosion protection

Freeze protection

Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -35°F (-37°C) and corro-
sion protection.If the antifreeze mixture is effective to
-35°F (-37°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).
The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for
replacement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Light Truck
Center.To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately -35°F
[-37°C]). If you use a solution that is more
than 55% anticorrosion/antifreeze (freeze
protection to approximately -49°F
[-45°C]), the engine temperature will
increase due to the lower heat transfer
capability of the solution. Therefore, do not
use more than this amount of anticorro-
sion/antifreeze.
If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label instruc-
tions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Light
Truck Center.
!Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the
Mercedes-Benz Limited Warranty.

529 Technical data
Fuels, coolants, lubricants
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be
specifically formulated to protect the aluminum parts. Failure to use such
anticorrosion/antifreeze coolant will result
in a significantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Light Truck Center for service.
Anticorrosion/antifreeze quantity
Approximate freeze protection
Model-35°F (-37°C)-49°F (-45°C)
ML 320 CDI
ML 3505.0 US qt (4.75 l)5.5 US qt (5.2 l)
ML 5501
1Data preliminary.
5.6 US qt (5.25 l)6.1 US qt (5.8 l)
ML 63 AMG6.1 US qt (5.8 l)6.8 US qt (6.4 l)

530 Technical data
Fuels, coolants, lubricants
Windshield washer system and
headlamp cleaning system*
Both the windshield washer system and
headlamp cleaning system* are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately 8.1 US qt (7.7 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ration
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:

1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1gal [4.0l] water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit ” and commercially avail-
able premixed windshield washer
solvent/antifreeze:

1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent)Warning!G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

531 Index
A
ABS 98
Indicator lamp 400
Messages in the multifunction
display 415
Off-road - ABS 99
Accelerator position, automatic
transmission 190
Accessory weight 379
Accident 64
Active head restraint 88, 127, 458
Adaptive Damping System (ADS)* 255
Air bags 74
Children 75, 89
Front passenger front air bag off
indicator lamp 31, 83
Front, Driver 77
Front, Passenger 77
Occupant Classification System
(OCS) 79
Safety guidelines 76
Side impact (front and rear*) 78
Window curtain 78Air conditioning refrigerant 525
Air conditioning system see
Climate control or
Automatic climate control (3-zone)*
Air conditioning, Cooling 214, 229
Air distribution, Front 209, 224
Air distribution, Rear 217, 233
Air pressure see Tire inflation pressure
Air pump, electric (ML 63 AMG) 485
Air recirculation mode 212, 227
Air suspension program* 254
Adaptive Damping System
(ADS)* 255
Messages in the multifunction
display 447
Vehicle level control* 255
Air vents 217
Air vents, Front 210, 224
Air vents, Rear 234
Air volume 210, 225
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 450, 483Anticorrosion/antifreeze 529
Antiglare, Interior rear view mirror 199
Antiglare, Rear view mirrors* 199
Antilock Brake System see ABS
Anti-theft systems 107
Anti-theft alarm system 106, 107
Immobilizer 106
Aquaplaning see Hydroplaning
Armrest storage/telephone* compart-
ment
Front 281
Ashtrays (Depending on vehicle
configuration) 285
Aspect ratio 379
ATF 345
Attaching a trailer 330
AUDIO menu 160
Audio menu
CD operation 161
Radio operation 160
Satellite radio* operation 160
Auto-dimming*, Rear view mirrors 199
Automatic central locking, Control
system 175

532 Index
Automatic climate control (3-zone)* 218
Air conditioning, Cooling 229
Air distribution, Front 224
Air distribution, Rear 233
Air recirculation mode 227
Air vents, Front 224
Air volume 225
Control panel, Front 220
Control panel, Rear 231
Deactivating system 222
Defogging 225
Defrosting 225
Maximum cooling, MAXCOOL 226
Rear passenger compartment 231
Rear window defroster 203
Residual engine heat (REST) 230
Using driver-side settings for
all temperature zones 229
Automatic headlamp mode 136
Automatic lighting control, Interior
lighting 142
Automatic locking when driving 125
Automatic shift program
(ML 63 AMG only) 195Automatic transmission 54
Accelerator position 190
Automatic shift program
(ML 63 AMG only) 195
Emergency operation
(Limp-Home Mode) 197
Gear ranges 192
Gear selector lever 54, 183
Gear shifting malfunctions 197
Hill start assist system 191
Kickdown 190
Kickdown, manual shift program
(ML 63 AMG only) 196
Manual shift progam
(ML 63 AMG only) 195
Program mode selector switch
(ML 63 AMG only) 194
Shift program (ML 63 AMG only) 194
Shifting procedure 186
Starting the engine 54
Steering wheel gearshift control 193
Towing a trailer 191
Transmission fluid level 345
Transmission positions 187
Automatic Transmission Fluid see ATFB
Backrest
Seat 44
Seat, Lumbar support 129
Seat, Multicontour* 129
Backup lamps
Messages in the multifunction
display 438
Replacing bulbs 471
Bar 380
BAS 100
Lamps in instrument cluster 400
Messages in the multifunction
display 415
Basic carrier bars* 266
Batteries, SmartKey
Check lamp 110, 113
Messages in the multifunction
display 427
Replacing 461
Battery, Vehicle 489
Charging 496
Disconnecting and connecting 491
Jump starting 497
Removing and installing 491

533 Index
Bead 380
Belt reel 276
Beverage holder see Cup holder
Block heater (Canada only) 385
Bolts, Collapsible tire
(ML 63 AMG only) 453
Bolts, Minispare wheel
(except ML 63 AMG) 452
Brake fluid 525
Checking 339
Messages in the multifunction
display 430
Brake lamp
Cleaning lenses 393
Messages in the multifunction
display 438
Replacing bulbs 471
Brake pads 312
Messages in the multifunction
display 428
Brakes 312
Warning lamp 401
Break-in period 310
Bulbs, replacing see Replacing bulbs
Button for Voice control* system 30,
148C
California retail buyers and lessees,
Important notice for 11
Camera see Rear view camera*
Can holder see Cup holder
Capacities and recommended
fuel/lubricants 522
Card holder 32, 35, 284
Cargo compartment cover blind 271
Cargo net* 272
Cargo tie-down rings 268
Carpets, Cleaning 397
Catalytic converter
(gasoline engine) 335
CD changer* 161, 279
CD player 161
Center console
Lower part 32
Upper part 31
Central locking
Automatic 125
Locking/unlocking from the
inside 126
Switch 126Certification label 510
CHECK ENGINE malfunction
indicator lamp 403, 404
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 365
Checking tire pressure electronically with
the Tire Pressure Monitoring System
(TPMS), (USA only) 362
Checklist
Off-road driving 322
Returning from off-road driving 327
Children in the vehicle 89
Air bags 75, 89
Blocking rear door window
operation 96
Indicator lamp, Front passenger front
air bag 83
Infant and child restraint systems 84,
90
LATCH-type child seat anchors 93
Occupant Classification System
(OCS) 79
Cigarette lighter (Depending on vehicle
configuration) 286

534 Index
Climate control 204
Air conditioning, Cooling 214, 215
Air distribution, Front 209
Air distribution, Rear 217
Air recirculation mode 212
Air vents, Front 210
Air volume 210
Control panel*, Rear 216
Control panel, Front 206
Deactivating system 208
Defogging 212
Defrosting 210
Rear window defroster 203
Residual engine heat (REST) 215
Clock 27, 169
Cloth upholstery,
Cleaning and care of 397
Cockpit 24
Cockpit Management and Data System
see COMAND system
Cold tire inflation pressure 380
Collapsible tire 518
Collapsible tire (ML 63 AMG only) 453
Collapsible wheel chock 452COMAND system see separate operating
instructions
Combination switch 59, 60, 62, 139
Compass 307
Adjustment 173
Calibration 174
Calling up the compass 307
Control and operation of radio
transmitters 334
Control system 147
Multifunction display 147
Multifunction steering wheel 148
Resetting to factory default 164
Control system menus 147
AIRMATIC*/Compass 162
AMG menu 156
AUDIO 160
NAV* 161
Settings 163
Standard display 154
TEL* 180
Trip computer 178
Vehicle configuration 177
Vehicle status message memory 162Control system submenus 151, 153, 166
Comfort* 176
Instrument cluster 167, 168
Lighting 170
Time/Date 169
Vehicle 173
Coolant 345, 528
Anticorrosion/antifreeze
mixing ratio and quantity 529
Capacities 522
Checking coolant level 339, 345
Messages in the multifunction
display 431, 433
Temperature 336
Temperature display 154
Corner-illuminating front fog lamps* 140
Messages in the multifunction
display 439
Replacing bulbs 469
Crossing obstacles 325
Cruise control 244
Activating 246
Messages in the multifunction
display 416

535 Index
Cup holders 284
Cleaning 285
Front center console 285
Front center console,
Removing/Installing 285
Rear armrest 284
Curb weight 380
Current transmission program mode
(AMG vehicles only) 147
D
Date display, Setting 169
Daytime running lamp mode 137
Setting 170
Deep water see Standing water
Defogging windshield 210, 225
Defrosting, Front 210, 225
Defrosting, Rear 203
Delayed shut-off
Exterior lamps 171
Interior lighting 172
Department of Transportation see DOT
Diesel engine
Preglow indicator lamp 29Difficulties
While driving 63
While starting 57
Digital clock see Clock
Digital speedometer 147, 155
Dimensions, Vehicle 520
Direction of rotation (tires) 351
Displays
Digital speedometer 147, 155
Maintenance service indicator 386
Messages in the multifunction
display 413
Multifunction display 147
Outside temperature 147, 155
Selecting 168
Symbol messages 427
Text messages 415
Vehicle status message 162, 413
Vehicle system settings,
Control system 151, 153, 163
Distance to empty (range), Trip
Computer 178Door
Entry lamps 144
Locking, In an emergency 456
Locking/unlocking,
KEYLESS-GO* 39, 69
Locking/unlocking, SmartKey 38, 68
Messages in the multifunction
display 435
Opening from inside/outside 112,
118
Remote door unlock (Tele Aid) 301
Unlocking, Mechanical key 455
Door control panel 36
Door handle 36
Door windows see Power windows
DOT 374, 380
Downhill driving
Cruise control 246
Downhill Speed Regulation (DSR) 249
Messages in the multifunction
display 428
Drinking and driving 311
