2008 MERCEDES-BENZ ML63AMG Owner's Manual

232 Controls in detail
3-zone automatic climate control*
Operating from the front
Deactivating
Press button> (page 220).
The indicator lamp on the button goes
out.
In displaye (
page 220), you will see
the> symbol followed by
MODE for
approximately 3 seconds.
Press button´ (page 220).
In displaye (
page 220), you will see
the> symbol followed by
OFF.
The rear automatic climate control is
switched off.Reactivating
Press button> (page 220).
The indicator lamp on the button
comes on.
In displaye (
page 220), you will see
the> symbol followed by
ON and
MODE. The MODE display is cleared and
the indicator lamp on button>
goes out after approximately
3 seconds.
The rear automatic climate control
switches on.Setting the temperature
Press button> (page 220).
The indicator lamp on the button
comes on.
In displaye (
page 220), you will see
the> symbol followed by
MODE.
Set the desired temperature for the
rear passenger compartment using
temperature control3 (
page 231).
After approximately 3 seconds after
the last adjustment, the display switch-
es back to its standard display and the
indicator lamp on button> goes
out.
iYou can also press the>button once
more to switch back to the standard display.

233 Controls in detail
3-zone automatic climate control*
Adjusting air distribution
Use the air distribution controls5 or6
to adjust the air distribution for the rear
passenger compartment.
The symbols on the controls represent the
following functions:
Adjusting manually
Press the desired air distribution con-
trol.
The indicator lamp on buttonU
goes out.Adjusting automatically
Press buttonU while the engine is
running.
The indicator lamp on the button
comes on. The air distribution is adjust-
ed automatically.
Setting the temperature
Use temperature control3 (
page 231)
to separately adjust the air temperature of
the rear passenger compartment.
You should raise or lower the temperature
setting in small increments, preferably
starting at 72°F (22°C). The automatic cli-
mate control will adjust to the set temper-
ature as fast as possible.Increasing the temperature
Turn temperature control3
(
page 231) slightly clockwise.
The rear automatic climate control will
correspondingly adjust the interior air
temperature for the rear passenger
compartment.
Decreasing the temperature
Turn temperature control3
(
page 231) slightly counterclock-
wise.
The rear automatic climate control will
correspondingly adjust the interior air
temperature for the rear passenger
compartment.
SymbolFunction
ZDirects air to the center air
vents
YDirects air to the footwells and
the side air vents
iThe rear automatic climate control will not
cool the air when the air conditioning is switched
off (
page 229).

234 Controls in detail
3-zone automatic climate control*
Adjusting air volume
Adjusting manually
Five blower speeds are available.
Press button
to decrease or
buttonQ to increase air volume to
the desired level.
The indicator lamp on the buttonU
goes out. The selected blower speed is
shown by the indicator lamps for air
volume settings9 (
page 231).
Adjusting automatically
Press buttonU.
The indicator lamp on the button
comes on. The air volume is adjusted
automatically.

235 Controls in detail
Power windows
Power windows
The door windows are opened and closed
electrically. The switches for all door win-
dows are located on the driver’s door con-
trol panel. The switches for the respective
door windows are located on the front
passenger door and the rear doors.
Switch on the ignition (page 39).
Warning!G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
Activate the override switch (
page 96)
when children are riding in the back seats of
the vehicle. The children could otherwise in-
jure themselves, e.g. by becoming trapped
in the window opening.
The closing of a door window can be imme-
diately halted by releasing the switch or, if
switch was pulled past the resistance point
and released, by either pressing or pulling
the respective switch.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you pulled the switch past the resistance
point and released it to close the door win-
dow, the automatic reversal function will
stop the window and open it slightly.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you are closing a door window by pulling and
holding the switch, or by pressing and hold-
ing button‹on the SmartKey, by press-
ing and holding the lock button (vehicles
with KEYLESS-GO*) on a door handle, the
automatic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised
access to a vehicle could result in an
accident and/or serious personal injury.iYou can also open or close the windows
using the SmartKey, see “Summer opening fea-
ture” (
page 237) and see “Convenience clos-
ing feature” (
page 238).
Depending on the current position, the power
windows may also open or close when the air
recirculation button: on the control panel of
the climate control (
page 206) or automatic
climate control* (
page 220) is pressed and
held.
iAfter switching off the ignition (page 39)
or removing the SmartKey from the starter
switch, the windows can be operated

until you open the driver’s or front passenger
door

for at least 5 minutes if nor door was opened

236 Controls in detail
Power windows
Door windows
1Left front door window
2Right front door window
3Right rear door window
4Left rear door windowOpening the door windows
Press switch1, 2, 3, or4
(
page 236) to the resistance point.
The corresponding door window moves
downwards until you release the
switch.
Closing the door windows
Pull switch1, 2, 3, or4
(
page 236) to the resistance point.
The corresponding door window moves
upwards until you release the switch.Fully opening the door windows
(Express-open)
Press switch1, 2, 3, or4
(
page 236) past the resistance point
and release.
The corresponding door window opens
completely.
Fully closing the door windows
(Express-close)
Pull switch1, 2, 3, or4
(
page 236) past the resistance point
and release.
The corresponding door window closes
completely.
Warning!G
If you pull and hold the switch up when clos-
ing the door window, and upward movement
of the door window is blocked by some ob-
struction including but not limited to arms,
hands, fingers, etc., the automatic reversal
will not operate.
Warning!G
Driver’s door only:
If within 5 seconds switch is again pulled
past the resistance point and released, the
automatic reversal will not function.

237 Controls in detail
Power windows
Remove the obstruction.
Pull the respective door window switch
past the resistance point again and
release.
Stopping door windows during
Express-operation
Press or pull the respective door
window switch again.
Synchronizing the door windows
The door windows must be resynchronized

after the battery was disconnected

if the door windows cannot be fully
opened (Express-open) or closed
(Express-close)
Close all doors.
Switch on the ignition (page 40).
Pull and hold switch1, 2,3, or4
(
page 236).
Once a door window is closed com-
pletely, hold the respective switch for
approximately 3 seconds.
The door window is synchronized.
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously:

opening the door windows

opening the tilt/sliding sunroof

switching on the seat ventilation* for
the driver’s seat
iIf the upward movement of a door window is
blocked during the closing procedure, the door
window will stop and open slightly.
iIf the door window still does not close when
there is no obstruction, pull and hold the respec-
tive power window switch. The door window will
then close without the obstruction sensor
function.iEach door window must be resynchronized
separately.


238 Controls in detail
Power windows
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle.
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.
Press and hold buttonΠon the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof have reached
the desired position.
Release buttonΠon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
Convenience closing feature
When locking the vehicle, you can simulta-
neously close

the door windows

the tilt/sliding sunroof
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(
page 238).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.
Warning!G
When closing the windows and the
tilt/sliding sunroof, make sure that there is
no danger of anyone being harmed by the
closing procedure.
If potential danger exists, proceed as fol-
lows:

Release button‹ to stop the closing
procedure. To open, press and hold
buttonŒ. To continue the closing
procedure after making sure that there
is no danger of anyone being harmed by
the closing procedure, press and hold
button‹.
Vehicles with KEYLESS-GO*:

Release the lock button (page 69) on
the driver’s outside door handle to stop
the closing procedure.

Immediately pull on the same outside
door handle and hold firmly. The win-
dows and the tilt/sliding sunroof will
open for as long as the door handle is
held but the door is not opened.


239 Controls in detail
Power windows
Press and hold button‹ on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof are completely
closed.
Release button‹ on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:
Press and hold the lock button on an
outside door handle (
page 69) until
the windows and the tilt/sliding sun-
roof are completely closed.
Release the lock button on the outside
door handle to interrupt the closing
procedure.
