2008 MERCEDES-BENZ ML63AMG Owner's Manual

456 Practical hints
Unlocking/locking in an emergency
Locking the vehicle
If you cannot lock the vehicle with the
SmartKey or KEYLESS-GO*, lock the vehi-
cle carrying out the following steps.
Close the front passenger door, the
rear right door and the tailgate.
Open the driver’s door and the rear left
door.
Press the central locking switch on the
driver’s door (
page 126).
The locking knobs of the front passen-
ger door and the rear doors move
down.
If the vehicle battery is disconnected or
drained:
Press down the locking knobs of
the front passenger door and the
rear doors manually.
Exit the vehicle.
Close the driver’s door.
Enter the vehicle through the rear left
door.
Press down the locking knob of the
driver’s door.
Exit the vehicle.
Close the rear left door.
The vehicle is locked.
Unlocking and opening the tailgate
A minimum height clearance of 7.2 ft
(2.20 m) is required to open the tailgate.If the tailgate can no longer be unlocked
and opened using the Œbutton on the
SmartKey or the KEYLESS-GO* function,
use the emergency release lever to unlock
and open the tailgate.
The emergency release lever is located on
the inside of the tailgate.
1Emergency release lever
2CoverRemove cover2 from the trim on the
tailgate.
Push release lever1 all the way to the
left.
Lift the tailgate.
!To prevent inadvertent lockout, make sure
to have the SmartKey or SmartKey with
KEYLESS-GO* with you before proceeding with
the next step. The next step will lock the vehicle.
iThis procedure does not arm the anti-theft
alarm system, nor does it lock the fuel filler flap.

457 Practical hints
Unlocking/locking in an emergency
Fuel filler flap
Open the tailgate (page 119).
The fuel filler flap release is located behind
a cover in the right side trim panel of the
cargo compartment.
1Lock
2Cover
Insert a suitable object such as a coin
into the slot of lock1.
Turn lock1 by 90° in direction of
arrow.
Remove cover2.3Fuel filler flap release
Pull yellow fuel filler flap release3 in
direction of arrow.
The fuel filler flap is unlocked.
Open the fuel filler flap (page 337).
!Always make sure there is sufficient over-
head clearance.
iIf the vehicle has previously been locked
from the outside using the SmartKey or
KEYLESS-GO*, opening the tailgate from the
inside using the emergency release lever will
trigger the anti-theft alarm system.
To cancel the alarm, do one of the following:

Insert the SmartKey or the SmartKey with
KEYLESS-GO* in the starter switch.

Press buttonŒ or‹ on the
SmartKey or the SmartKey with
KEYLESS-GO*.
In vehicles with KEYLESS-GO*:

Pull an outside door handle.
The SmartKey with KEYLESS-GO* must be
within 3 ft (1 m) of the vehicle.

Press the KEYLESS-GO* start/stop button
(
page 41).
The SmartKey with KEYLESS-GO must be
inside the vehicle.

458 Practical hints
Resetting activated head restraints
If the active head restraints have been trig-
gered in a rear-end collision, the active
head restraints must be reset. Otherwise,
the active head restraints cannot offer any
additional protection in the event of anoth-
er rear-end collision.
You can tell that the head restraints have
been activated when they have been
moved forward and cannot be adjusted.
Vehicles without Rear seat entertain-
ment system*1Pull
2Adjust downward
3Press
Pull the top of the head restraint cush-
ion in direction of arrow1 as far as it
will go.
Adjust the head restraint cushion
downward in direction of arrow2 as
far as it will go.
Firmly press the top of the active head
restraint cushion towards the head
restraint cover in direction of arrow3
until it engages.
Warning!G
For safety reasons, have the active head re-
straints checked by an authorized
Mercedes-Benz Light Truck Center after a
rear-end collision.
Warning!G
When pushing back the head restraint cush-
ion, take care that your fingers do not be-
come caught between the head restraint
cushion and the cover. Failing to do so may
lead to injury.
!Be careful not to damage upholstery.
iFor your convenience, we recommend that
you have this work carried out by an authorized
Mercedes-Benz Light Truck Center.
iPressing the head restraint cushion back
requires high force. If you encounter difficulties
when pushing the head restraint back please
have the procedure performed at an authorized
Mercedes-Benz Light Truck Center.

459 Practical hints
Resetting activated head restraints
Repeat this procedure on the active
head restraint for the second front
seat.
For information on active head restraints,
see “Active head restraint” (
page 88).
For information on head restraint adjust-
ment, see “Seats” (
page 43).Vehicles with Rear seat entertainment
system*
Take the reset tool out of the
Mercedes-Benz vehicle literature
pouch.
1Reset tool
2Active head restraint1Reset tool
2Active head restraint
3Rectangular opening
Guide reset tool1 into rectangular
opening3 of active head restraint2.
Press reset tool1 downward in
direction of arrow until you hear the
head restraint release mechanism
audibly disengage.
Pull out reset tool1.

460 Practical hints
Resetting activated head restraints
Firmly press the active head restraint
cushion backward towards the head
restraint cover in direction of arrow
until it engages.
Repeat this procedure on the active
head restraint for the second front
seat.
After resetting the active head
restraints store reset tool1 in the
Mercedes-Benz vehicle literature
pouch.
For information on active head restraints,
see “Active head restraint” (
page 88).
For information on head restraint adjust-
ment, see “Seats” (
page 43).


461 Practical hints
Replacing SmartKey batteries
Replacing SmartKey batteries
If the batteries in the SmartKey or the
SmartKey with KEYLESS-GO* are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an autho-
rized Mercedes-Benz Light Truck Center.
Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove mechanical key1 from the
SmartKey or SmartKey with
KEYLESS-GO* (
page 455).1Mechanical key
2Battery compartment
Insert mechanical key1 into opening.
Press mechanical key1 in direction of
arrow.
The battery compartment2 is
unlatched.
Pull battery compartment2 out of the
SmartKey housing.
Warning!G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen inserting the batteries, make sure
they are clean and free of lint.
iWhen replacing batteries, always replace
both batteries.
The required replacement batteries are available
at any Mercedes-Benz Light Truck Center.


462 Practical hints
Replacing SmartKey batteries
3Batteries
4Contact spring
Pull out batteries3.
Using a line-free cloth, insert new
batteries3 under contact springs4
with the positive terminal (+) side
facing up.
Return battery compartment2 into
housing until it locks into place.
Slide mechanical key1 back into the
SmartKey or SmartKey with
KEYLESS-GO*.
Check the operation of the SmartKey
or SmartKey with KEYLESS-GO*.


463 Practical hints
Replacing bulbs
Replacing bulbs
Bulbs
Safe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp as-
semblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See an authorized
Mercedes-Benz Light Truck Center for
headlamp adjustment.iIf the headlamps or front fog lamps are
fogged up on the inside as a result of high humid-
ity, driving the vehicle a distance with the lights
on should clear up the fogging.iSubstitute bulbs will be brought into use
when the following lamps malfunction:

Turn signal lamps

Brake lamps

Parking lamps

Tail lamps
Read and observe the messages in the multi-
function display (
page 438).
