320 Operation
Driving instructions
Read this chapter carefully before you be-
gin off-road travel.
Familiarize yourself with the vehicle char-
acteristics and gear changing before you
attempt any difficult terrain off-road driv-
ing. We recommend that you start out with
easy off-road travel.Special driving features for off-road
driving
The following driving features are available
for specific kind of operation:

Off-road – ABS (page 99)

Off-road – ESP® (page 103)

Off-road – 4-ETS (page 105)

Hill start assist system (page 191)

Downhill Speed Regulation (DSR)
(
page 249)

Off-road driving program (page 253)

Air suspension* (page 254)
Never let the vehicle roll backwards in idle.
You may lose control of the vehicle if you
use only the service brake. For information
on driving downhill, see “Driving downhill”
(
page 324).
Warning!G
Sand, dirt, mud and other material having
friction property can cause exceptional wear
and tear as well as brake failure.
Have the brakes checked for dirt build-up
and cleaned. There is otherwise a risk that
full braking power may not be available in an
emergency.
Warning!G
Vehicles with air suspension program*:
Please be aware that by raising the vehicle
level, the center of gravity also rises. There-
fore, always ensure that the vehicle level is
as low as possible. With higher ride height
the ESP
® may activate earlier in certain
situations.


321 Operation
Driving instructions
Off-road driving rules

Engage the off-road driving program
(
page 253) before driving under
off-road conditions.

Vehicles with air suspension program*:
Make sure you select a vehicle level
(
page 255) appropriate to the topo-
graphical conditions. Always make
sure the vehicle has enough ground
clearance.

Fasten items being carried as securely
as possible (
page 266).

Always navigate gradients with the en-
gine on and with the transmission en-
gaged in a gear. Switch on the DSR
(
page 250) to help maintain a preset
speed.
!Observe the following during off-road
driving:

Keep doors, tailgate, windows, and
tilt/sliding sunroof closed whenever driving
off-road.

Adjust vehicle speed to condition of terrain.
The more uneven, rutty and steeper the ter-
rain, the lower the speed should be. Drive
through water slowly at an even speed,
avoiding a bow wave.

Be especially careful when driving in un-
known territory. It may be necessary to get
out of the vehicle and scout the path you in-
tend to take.

Watch out for obstacles, such as rocks,
holes, tree stumps and ruts.

Before driving through water, determine its
depth.

Do not stop vehicle while immersed in water,
and do not shut off the engine.

In sandy soil, drive at a steady speed as al-
lowed by conditions. This helps overcome
the vehicle rolling resistance and reduces
the likelihood of the vehicle sinking into the
ground.

Do not initiate jumps with the vehicle. It
interrupts the forward momentum of the
vehicle.

Always drive onto slopes with the engine
running and the vehicle in gear.

Do not shift automatic transmission to
positionN.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 359) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.

322 Operation
Driving instructions
Checklist before off-road driving
Engine oil level

Check the engine oil level with the oil
dipstick (
page 343).
Only with a proper oil level can the
vehicle obtain a trouble-free oil supply,
even on steep gradients.Tires

Check the tread depth and maintain
specified tire inflation pressure
(a placard with the recommended tire
inflation pressures is located on the
driver’s door B-pillar (
page 352)).

Check tires for possible damage and
remove foreign objects.

Replace missing valve caps.
Rims

Dented or bent rims can cause tire in-
flation pressure loss and damage the
tire beads. For this reason, check and,
if necessary, change rims before driv-
ing off-road.
Vehicle tool kit

Check if the vehicle jack (page 450)
is functional.

In all cases take the vehicle tool kit, a
strong tow rope, a shovel and a small
plank (to put under the vehicle jack on
sandy soil) with you.Driving in steep terrain
Slope angle
1 Overhang angle, front
2Overhang angle, rear
!If the engine oil level warning lamp
(
page 434) comes on while driving, stop the
vehicle in a safe location or as soon at is safe to
do so. Check the engine oil level (
page 343).
The engine oil level warnings should not be
ignored. Extended driving with the symbol
displayed could result in serious engine damage
that is not covered by the Mercedes-Benz
Limited Warranty.
Vehicles with
steel suspen-
sion111
1Vehicles with AMG Sport-Package*
2
31°22°29°

323 Operation
Driving instructions

Comply with the warnings
(
page 319) and rules for off-road
driving (
page 321).

Driving on embankments, slopes and
other steep inclines should only be
done straight up or downhill, i.e. in the
line of gravity. Maximum vehicle climb-
ing ability is a 100% grade which is
equivalent to a slope angle of
45 degrees. Keep in mind that the
climbing ability of the vehicle depends
on terrain conditions.

Shift automatic transmission to
position1 (
page 192).

Drive slowly.

Avoid excessive engine speeds – drive
with moderate engine speeds
(max. 3 000 rpm).

Utilize the engine’s braking power
when descending a slope, observe the
engine speed (do not overrev the en-
gine). Apply the service brake as need-
ed.

Check the brakes after a lengthy down-
grade drive.Traction in steep terrain
The maximum vehicle climbing ability is a
100% grade which is equivalent to a slope
angle of 45 degrees. Keep in mind that the
climbing ability of the vehicle depends on
terrain conditions.
Be easy on the accelerator and watch for
continuous wheel traction when driving in
steep terrain.
Vehicles with air
suspension pro-
gram*111
1Vehicles with AMG Sport-Package*
2
Raised level34°29°31°
Highway29°22°27°
ML 63 AMG12
Raised level28°29°
Highway23°24°
iFor maximum engine speed, see “Instru-
ment cluster” (
page 26) and see “Engine”
(
page 513).
Warning!G
Never turn the vehicle around on steep
inclines. The vehicle might roll over. If the
vehicle cannot complete the attempted
climb, back it down in reverse gear.
iThe hill start assist system supports you
when driving uphill.
For more information, see “Hill start assist sys-
tem” (
page 191).
iThe 4-ETS helps greatly when starting out on
a steep incline when the front wheels have then
the tendency to slip due to the weight shifting
towards the rear axle.
The 4-ETS recognizes the situation and limits the
torque for the front wheels by braking them.
Simultaneously the torque for the rear wheels is
increased.

324 Operation
Driving instructions
Driving across a hilltop
Decelerate just ahead of a hilltop (do not
shift automatic transmission to
positionN), to prevent the vehicle from
speeding up too much after climbing a hill.
Use the momentum of the vehicle to drive
across the hilltop.
After climbing a hill, driving in this manner
prevents the vehicle from:

losing ground contact when cresting
hills

losing its forward momentum

speeding up too much after climbing
the hill
Driving downhill

Drive slowly.

Do not drive at an angle to the incline.
Steer into the line of gravity and drive
with the front wheels pointing straight
downhill. Otherwise, the vehicle may
slide sideways off the path and roll
over.

Shift automatic transmission to
position1 (
page 192).

On steep inclines, use the Downhill
Speed Regulation (
page 249).

Utilize the engine’s braking power to
reduce vehicle speed.
If this is insufficient, apply the brakes
gently. Make sure the vehicle is moving
in the line of gravity.

Check the brakes after a lengthy down-
grade drive.Driving through water
1Fording depth
iThe special Off-road – ABS (page 99) set-
ting allows for precise and brief (cyclical) block-
ing of the front wheels, permitting them to dig
into loose ground.
Remember that, when stopped, the front wheels
slide across a surface and thus lose their ability
to steer the vehicle.Vehicles with steel
suspension1
20.00 in (50 cm)
Vehicles with air
suspension
program* or
ML 63 AMG1
Raised level20.00 in (50 cm)

325 Operation
Driving instructions

Before driving through water, deter-
mine its depth.

Vehicles with air suspension program*:
Select the highest vehicle level
possible (
page 255).

Switch to off-road driving program
(
page 253) before driving through
water.

Shift automatic transmission to
position1 or2 (
page 192).

Avoid high engine speeds.

Enter and leave the water only at a
shallow spot, driving at walking speed.

Drive through the water slowly and at a
constant speed.

Do not stop vehicle while immersed in
water, and do not shut off the engine.

There is a very high level of driving re-
sistance in water. The surface is slip-
pery and may not be firm, making
pulling away in water difficult and dan-
gerous.

Make sure that only small bow waves
are formed when driving the vehicle
through water.

Clean mud off the tire tread after driv-
ing through water.

To dry the brakes, apply pressure to the
brake pedal several times while driving
after leaving the water.Crossing obstacles
!The water depth must not exceed the
respective value listed in the table. The ground
under the water might not be firm which could
result the water being deeper than expected
when driving the vehicle through it. Please note
that the water level is correspondingly lower for
flowing water.
!Never accelerate before driving into the
water. The bow wave could force water into the
engine and auxiliary equipment, thus damaging
them.
!Do not open any of the vehicle’s doors while
driving through water. Water could otherwise en-
ter the vehicle interior and damage the vehicle’s
electronics, as well as the interior equipment.
!Obstacles can damage the vehicle
underbody or suspension components. If possi-
ble use the assistance of a second person out-
side the vehicle to scout the path you intend to
take and check for adequate ground clearance
when you cross obstacles with your vehicle. The
person assisting you outside the vehicle should
always be a safe distance away from the vehicle
and positioned so that he or she cannot get hurt
in case of any unexpected vehicle movement.
After off-road driving or crossing obstacles, in-
spect vehicle for any damage, especially vehicle
underbody and suspension components. Failure
to do so can adversely affect the vehicle’s future
performance, including increased chance of an
accident.

326 Operation
Driving instructions
When driving over tree stumps, big rocks
and other obstacles, observe the following
rules:

Make sure the off-road driving program
(
page 253) is switched on.

Avoid high engine speeds.

Shift automatic transmission to
position1 (
page 192).

Check the vehicle clearance before
crossing obstacles.

Cross obstacles (e.g. tree stumps or
big rocks) very slowly by aiming one of
the front wheels at the center of the ob-
stacle, and repeat same with the rear
wheel.Driving on sand
When driving on sand, observe the follow-
ing rules:

Vehicles with air suspension program*:
Set the raised level (
page 255).

Avoid high engine speeds.

Shift automatic transmission into a
gear range that is appropriate for the
terrain.

In sandy soil, drive at a steady speed as
conditions permit. This helps overcome
the vehicle rolling resistance and re-
duce the likelihood of the vehicle sink-
ing into the ground.

Drive in tracks of other vehicles if they
are not too deep and you have suffi-
cient clearance.
Ruts
A number of off-road tracks or other by-
ways have deep ruts which can cause the
underbody to come in contact with the
ground.

Make sure the off-road driving program
(
page 253) is switched on.

Vehicles with air suspension program*:
Set the raised level (
page 255).
!Special attention is needed when you cross
obstacles on a steep incline.
The vehicle could slide sideways as a result of its
possible slanted position which in turn may
result in the vehicle tipping or rolling over.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 359) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.

327 Operation
Driving instructions

Avoid high engine speeds.

Shift automatic transmission to
position1 (
page 192).

Drive next to the ruts rather than
through them if at all possible.

If the ruts are too deep to drive in, drive
with one side of the vehicle on the
grassy center strip if the route permits.Returning from off-road drivingOff-road driving increases strain on the
vehicle.
We recommend that you inspect the vehi-
cle for possible damage after each off-road
trip. Recognizing any damage and a subse-
quent timely repair reduces the chance of
a possible breakdown or accident later on.
Proceed as follows:

Switch off the off-road driving program
(
page 253).

Switch off the DSR (page 250).

Vehicles with air suspension program*:
Lower the vehicle back to a level
suitable for road conditions, e.g. High-
way/High-speed level (
page 255).

Clean all exterior lamps and check for
possible damage.

Clean the front and rear license plate.
!Check that the ruts are not too deep and
your vehicle’s clearance is sufficient. Otherwise:

your vehicle may be damaged

the underbody of the vehicle may come in
contact with the ground and you may get
stuck
Warning!G
If you feel a sudden significant vibration or
ride disturbance, or you suspect that possi-
ble damage to your vehicle has occurred,
you should turn on the hazard warning flash-
ers, carefully slow down, and drive with cau-
tion to an area which is a safe distance from
the roadway.
Inspect the tires and under the vehicle for
possible damage. If the vehicle or tires ap-
pear unsafe, have it towed to the nearest
Mercedes-Benz Light Truck Center or tire
dealer for repairs.
Damage to the vehicle may influence driving
comfort and pose the risk of accident to you
and other drivers.
