2008 MERCEDES-BENZ ML63AMG Owner's Manual

176 Controls in detail
Control system
Limiting opening height of tailgate*
Use this function to activate or deactivate
the limiting opening height of the tailgate.
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Opening Limiter
Tailgate
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the limiting opening height of the
tailgate
On or Off.Comfort submenu*
Access the
Comfort submenu via the
Settings menu. Use the Comfort submenu
to change the settings for a number of con-
venience features.
The following functions are available:Activating easy-entry/exit feature*
Use this function to activate and
deactivate the easy-entry/exit feature
(
page 46).
FunctionPage
Activating easy-entry/exit
feature*176
Setting fold-in function* for
exterior rear view mirrors177
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:

Move steering wheel adjustment stalk*
(
page 48).

Press one of the stored position
buttons* or the memory buttonM*
(
page 133).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

177 Controls in detail
Control system
Move the selection marker with
buttonæ orç to the
Comfort
submenu.
Press buttonj ork repeatedly
until the message
Easy-entry Function appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the easy-entry/exit feature
On or Off.Setting fold-in function* for exterior
rear view mirrors
Using this function, you can set the
exterior rear view mirrors to be automati-
cally folded in when you lock your vehicle.
Move the selection marker with
buttonæ orç to the
Comfort
submenu.
Press buttonj ork repeatedly
until the message
Fold In Mirrors
When Locking
appears in the multi-
function display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
function
On or Off.
Vehicle configuration
The following functions are available:
iWith this function set to On and the exterior
rear view mirrors folded in using the button on
the door control panel (
page 200), the exterior
rear view mirrors will not fold out when you
switch on the ignition. You will then have to fold
out the exterior rear view mirrors using the
button on the door control panel (
page 200).
Make sure both exterior rear view mirrors are
folded out completely before driving off.
FunctionPage
DSR set speed178

178 Controls in detail
Control system
DSR (Downhill Speed Regulation)
programmed default speed
In the
DSR menu, you can program the
default speed the DSR is set to when it is
activated.
You can program the default speed be-
tween 4 - 10 mph (Canada: 6 - 18 km/h).
The set value is increased in 1 mph
(Canada: 2 km/h) increments.
Press buttonè orÿ repeatedly
until the message
DSR Speed appears
in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç repeatedly
until the desired speed is shown in the
multifunction display.
When DSR is switched on, DSR will use
the programmed default speed to regu-
late the vehicle’s speed.Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:
iOnce DSR is switched on, you can adjust the
set speed using the cruise control lever
(
page 251).
FunctionPage
Fuel consumption statistics
since start179
Fuel consumption statistics
since last reset179
Resetting fuel consumption
statistics179
Distance to empty180
iWhen you enter the trip computer menu, you
will always see the fuel consumption statistics
since start first.

179 Controls in detail
Control system
Fuel consumption statistics since start
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since startFuel consumption statistics since last
resetPress buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the message
From Reset appears
in the multifunction display.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last
resetResetting fuel consumption statistics
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the fuel consumption statistics
which you want to reset appear in the
multifunction display.
Press and hold the reset button in the
instrument cluster (
page 145) until
the respective values are reset to
0.
iAll statistics stored since the last engine
start will be reset approximately 4 hours after
the SmartKey in the starter switch is turned to
position0 or removed from the starter switch.
Resetting will not occur if you turn the SmartKey
back to position1 or2 within this time period.
iThe fuel consumption statistics reset auto-
matically to 0 when either of the following values
is exceeded:

distance covered: 100 000 miles

time elapsed: 10 000 hours

180 Controls in detail
Control system
Distance to empty
Press buttonÿ orè repeatedly
until the message
From Start appears
in the multifunction display.
Press buttonj ork repeatedly
until the message
Range: appears in
the multifunction display.
The calculated remaining driving range
based on the current fuel tank level
appears in the multifunction display.
TEL* menu
You can use the functions in the
TEL menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.
Switch on the telephone and COMAND
system.
Press buttonÿ orè on the
multifunction steering wheel repeated-
ly until the message
TEL appears in the
multifunction display.
iIf only very little fuel is left in the tank, a
vehicle at the fuel pump is shown instead of the
range.
Warning!G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic condi-
tions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

181 Controls in detail
Control system
Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:

If the telephone is off, the message
TEL Off appears in the multifunction
display.

If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network, the message
Ready appears in
the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the message, or if available, the caller ID
(name and number):Press buttons.
You have answered the call. The
duration of the call appears in the
multifunction display.
Ending a call or rejecting an incoming
call
Press buttont.Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.
Press buttonÿ orè repeatedly
until the message
TEL appears in the
multifunction display.
Press buttonj ork.
The control system reads the phone
book which is stored in the telephone.
This may take several minutes. The
message
Please Wait appears in the
multifunction display.
When the message
Please Wait
disappears, the phone book has been
loaded.
Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in
ascending or descending alphabetical
order.


182 Controls in detail
Control system
1Name from the phone book
Press buttons.
The system dials the selected phone
number.

If the connection is successful and
this feature is supported by your
network provider, the name of the
party (if stored in your phone book)
you are calling and the duration of
the call will appear in the multifunc-
tion display.

If no connection is made, the
control system stores the dialed
number in the redial memory.Redialing
The control system stores the most
recently dialed phone numbers. This
eliminates the need to search through your
entire phone book.Press buttonÿ orè repeatedly
until the message
TEL appears in the
multifunction display.
Press buttons.
The first number in the redial memory
appears in the multifunction display.
Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
Press buttons.
The control system dials the selected
phone number.
iIf you press and hold buttonj ork
for longer than 1 second, the system scrolls
rapidly through the list of names until you
release the button again.
Cancel the quick search mode by pressing
buttont.


183 Controls in detail
Automatic transmission
Automatic transmission
For more information on driving with an
automatic transmission, see “Automatic
transmission” (
page 54).
Your vehicle’s transmission adapts its gear
shifting process to your individual driving
style by continually adjusting the shift
points up or down. These shift point adjust-
ments are performed based on current
operating and driving conditions.
If the operating conditions change, the
automatic transmission reacts by
adjusting its shift program.
Gear selector lever
The gear selector lever is located on the
right of the steering column.
Gearshift pattern for automatic
transmission
PPark position
RReverse gear
NNeutral
DDrive position
iDuring the brief warm-up, transmission
upshifting is delayed. This allows the catalytic
converter (gasoline engine) or the oxidation
catalyst (diesel engine) to heat up more quickly
to operating temperature.
Warning!G
Make sure that absolutely no objects are
obstructing the pedal’s range of movement.
Keep the driver’s footwell clear of all obsta-
cles. If there are any floormats or carpets in
the footwell, make sure that the pedals still
have sufficient clearance.
During sudden driving or braking maneuvers
the objects could get caught between the
pedals. You could then no longer brake or
accelerate. This could lead to accidents and
injury.
