2007 VOLVO XC90 Owners Manual

2007 Volvo XC90
at which the airbag deploys is determined by whether or not the seat bel\
t is being used, as well as the
severity of the collision.
l Collisions can occur where only one of the airbags deploys. If the impac\
t is less severe, but severe
enough to present a clear injury risk, the dual-stage airbags are trigge\
red at 70-80% of their total
capacity. If the impact is more severe, the dual-stage airbags are trigg\
ered at full capacity.
Should you have questions about any component in the SRS system, please \
contact a trained and
qualified Volvo service technician or Volvo Customer Support:
In the USA:
Volvo Cars of North America, LLC
Customer Care Center
P.O. Box 914
Rockleigh, New Jersey 07647-0914
1-800-458-1552
www.volvocars.us
In Canada:
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
www.volvocanada.com
pg. 18 Safety
Front airbags
WARNING!
l Do not use child safety seats or child booster cushions/backrests in the\
front passenger's seat. We
also recommend that occupants under 4 feet 7 inches (140 cm) in height\
who have outgrown these
devices sit in the rear seat with the seat belt fastened
1.
l Never drive with the airbags deployed. The fact that they hang out can i\
mpair the steering of your
vehicle. Other safety systems can also be damaged.
l The smoke and dust formed when the airbags are deployed can cause skin a\
nd eye irritation in the
event of prolonged exposure.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (10 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90

1. See also the Occupant Weight Sensor information on page 20.
pg. 19 Safety
Front airbags
WARNING!
l Children must never be allowed in the front passenger's seat. Volvo reco\
mmends that ALL
occupants (adults and children) shorter than 4 feet 7 inches (140 cm)\
be seated in the back seat of any
vehicle with a passenger-side front airbag. See
page 30 for guidelines.
l Occupants in the front passenger's seat must never sit on the edge of th\
e seat, sit leaning toward the
instrument panel or otherwise sit out of position.
l The occupant's back must be as upright as comfort allows and be against \
the seat back with the seat
belt properly fastened.
l Feet must be on the floor, e.g., not on the dash, seat or out of the win\
dow.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (11 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
WARNING!
l No objects or accessory equipment, e.g. dashboard covers, may be placed \
on, attached to, or
installed near the air bag hatch (the area above the glove compartment)\
or the area affected by airbag
deployment (see the illustration on
page 16).
l There should be no loose articles, e.g. coffee cups, on the floor, seat,\
or dashboard area.
l Never try to open the airbag cover on the steering wheel or the passenge\
r's side dashboard. This
should only be done by a trained and qualified Volvo service technician.\
Failure to follow these instructions can result in injury to the vehicle\
occupants.
pg. 20 Safety
Occupant Weight Sensor (OWS)
Disabling the passenger's side front airbag
Volvo recommends that ALL occupants (adults and children) shorter than\
4 feet 7 inches (140 cm) be
seated in the rear seat of any vehicle with a passenger's side front air\
bag, and be properly restrained.
Children should always be seated in child restraints appropriate for the\
ir size and weight. See also the
child safety recommendations beginning on
page 31.
The Occupant Weight Sensor (OWS) is designed to meet the regulatory re\
quirements of Federal Motor
Vehicle Safety Standard (FMVSS) 208 and is designed to disable (will \
not inflate) the passenger's side
front airbag under certain conditions. The OWS works with sensors that a\
re part of the front passenger's
seat and seat belt. The sensors are designed to detect the presence of a\
properly seated occupant and
determine if the passenger's side front airbag should be enabled (may i\
nflate) or disabled (will not
inflate).
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (12 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
The OWS will disable (will not inflate) the passenger's side front air\
bag when:
l the front passenger's seat is unoccupied, or has small/medium objects in\
the front seat,
l the system determines that an infant is present in a rear-facing infant \
seat that is installed according to
the manufacturer's instructions,
l the system determines that a small child is present in a forward-facing \
child restraint that is installed
according to the manufacturer's instructions,
l the system determines that a small child is present in a booster seat,
l a front passenger takes his/her weight off of the seat for a period of t\
ime,
l a child or a small person occupies the front passenger's seat. The OWS u\
ses a PASSENGER
AIRBAG OFF indicator lamp which will illuminate and stay on to remind yo\
u that the passenger's side
front airbag is disabled. The PASSENGER AIRBAG OFF indicator lamp is loc\
ated in the overhead
console, near the base of the rearview mirror.
NOTE: The PASSENGER AIRBAG OFF indicator lamp will illuminate for a short per\
iod of time when
the ignition is turned on to confirm it is functional. When the front pa\
ssenger's seat is not occupied
(empty seat) or in the event that the passenger's side front airbag is\
enabled (may inflate), the
PASSENGER AIRBAG OFF indicator lamp will be off.
However, if a fault is detected in the system:
l The OWS indicator light will stay on.
l The SRS warning light (see page 15) will come on and stay on.
l The message PASS. AIRBAG OFF SERVICE URGENT will be displayed in the inf\
ormation display.
pg. 21 Safety
Occupant Weight Sensor (OWS)
WARNING!
If a fault in the system is detected and indicated as explained on the p\
revious page, be aware that the
passenger's side front airbag will not deploy in the event of a collisio\
n.
In this case, the safety systems and Occupant Weight Sensor should be in\
spected by an authorized
Volvo retailer as soon as possible.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (13 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
WARNING!
l Never try to open, remove, or repair any components in the OWS system. T\
his could result in
system malfunction. Maintenance or repairs should only be carried out by\
an authorized Volvo
service technician.
l The front passenger's seat should not be modified in any way. This could\
reduce pressure on the
seat cushion, which might interfere with the OWS system's function.
The OWS is designed to disable (will not inflate) the passenger's side\
front airbag when a rear facing
infant seat, a forward-facing child restraint, or a booster seat is dete\
cted. The PASSENGER AIRBAG
OFF indicator lamp will illuminate and stay on to remind you that the pa\
ssenger's side front airbag is
disabled (see the following table).
1. Volvo recommends that children always be properly restrained in appro\
priate child restraints in the rear seats.
In rare situations when the seat belt is not properly fastened, some chi\
ld restraints may not be detected by the
OWS because there is very little weight on the vehicle seat cushion. In \
these cases the passenger's side front
airbag may be disabled, but the PASSENGER AIRBAG OFF indicator lamp will\
not be lit. Do not assume that
the passenger's side front airbag is disabled unless the PASSENGER AIRBA\
G OFF indicator lamp is lit. Make
sure the child restraint is properly installed (turn the vehicle off, r\
emove the child restraint from the vehicle and
reinstall the restraint following the child restraint manufacturer's ins\
tructions) and that the PASSENGER
AIRBAG OFF indicator lamp is on, or move the child restraint to the rear\
seat.
The OWS is designed to enable (may inflate) the passenger's side front\
airbag anytime the system senses
that a person of adult size is sitting properly in the front passenger's\
seat. The PASSENGER AIRBAG
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (14 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
OFF indicator lamp will be off and remain off.
If a person of adult size is sitting in the front passenger's seat, but \
the PASSENGER AIRBAG OFF
indicator lamp is on, it is possible that the person isn't sitting prope\
rly in the seat. If this happens:
l Turn the vehicle off and ask the person to place the seat back in an upr\
ight position.
pg. 22 Safety
Occupant Weight Sensor (OWS)
l Have the person sit upright in the seat, centered on the seat cushion, w\
ith the person's legs
comfortably extended.
l Restart the vehicle and have the person remain in this position for abou\
t two minutes. This will allow
the system to detect that person and enable the passenger's frontal airb\
ag.
l If the PASSENGER AIRBAG OFF indicator lamp remains on even after this, t\
he person should be
advised to ride in the rear seat.
This condition reflects limitations of the OWS classification capability\
. It does not indicate OWS
malfunction.
Modifications
If you are considering modifying your vehicle in any way to accommodate \
a disability, for example by
altering or adapting the driver's or front passenger's seat(s) and/or \
airbag systems, please contact Volvo
at:
In the USA:
Volvo Cars of North America, LLC
Customer Care Center
P.O. Box 914
Rockleigh, New Jersey 07647-0914
1-800-458-1552
In Canada:
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (15 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
WARNING!
l No objects that add to the total weight on the seat should be placed on \
the front passenger's seat. If
a child is seated in the front passenger's seat with any additional weig\
ht, this extra weight could cause
the OWS system to enable the airbag, which might cause it to deploy in t\
he event of a collision,
thereby injuring the child.
l The seat belt should never be wrapped around an object on the front pass\
enger's seat. This could
interfere with the OWS system's function.
l The front passenger's seat belt should never be used in a way that exert\
s more pressure on the
passenger than normal. This could increase the pressure exerted on the w\
eight sensor by a child, and
could result in the airbag being enabled, which might cause it to deploy\
in the event of a collision,
thereby injuring the child.
pg. 23 Safety
Occupant Weight Sensor (OWS)
WARNING!
Keep the following points in mind with respect to the OWS system. Failur\
e to follow these
instructions could adversely affect the system's function and result in \
serious injury to the occupant of
the front passenger's seat:
l The full weight of the front seat passenger should always be on the seat\
cushion. The passenger
should never lift him/herself off the seat cushion using the armrest in \
the door or the center console,
by pressing the feet on the floor, by sitting on the edge of the seat cu\
shion, or by pressing against the
backrest in a way that reduces pressure on the seat cushion. This could \
cause OWS to disable the
front passenger's side airbag.
l Do not place any type of object on the front passenger's seat in such a \
way that jamming, pressing,
or squeezing occurs between the object and the front seat, other than as\
a direct result of the correct
use of the ALR/ELR seat belt (see
page 30).
l No objects should be placed under the front passenger's seat. This could\
interfere with the OWS
system's function.
pg. 24 Safety
Side impact (SIPS) airbag
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (16 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
Side impact airbags - front seats only
As an enhancement to the structural side impact protection built into yo\
ur vehicle, the vehicle is also
equipped with Side Impact Protection System (SIPS) airbags.
The SIPS airbag system is designed to help increase occupant protection \
in the event of certain side
impact collisions. The SIPS airbags are designed to deploy only during c\
ertain side-impact collisions,
depending on the crash severity, angle, speed and point of impact.
NOTE: SIPS airbag deployment (one airbag) occurs only on the side of the ve\
hicle affected by the
impact. The airbags are not designed to deploy in all side impact situat\
ions.
Components in the SIPS airbag system
This SIPS airbag system consists of gas generators and side airbag modul\
es built into the outboard sides
of both front seat backrests.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (17 of 39)12/30/200\
6 5:53:33 PM
