2007 VOLVO XC90 Owners Manual

2007 Volvo XC90
18. -
19. Engine control module feed, engine relay 5
20. Parking lights 15
21. -
pg. 203 Maintenance
Fuses
Fuses in the passenger compartment
Fuses are located inside the access panel on the edge of the dashboard, \
on the driver's side. There are
also a number of spare fuses. When replacing a blown fuse, be sure to re\
place it with a new one of the
same color and amperage (written on the fuse).
No. Amperage
1. Blower - climate system 30
2. Audio amplifier 30
3. Power driver's seat (option) 25
4. Power passenger's seat (option) 25
5. Driver's door - central locking, power windows, door mirror 25
6. Front passenger's door - central locking, power windows, door mirror \
25
7. -
8. Radio, CD player, Rear Seat Entertainment (RSE) 15
9. Volvo Navigation System (option), Sirius satellite radio (option)\
10
10. On-board diagnostics, headlight switch, steering wheel angle sensor,\
steering wheel
module 5
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (31 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
11. Ignition switch, SRS, engine control module (V8, 6-cyl.) immobiliz\
er, transmission
control module (V8, 6-cyl.)7.5
12. Ceiling lighting, upper electronic control module 10
13. Moonroof (option) 15
14. -
15. -
16. -
17. -
18. -
19. -
20. -
21. -
22. -
23. -
24. -
25. -
26. -
27. -
28. -
29. -
30. -
31. -
32. -
33. -
34. -
35. -
36. -
37. -
38. -
pg. 204 Maintenance
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (32 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
Fuses
Fuse box in the passenger compartment, behind the plastic cover, driver'\
s side
This fuse box is located behind the plastic cover below the steering whe\
el. When replacing a blown fuse,
be sure to replace it with a new one of the same color and amperage (wr\
itten on the fuse). No. Amperage
1. Heated passenger's seat 15
2. Heated driver's seat 15
3. Horn 15
4. -
5. Audio system 10
6. -
7. -
8. Alarm siren 5
9. Brake light switch feed 5
10. Instrument panel, climate system, power driver's seat, Occupant Weig\
ht Sensor 10
11. 12-volt sockets - front and rear seats 15
12. -
13. -
14. -
15. ABS, STC/DSTC 5
16. Power steering, Active Bi-Xenon headlights (option) 10
17. Driver's side front foglight (option) 7.5
18. Passenger's side front foglight (option) 7.5
19. -
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (33 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
20. Coolant pump (V8)5
21. Transmission control module 10
22. Driver's side high beam 10
23. Passenger's side high beam 10
24. -
25. -
26. -
27. -
28. Power passenger's seat (option) 5
29. -
30. -
31. -
32. -
33. Vacuum pump 20
34. Pump - windshield and tailgate washers 15
35. -
36. -
pg. 205 Maintenance
Fuses
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (34 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
Fuses in the cargo compartment
The fuses in the cargo area are located behind the panel on the driver's\
side of the cargo compartment.
When replacing a blown fuse, be sure to replace it with a new one of the\
same color and amperage
(written on the fuse). No. Amperage
1. Backup lights 10
2. Parking lights, foglights, cargo compartment lighting, license plate \
lights, brake light
diodes 20
3. Accessories 15
4. -
5. Rear Electronic module 10
6. Rear Seat Entertainment (accessory) 7.5
7. Trailer wiring (30-feed) 15
8. 12-volt socket in cargo compartment 15
9. Rear passenger's side door - power window, power window cutout functi\
on 20
10. Rear driver's side door - power window, power window cutout function\
20
11. -
12. -
13. -
14. Subwoofer (option), rear air conditioning system (option) 15
15. -
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (35 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
16. -
17. Accessory audio 5
18. -
19. Rear window wiper 15
20. Trailer wiring (15-feed) 20
21. -
22. -
23. All Wheel Drive 7.5
24. -
25. -
26. Park assist 5
27. Main fuse: trailer wiring, park assist, All Wheel Drive 30
28. Central locking system 15
29. Driver's side trailer lighting: parking lights, turn signal 25
30. Passenger's side trailer lighting: brake light, fog light, turn sign\
al 25
pg. 206 Maintenance
Fuses
No.Amperage
31. Main fuse: fuses 37 and 38 40
32. -
33. -
34. -
35. -
36. -
37. Heated rear window 20
38. Heated rear window 20


file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (36 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90

Contents | Top of Page
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (37 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
2 0 0 7
VOLVO XC90
Specifications

pg. 207 Specifications
Label information
208
Weights
209
Dimensions
210
Bulbs
211
Engine oil
212
Fluid specifications and
capacities
213
Suspension
213
Three-way catalytic converter
215
Electrical system
216
Engine specifications
217
Volvo programs
218
All specifications are subject to change without prior notice.
