2007 VOLVO XC90 Owners Manual

2007 Volvo XC90
1. Model plate
Vehicle Identification Number (VIN). Codes for color and upholstery, e\
tc.
2. Child safety lock labels
1
3. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA\
) and Ministry of
Transport (CMVSS) standards (Canada)
Your Volvo is designed to meet all applicable safety standards, as evide\
nced by the certification label on
the facing side of the driver's door. For further information regarding \
these regulations, please consult
your Volvo retailer.
4. Loads and Tire Pressures
The appearance of the decal will vary, depending on the market for which\
the vehicle is intended.
l Canadian models: upper decal
l U.S. models: lower decal
5. Vehicle Identification Number (VIN)
The VIN plate is located on the top left surface of the dashboard. The V\
IN is also stamped on the right
hand door pillar. The Vehicle Identification Number (VIN) should alway\
s be quoted in all
correspondence concerning your vehicle with the retailer and when orderi\
ng parts.
6. Vehicle Emission Control Information/ Vacuum hose routing
Your Volvo is designed to meet all applicable emission standards, as evi\
denced by the certification label
on the underside of the hood. For further information regarding these re\
gulations, please consult your
Volvo retailer.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (2 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
1. Not on vehicles equipped with the optional power child safety locks. \
pg. 209 Specifications
Weights
Gross vehicle weight1 USA
Canada
5-seat, 6-cyl, FWD 5750
lbs -
5-seat, 6-cyl, AWD 5900
lbs 2680 kg
5-seat, 8-cyl, AWD 5900
lbs 2680 kg
7-seat, 6-cyl, FWD 5915
lbs -
7-seat, 6-cyl, AWD 6080
lbs 2760 kg
7-seat, 8-cyl, AWD 6100
lbs 2770 kg
Capacity weight
5-seat models 1160
lbs 525 kg
7-seat models 1210
lbs 550 kg
Permissible axle weight,
front*
5-seat, 6-cyl, FWD 770 lbs -
5-seat, 6-cyl, AWD 2880
lbs 1310 kg
5-seat, 8-cyl, AWD 2930
lbs 1330 kg
7-seat, 6-cyl, FWD 2770
lbs -
7-seat, 6-cyl, AWD 2880
lbs 1310 kg
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (3 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
7-seat, 8-cyl, AWD 2930
lbs 1330 kg
1. Permissible axle weight or gross vehicle weight must never be exceede\
d.
Permissible axle weight,
rear
1 USA
Canada
5-seat, 6-cyl, FWD 3060 lbs -
5-seat, 6-cyl, AWD 3150 lbs 1430 kg
5-seat, 8-cyl, AWD 3150 lbs 1430 kg
7-seat, 6-cyl, FWD 3170 lbs -
7-seat, 6-cyl, AWD 3240 lbs 1470 kg
7-seat, 8-cyl, AWD 3240 lbs 1470 kg
Curb weight
5-seat, FWD 4290-4400
lbs -
5-seat, AWD 4420-4655
lbs 2020-2130 kg
7-seat, FWD 4475-4570
lbs -
7-seat, AWD 4605-4820
lbs 2110-2160 kg
Max. roof load 220 lbs 100 kg
Trailer weight, w/o brakes 1650 lbs 750 kg
Trailer weights, with brakes See the table on
page 137
Max. tongue weight See the table on
page 137
WARNING!
When adding accessories, equipment, luggage and other cargo to your vehi\
cle, the total capacity
weight must not be exceeded.
pg. 210 Specifications
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (4 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
Dimensions
Length188.9 in (479.8 cm)
Width 74.7 in (189.8 cm)
Height 70.2 in (178.4 cm)
Wheelbase 112.6 in (285.7 cm)
Front track 64.3 in (163.4 cm)
Rear track 63.9 (162.4 cm)
Turning
circle 39-40 ft. (11.9-12.3
m)
Cargo capacity
With optional 3rd row of seats folded down:
5-seat: 41.6 cu. ft (1178 liters)
7-seat: 43.3 cu. ft (1225 liters)
Behind 1st row of seats, with 2nd (and optional 3rd) row of seats fold\
ed down:
5-seat: 84.9 cu. ft (2403 liters)
7-seat: 85.1 cu. ft (2410 liters)
Behind 1st row of seats, with front passenger seat, 2nd row (and option\
al 3rd row) of seats folded down:
5-seat: 92.0 cu. ft (2606 liters)
7-seat: 93.2 cu. ft (2640 liters)
pg. 211 Specifications
Bulbs
High beam H7 65W-
Low beam H11
55W -
Active Bi-Xenon low beam (option) D1S 35W
Active Bi-Xenon high beam (option) H9 65W
Front fog lights H1 55W
Front/rear parking lights, front/rear side marker lights license plate l\
ight, rear
footwell lighting W5W
W2,1x9,5d
Front turn signals H21W BAY9s
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (5 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
Rear fog lightP21/4W BAY9s
Brake lights, backup lights P21W BA15s
Rear turn signals PY21W BA15s
10. Vanity mirror lighting 1.2W SV5.5
11. Front footwell lighting, cargo area lighting C5W SV8.5
WARNING!
Active Bi-Xenon headlights (option) - due to the high voltage used by \
these headlights, these bulbs
should only be replaced by an authorized Volvo service technician.
pg. 212 Specifications
Engine oil
Specifications
Engine oil must meet the minimum ILSAC specification GF-3, API SL, and A\
CEA A1/ B1. Lower
quality oils may not offer the same fuel economy, engine performance, or\
engine protection.
Volvo recommends
.
Volume
Engine designation Volume between
MIN-MAX on dipstick Volume
1
3.2 6-cyl. B6324S
0.85 US qts (0.8 liters) 7.7 US qts (7.3 liters)
V8 AWD B8444S 1.3 US qts (1.2 liters) 7.1 US qts. (6.7
liters)
1. Including filter replacement
pg. 213 Specifications
Fluid specifications and capacities
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (6 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
Fuel tank 21.1 US gals. (80 liters) Minimum octane requirement - AKI 87 (RON
91) - unleaded fuel (See also page 117)
Transmission oil
1
TF-80SC 7.4 US qts. (7.0 liters)
Miscellaneous
Power steering 1.1 US qts. (1.0 liters)
Windshield washer
reservoir 6.9 US qts. (6.5 liters)
Brake fluid 0.63 US qts. (0.6 liters)
Air conditioning system Front - 2.2 lb. (1 kg), Rear (option) 2.9 lb. (1.3 kg) R 134a (HF\
C134a)
Coolant Volvo original coolant/antifreeze (Thermostat begins to open at 194°\
F
(90° C)).
3.2 6-cyl. 7.9 US qts. (7.5 liters)
V8 10.7 US qts. (10.2 liters)
1. The transmission oil does not normally need to be changed during the \
service life of the vehicle. However, it
may be necessary to replace the oil if the vehicle is often driven in ar\
eas of sustained temperature extremes (hot
or cold), when towing a trailer over long distances, for prolonged driv\
ing in mountainous areas, or if the vehicle
is often driven short distances in temperatures under 40°F (5°C)\
.
Transmission
Oil grade:
Type: JWS 3309
Different types of oil should never be mixed.
Power steering
Grade: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 o\
r equivalent.
Brake fluid
Fluid type: DOT 4+ boiling point >536° F (280° C), P/N 9437433
Rear suspension
Individual rear wheel suspension with longitudinal support arms, double \
link arms and track rods.
Front suspension
Spring strut suspension with integrated shock absorbers and control arms\
linked to
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (7 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
pg. 214 Specifications
Suspension
the support frame. Power-assisted rack and pinion steering. Safety type \
steering column.
pg. 215 Specifications
Three-way catalytic converter
Points to keep in mind
l Keep your engine properly tuned. Certain engine malfunctions, particular\
ly involving the electrical,
fuel or distributor ignition systems, may cause unusually high three-way\
catalytic converter
temperatures. Do not continue to operate your vehicle if you detect engi\
ne misfire, noticeable loss of
power or other unusual operating conditions, such as engine overheating \
or backfiring. A properly tuned
engine will help avoid malfunctions that could damage the three-way cata\
lytic converter.
l Do not park your vehicle over combustible materials, such as grass or le\
aves, which can come into
contact with the hot exhaust system and cause such materials to ignite u\
nder certain wind and weather
conditions.
l Excessive starter cranking (in excess of one minute), or an intermitte\
ntly firing or flooded engine can
cause three-way catalytic converter or exhaust system overheating.
l Remember that tampering or unauthorized modifications to the engine, the\
Electronic Control
Module, or the vehicle may be illegal and can cause three-way catalytic \
converter or exhaust system
overheating. This includes:
- Altering fuel injection setting or components.
- Altering emission system components or location or removing components\
.
- Repeated use of leaded fuel.
NOTE: Unleaded fuel is required for vehicles with three-way catalytic convert\
ers.
pg. 216 Specifications
Electrical system
12-volt system with voltage controlled generator. Single wire system in \
which the chassis and engine
block are used as conductors, grounded on the chassis.
Battery 3.2 6-cyl. V8
Voltage 12 V 12 V
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (8 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
Cold start capacity(CCA) 520 A 600 A
Reserve capacity (RC) 100 min 120 min
Capacity (Ah) 60 70
If you must replace your battery, be sure to replace it with a battery o\
f the same cold start capacity and
reserve capacity as the original (See the decal on the battery).
pg. 217 Specifications
Engine specifications
B6324S B8444S
Output(kW/rps) 175/103 232/100
(hp/rpm) 235/6200 311/6000
Torque(Nm/rps) 320/53 440/65
(ft. lbs./rpm) 235/3200 325/3900
No. of cylinders 6 8
Bore (in./mm) 3.3/84 3.7/94
Stroke (in./mm) 3.77/96 3.13/79.5
Cylinder displacement,
liters 3.19 (194.7 cu
in)
4.41 (268.6 cu. in.)
Compression ratio 10.8:1 10.4:1
Charge air cooler (Intercooler)
Turbocharged engines employ a turbocompressor to force air into the engi\
ne inlet manifold and a charge
air cooler to cool the compressed inlet air. The resulting increase in a\
ir flow raises pressure in the intake
manifold and increases engine power over that developed by the normally-\
aspirated engine. The charge
air cooler (which resembles a radiator) is located between the turbo-c\
ompressor and inlet manifold.
Fuel system
The engine is equipped with a multiport fuel injection system.
pg. 218 Specifications
Volvo programs
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (9 of 10)12/30/2006\
