2007 VOLVO XC90 Owners Manual

2007 Volvo XC90
pg. 185 Maintenance
Engine compartment
Engine compartment
1. Brake fluid reservoir
2. Relay/fuse box
3. Air cleaner
4. Cooling fan
5. Radiator
6. Dipstick-engine oil
7. Filler cap-engine oil
8. Washer fluid reservoir
9. Power steering fluid reservoir
10. Expansion tank-coolant
11. Data plate
12. Battery (under floor in rear cargo area)
WARNING!
The cooling fan (6) may start or continue to operate (for up to 6 min\
utes) after the engine has been
switched off.
pg. 186 Maintenance
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (7 of 37)12/30/2006\
5:53:50 PM

2007 Volvo XC90
Engine oil
Oil specifications
Engine oil must meet the minimum ILSAC specification GF-3, API SL, and A\
CEA A1/ B1. Lower
quality oils may not offer the same fuel economy, engine performance, or\
engine protection.
Volvo recommends
.
Depending on your driving habits, premium or synthetic oils may provide \
superior fuel economy and
engine protection. Consult your Volvo retailer for recommendations on pr\
emium or synthetic oils.
Oil additives must not be used.
NOTE: Synthetic oil is not used when the oil is changed at the normal mainten\
ance services. This oil is
only used at customer request, at additional charge. Please consult your\
Volvo retailer.
Oil viscosity (stable ambient temperatures)
Operation in hot climates
When temperatures exceed 86° F (30° C) in your area, Volvo recom\
mends, for the protection of your
engine, that you use a heavier weight oil, such as such as SAE 5W-40 or \
0W-40. See the viscosity chart.
Operation in temperate climates
Incorrect viscosity oil can shorten engine life. Under normal use when t\
emperatures do not exceed 86° F
(30° C), SAE 5W-30 will provide good fuel economy and engine protec\
tion. See the viscosity chart.
Extreme engine operation
Synthetic oils meeting SAE 0W-30 or 0W-40 and complying with oil quality\
requirements are
recommended for driving in areas of sustained temperature extremes (hot\
or cold), when towing a trailer
over long distances, and for prolonged driving in mountainous areas.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (8 of 37)12/30/2006\
5:53:50 PM

2007 Volvo XC90
American Petroleum Institute (API) symbol
The API Service Symbol "donut" is divided into three parts:
l The upper section describes the oil's performance level.
l The center identifies the oil's viscosity.
l The lower section indicates whether the oil has demonstrated energy-cons\
erving properties in a
standard test in comparison to a reference oil.
pg. 187 Maintenance
Engine oil
Changing engine oil and oil filter
See the previous page for oil specifications and
page 212 for oil volumes. Refer to the Warranty and
Service Records Information booklet for information on the oil change in\
tervals.
NOTE:
l Volvo does not recommend the use of oil additives.
l Synthetic oil is not used when the oil is changed at the normal maintena\
nce intervals except at owner
request and at additional charge. Please consult your Volvo retailer.
Checking and adding oil
The oil level should be checked every time the vehicle is refueled. This\
is especially important during
the period up to the first scheduled maintenance service.
l The vehicle should be parked on a level surface when the oil is checked.\

l If the engine is warm, wait for at least 10-15 minutes after the engine has been switched off\
before
checking the oil.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (9 of 37)12/30/2006\
5:53:50 PM

2007 Volvo XC90
Checking the oil
- Pull out the dipstick and wipe it with a lint-free rag.
- Reinsert the dipstick, pull it out, and check the oil level.
- Add oil if necessary. If the level is close to the MIN mark, add appro\
ximately 1 US quart (1 liter) of oil.
- Run the engine until it reaches normal operating temperature.
- Switch off the engine and wait for at least 10-15 minutes and recheck \
the oil level. If necessary, add oil
until the level is near the mark.
CAUTION!
- Not checking the oil level regularly can result in serious engine dama\
ge if the oil level becomes too
low.
- Never fill oil above the MAX mark. This could cause an increase in oil\
consumption.
- Not checking the oil level regularly can result in serious engine dama\
ge if the oil level becomes too
low.
- Always add oil of the same type and viscosity as already used.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (10 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
WARNING!
Do not allow oil to spill onto or come into contact with hot exhaust pip\
e
surfaces.
pg. 188 Maintenance
Fluids
Washer fluid reservoir
The washer fluid reservoir is located in the engine compartment and hold\
s approx. 6.8 US qts (6.5 liters).
When there is less than approximately 1 US qt (1 liter) remaining in t\
he reservoir, the washer fluid spray
will be directed to the windshield only.
During cold weather, the reservoir should be filled with windshield wash\
er solvent containing antifreeze.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (11 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Changing coolant
Normally, the coolant does not need to be changed. If the system must be\
drained, consult your Volvo
retailer.
NOTE: Do not top off with water only. This reduces the rust-protective and an\
tifreeze qualities of the
coolant and has a lower boiling point. It can also cause damage to the c\
ooling system if it should freeze.
Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of wate\
r and antifreeze). CAUTION!
The cooling system must always be kept filled to the correct level. If i\
t is not kept filled, there can be
high local temperatures in the engine which could result in damage. Diff\
erent types of antifreeze/
coolant may not be mixed.
Check coolant regularly!
WARNING!
l Never remove the radiator cap while the engine is warm. Wait until the v\
ehicle cools.
l If it is necessary to top up the coolant when the engine is warm, unscre\
w the expansion tank cap
slowly so that the overpressure dissipates.
pg. 189 Maintenance
Fluids
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (12 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Brake fluid reservoir
The brake fluid should always be above the MIN mark on the side of the r\
eservoir. Check, without
removing the cap, that there is sufficient fluid in the reservoir.
Fluid type: DOT 4+ boiling point >536 °F (280 °C), P/N 9437433.
Replace: Every second year or 30,000 miles (48,000 km). The fluid should be re\
placed once a year or
every 15,000 miles (24,000 km) when driving under extremely hard condi\
tions (mountain driving, etc.).
Always entrust brake fluid changing to an authorized Volvo retailer.
Power steering fluid reservoir
The fluid level should always be between the ADD and FULL marks.
Fluid type: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 o\
r equivalent.
Replace: No fluid change required.
NOTE: If a problem should occur in the power steering system or if the vehicl\
e has no electrical current
and must be towed, it is still possible to steer the vehicle. However, k\
eep in mind that greater effort will
be required to turn the steering wheel.
pg. 190 Maintenance
Wiper blades
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (13 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Windshield wiper blades
To change a windshield wiper blade:
- Fold the wiper arm out from the windshield and hold the wiper blade.
- Press in the grooved catches and pull out the wiper blade.
- Insert a new wiper blade and ensure that it is securely in place.
NOTE: The driver's side wiper blade is longer than the one on the passenger's\
side.
Tailgate wiper blade
To change a tailgate wiper blade:
- Pull the wiper arm rearward, away from the tailgate window.
- Pull out the wiper blade as shown in the illustration.
- Press the new wiper blade into place. Check that it is properly secure\
d.
pg. 191 Maintenance
Battery
