2007 VOLVO XC90 Owners Manual

2007 Volvo XC90
Using the ISOFIX lower child seat anchors
Lower anchors for ISOFIX-equipped child seats are located in the second \
row, outboard seats, hidden
below the backrest cushions. Symbols on the seat back upholstery mark th\
e anchor positions (see the
illustration above).
To access the anchors:
1. Put the child restraint in position.
2. Kneel on the child restraint to press down the seat cushion and locat\
e the anchors by feel.
3. Fasten the attachment on the child restraint's lower straps to the IS\
OFIX lower anchors.
4. Firmly tension the lower child seat straps according to the manufactu\
rer's instructions.
NOTE:
l The rear seat's center position is not equipped with ISOFIX lower anchor\
s. When installing a child
restraint in this position, attach the restraint's top tether strap (if\
it is so equipped) to the top tether
anchorage point (see the information on
page 39) and secure the restraint with the vehicle's center seat
belt (see the information beginning on
page 31).
l Always follow your child seat manufacturer's installation instructions, \
and use both ISOFIX lower
anchors and top tethers whenever possible.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (34 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
WARNING!
Be sure to fasten the attachment correctly to the anchor (see the illus\
tration above). If the attachment
is not correctly fastened, the child restraint may not be properly secur\
ed in the event of a collision.
pg. 39 Safety
Top tether anchors
Top tether anchors
Your vehicle is equipped with child restraint top tether anchorages in a\
ll second row seat positions
(second-row seats only in 7-seat models).
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (35 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
Using the top tether anchorages
- Place the child restraint on the rear seat.
- Route the top tether strap under the head restraint and fasten its att\
achment to the anchorage.
- Firmly tension the top tether strap according to the child restraint m\
anufacturer's instructions. Tension
the top tether strap only after the lower anchor straps or the seat belt\
have been firmly tensioned.
See
page 38 for on securing the child restraint to ISOFIX lower anchors.
WARNING!
l Never route a top tether strap over the top or around the head restraint\
. It should always be routed
under the head restraint.
l Child restraint anchorages are designed to withstand only those loads im\
posed by correctly fitted
child restraints. Under no circumstances are they to be used for adult s\
eat belts or harnesses. The
anchorages are not able to withstand excessive forces on them in the eve\
nt of collision if full harness
seat belts or adult seat belts are installed to them. An adult who uses \
a belt anchored in a child
restraint anchorage runs a great risk of suffering severe injuries shoul\
d a collision occur.
l Do not install rear speakers that require the removal of the top tether \
anchors or interfere with the
proper use of the top tether strap.
NOTE:
l Child restraints could be recalled for safety reasons. You must register\
your child restraint to be
reached in a recall. To stay informed about child safety seat recalls, b\
e sure to fill out and return the
registration card that comes with new child restraints.
l Child restraint recall information is readily available in both the U.S.\
and Canada. For recall
information in the U.S., call the U.S. Government's Auto Safety Hotline \
at 1- 800-424-9393. In Canada,
visit Transport Canada's Child Safety website at
http://www.tc.gc.ca/roadsafety/childsafety/menu.htm.
pg. 40 Safety
Integrated booster cushion
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (36 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
Integrated booster cushion (option)
Volvo's own integrated booster cushion has been specially designed to he\
lp safeguard a child seated in
the rear seat. When using an integrated booster cushion, the child must \
be secured with the vehicle's
three-point seat belt.
Use this booster cushion only with children who weigh between 33 and 80 \
lbs (15 and 36 kg) and whose
height is between 38 and 54 in (97 and 137 cm). In Canada, Transport C\
anada's weight recommendation
is 40-80 lbs (18-36 kg).
The booster cushion is designed to raise the child higher, so that the s\
houlder strap crosses over the
child's collarbone, not over the child's neck. If using a booster cushio\
n does not result in proper
positioning of the shoulder strap, then the child should be placed in a \
properly secured child restraint
(see the information beginning on
page 31). The shoulder belt must never be placed behind the child's
back or under the arm.
Canada only: This cushion may be referred to as a built-in booster cushi\
on.
WARNING!
l DEATH or SERIOUS INJURY can occur.
l Follow all instructions on the booster cushion and in the vehicle's owne\
r's manual.
l MAKE SURE THE BOOSTER CUSHION IS SECURELY LOCKED BEFORE THE CHILD IS
SEATED.
l Use this booster cushion only with children who weigh between 33 and 80 \
lbs (15 and 36 kg) and
whose height is between 38 and 54 in (97 and 137 cm). In Canada, Trans\
port Canada's weight
recommendation is 40-80 lbs (18-36 kg).
pg. 41 Safety
Integrated booster cushion
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (37 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
Raising
- Pull the handle at the front of the cushion (1) forward.
- Move the seat belt latch aside before raising the cushion.
- With both hands push the cushion rearward (2).
- Push the cushion until it locks in place.
Lowering
- Pull the handle at the front of the cushion (1) forward.
- Pull the seat forward and press it down until it locks in place.
The booster cushion must be pressed down before the backrest can be fold\
ed down.
WARNING!
In the event of a collision while the integrated booster cushion was occ\
upied, the entire booster
cushion and seat belt must be replaced. The booster cushion should also \
be replaced if it is badly
worn or damaged in any way. This work should be performed by an authoriz\
ed Volvo retailer only.
pg. 42 Safety
This page left intentionally blank.



file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (38 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
Contents | Top of Page
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (39 of 39)12/30/200\
6 5:53:34 PM

2007 Volvo XC90
2 0 0 7
VOLVO XC90
Instruments and controls

pg. 43 Instruments and controls
Instrument overview
44
Instrument panel
46
Indicator and warning symbols
47
Switches in the center console
52
Steering wheel adjustment
54
Lighting panel
55
Left-side steering wheel lever
58
Right-side steering wheel lever
59
Hazard warning flashers, rear window/sideview mirror
defroster
61
Trip computer
62
Cruise control
63
Auxiliary 12-volt sockets
65
Parking brake
66
Opening the hood and tailgate
67
Power windows
68
Rearview mirror/power folding sideview mirrors
70
Power moonroof (option)
73
pg. 44 Instruments and controls
Instrument overview
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (1 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
pg. 45 Instruments and controls
Instrument overview
Page
1. Headlights/Parking lights
55
2. Instrument lighting
55
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (2 of 40)12/30/2006\
