2007 Volvo XC90
The seat belts are equipped with tensioners that reduce slack in the bel\
ts. These tensioners are triggered
in situations where the airbags deploy. The front seat belts also includ\
e a tension reducing device which,
in the event of a collision, limits the peak forces exerted by the seat \
belt on the occupant.
Buckling a seat belt
Pull the belt out far enough to insert the latch plate into the receptac\
le until a distinct click is heard. The
seat belt retractor is normally "unlocked" and you can move freely, prov\
ided that the shoulder belt is not
pulled out too far.
The retractor will lock up as follows:
l if the belt is pulled out rapidly
l during braking and acceleration
l if the vehicle is leaning excessively
l when driving in turns
When wearing the seat belt remember:
l The belt should not be twisted or turned.
l The lap section of the belt must be positioned low on the hips (not pre\
ssing against the abdomen).
l Make sure that the shoulder belt is rolled up into its retractor and tha\
t the shoulder and lap belts are
taut.
Unbuckling the seat belt
To remove the seat belt, press the red section on the seat belt receptac\
le. Before exiting the vehicle,
check that the seat belt retracts fully after being unbuckled. If necess\
ary, guide the belt back into the
retractor slot.
Seat belt reminder
The seat belt reminder consists of an audible signal, an indicator light\
above the rearview mirror, and a
symbol in the instrument panel that alert the driver and front seat pass\
enger if their seat belts are not
fastened.
pg. 13 Safety
Seat belts
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (4 of 39)12/30/2006\
5:53:33 PM

2007 Volvo XC90
The OWS will disable (will not inflate) the passenger's side front air\
bag when:
l the front passenger's seat is unoccupied, or has small/medium objects in\
the front seat,
l the system determines that an infant is present in a rear-facing infant \
seat that is installed according to
the manufacturer's instructions,
l the system determines that a small child is present in a forward-facing \
child restraint that is installed
according to the manufacturer's instructions,
l the system determines that a small child is present in a booster seat,
l a front passenger takes his/her weight off of the seat for a period of t\
ime,
l a child or a small person occupies the front passenger's seat. The OWS u\
ses a PASSENGER
AIRBAG OFF indicator lamp which will illuminate and stay on to remind yo\
u that the passenger's side
front airbag is disabled. The PASSENGER AIRBAG OFF indicator lamp is loc\
ated in the overhead
console, near the base of the rearview mirror.
NOTE: The PASSENGER AIRBAG OFF indicator lamp will illuminate for a short per\
iod of time when
the ignition is turned on to confirm it is functional. When the front pa\
ssenger's seat is not occupied
(empty seat) or in the event that the passenger's side front airbag is\
enabled (may inflate), the
PASSENGER AIRBAG OFF indicator lamp will be off.
However, if a fault is detected in the system:
l The OWS indicator light will stay on.
l The SRS warning light (see page 15) will come on and stay on.
l The message PASS. AIRBAG OFF SERVICE URGENT will be displayed in the inf\
ormation display.
pg. 21 Safety
Occupant Weight Sensor (OWS)
WARNING!
If a fault in the system is detected and indicated as explained on the p\
revious page, be aware that the
passenger's side front airbag will not deploy in the event of a collisio\
n.
In this case, the safety systems and Occupant Weight Sensor should be in\
spected by an authorized
Volvo retailer as soon as possible.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_01.htm (13 of 39)12/30/200\
6 5:53:33 PM

2007 Volvo XC90
2 0 0 7
VOLVO XC90
Instruments and controls

pg. 43 Instruments and controls
Instrument overview
44
Instrument panel
46
Indicator and warning symbols
47
Switches in the center console
52
Steering wheel adjustment
54
Lighting panel
55
Left-side steering wheel lever
58
Right-side steering wheel lever
59
Hazard warning flashers, rear window/sideview mirror
defroster
61
Trip computer
62
Cruise control
63
Auxiliary 12-volt sockets
65
Parking brake
66
Opening the hood and tailgate
67
Power windows
68
Rearview mirror/power folding sideview mirrors
70
Power moonroof (option)
73
pg. 44 Instruments and controls
Instrument overview
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (1 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
3. Panel vents78
4. Text window
46
5. Temperature gauge
46
6. Odometer/Trip odometer/Cruise control indicator
46, 63
7. Speedometer
46
8. Turn signal indicator lights
46
9. Tachometer
46
10. Ambient temperature gauge, clock, gear indicator
46
11. Fuel gauge
46
12. Indicator and warning symbols
47
13. Panel vents
78
14. Glove compartment
94
15. Hazard warning flashers
61
16. Audio system
219
17. Switches in the center console
52
18. Climate system controls
79
19. Windshield wiper/washer lever
59
20. Audio control buttons in steering wheel
224
21. Instrument panel
46
22. Horn
44
23. Cruise control buttons in steering wheel
63
24. Turn signals, High/low beams
58
25. Front fog lights, Rear fog light
55
26. Parking brake pedal
66
27. Parking brake release handle
66
28. Button for unlocking fuel filler door
55
29. Hood open lever
67
30. Reading lights
91
31. Courtesy light
91
32. Moonroof control (option)
73
33. Seat belt reminder
11
34. Rearview mirror
70
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (3 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
35. Central locking button45
36. Lockout switch for rear seat power windows
45
37. Power window controls
45
38. Sideview mirror controls
45
pg. 46 Instruments and controls
Instrument panel
1. Turn signal indicators - right/left
2. Text window
The text window displays information and warning messages.
3. Temperature gauge
The pointer should be approximately midway on the gauge when driving. Do not drive the vehicle if
the warning light is on. The text window will provide you with additional information.
If the engine temperature remains high, check coolant level - see
page 184.
4. Trip odometer
The trip odometers are used for measuring shorter distances. The right-h\
and digit gives tenth of a mile/
kilometer. Press the button for more than 2 seconds to reset. Change bet\
ween trip odometers 1 and 2
using one short press on the button.
5. Odometer
6. Speedometer
7. Warning symbol
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (4 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
Active Bi-Xenon headlights (ABL) - option
The beams of ABL headlights adjust laterally to help light up a curve ac\
cording to movements of the
steering wheel when the vehicle is turning. This function is activated a\
utomatically when the engine is
started and can be deactivated/reactivated by pressing the button. The i\
ndicator light in the button is on
when the function is activated. See also
page 55.
Rear seat air conditioning (option)
This button controls the optional rear seat air conditioning system on s\
even-seat models.
Folding sideview mirrors (option)
Press the button and release it to fold the sideview mirrors in or out. \
On certain models, when the button
is pressed, there may be a long pause before the mirrors move. Pressing \
the button again during this
pause may erase your first button press. If this happens, wait ten secon\
ds and press the button one more
time.
The mirrors cannot be adjusted during the first ten seconds after they h\
ave been folded out.
NOTE: If the sideview mirrors have been inadvertently pushed out of position \
(in a car wash, parking
lot, etc.) manually return them to normal position. If mirror adjustmen\
t does not seem to operate after
manual folding, reset the folding mirrors as follows:
- Turn the ignition key to position II.
- Manually fold the mirror(s) to the normal position.
- Press the button to fold both mirrors in.
- Press the button again to fold the mirrors out to their normal positio\
n.
Park Assist (option/ accessory as available)
This system provides an audible warning when the vehicle is being parked\
or if it is driven close to a
person or object. See
page 131 for more information.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (11 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Wipers operate at "high" speed.
Tailgate wiper/washer
1. Intermittent wiping
2. Normal wiping
Move the lever forward to start the tailgate washer.
Tailgate wiper and reverse gear
If the front wipers are on and the transmission is put into reverse gear\
, the tailgate wiper will go into
intermittent wiping function
1.
If the tailgate wiper is already in normal wiping function, the normal w\
iping function will continue.
1. Consult your Volvo retailer if you would like to have this function d\
eactivated.
pg. 61 Instruments and controls
Hazard warning flashers, rear window/sideview mirror defroster
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (21 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Hazard warning flashers
The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard. To activate
the flashers, press the triangular button in the center dash. Press the \
button again to turn off the flashers.
NOTE: Regulations regarding the use of the hazard warning flasher may vary, d\
epending on where you
live.

Rear window and sideview mirror defroster
Press the switch to start heating the rear window and sideview mirrors t\
o remove ice or condensation. A
light in the switch will light up.
A timer automatically switches off the heating after approximately 12 mi\
nutes. The LED will go out
correspondingly.
pg. 62 Instruments and controls
Trip computer (option)
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (22 of 40)12/30/200\
6 5:53:37 PM
