General Introduction
In case there is damage to body and/or part, protection measures
should be taken first to prevent the vehicle from damaging before
repairing them.
Example:
1. Protection adhesive strap should be contacted on the relative
part of body when conduct the disassembling and mounting
operation.
2. When prizing the body parts with screwdriver or scraper, those
body parts head or the edge of screwdriver or scraper should
be wrapped with adhesive strap to prevent paint layer and the
body from damaging.
If the antirust is damaged when repairing other parts, it should be
recoated in time.
Example:
1. In case the sealing agent, paint layer or priming coat on the
body is damaged due to peel-off or crack, etc. the correspond-
ing antirust shall be used for reparation.
2. If the hinge or plate is loosened or torn down, the antirust
should be re-coated after repairing them.
adhesive strap
Vehicle Body
General Introduction
peel-off
crack
anti-rust agent

B0-3
Engine cover
Adjustment of engine cover
Remark
as the centering bolt are used as the fixing bolt to fix the
hinge of engine cover, the engine cover cannot be adjusted when
mounting, in such case, the bolt with a washer should be used to
substitute the centering bolt.
1. Adjust the engine cover in front-back and right-left
direction.
Loosen the hinge bolts on engine cover to adjust the engine
cover.
2. Adjust the engine cover leading edge vertically;
Rotate the buffer block to adjust the engine cover.
3. Adjust the lock clips on engine cover Loosen the bolt to
adjust the lock clip. Vehicle Body
Engine Cover
centering bolt
bolt with washer

B0-4Vehicle Body
Front Door
Front door
Element figure
(glass)
glasschannel
outer auchi
inner tri-angle trim panel
door limiting device
door hinge
indoor handle
seal strip on
door plate
electric switch
and panel
interior trim panel
of electric door
(Dr)
interior trim panel
of electric door
(SF) interior trim panel of
electric door
sleeve
snapping ring elevator handle
(SL SK SY SJ)
door lamp
inner clip
lower rear glass
guide track sliding channelsmall sliding track door lock assembly
lower front glass
guide track lock cliplock ringlock barreloutdoor handle
manual interior
trim panel(Dr) snapping ring
glass bracket and glass gasket
rear vision mirror

B0-5
Adjustment of front door
1. Adjust the car door in the front-back and vertical direction;
Adjust the car door under the condition that the bolts of body
side hinge are loosened.
2. Adjust the car door in left-right and vertical direction
Adjustment should be made after the bolts of side hinge of
body are loosened.
3. Adjust the clip of door lock:
(a) Check whether the car door assembly and the match of
door lock are adjusted correctly.
(b) Loosen the lock clip lightly to mount the screws and tap
the lock clip with hammer to adjust their positions.
(c) Screw off the fixing screws of lock clip.
Disassembly of front door
1. Tear down the elevator handle (Dr)
Pull out the snapping ring of spring with dishcloth and tear
down the elevator handle and the sleeve.
2. Tear down the indoor handle
3. Tear down the inner triangle trim panel;
Loosen the clip open with a screwdriver to tear down the inner
triangle trim panel.
Notice: before using the screwdriver, wrapping the
screwdriver head with adhesive strap.
4. Tear down the rear vision mirror;
Tear down the three screws and rear vision mirror. Vehicle Body
Front Door

B0-6
5. Tear down the interior trim panel of car door:
(a) Tear down the inner clip bolts and the inner clip.
(b) Tear down the door lamp bolts and the door lamp;
(c) Insert the screwdriver into seam between fixing clip and
interior trim panel of car door to loosen the interior trim
panel.
Notice: before using the screwdriver, wrap its head with
adhesive strap.
(d) Tear down the interior trim panel of car door.
(Dr SF)
(a) Tear down the inner clip bolts and the inner clip;
(b) Tear down the door lamp bolts and the door lamp;
(c) Tear down the electric switch and panel.
(d) Insert the screwdriver into the seam between fixing clip
and the interior trim panel of car door to loosen the
interior trim panel.
Remark: use the adhesive strap to wrap the screwdriver
head before using.
(e) Tear down the interior trim panel of car door.

SL SK SY SJ)
(a) Tear down the door lamp bolts and the door lamp;
(b) Tear down the electric switch and the panel;
(c) Tear down the screw covers and screws on the indoor
trim panel
(d) Insert the screwdriver into the seam between the fixing
clip and the interior trim panel of car door to loosen it.
Notice: use the adhesive strap to wrap the screwdriver
head before using.
(f) Tear down the interior trim panel of car door.manually operated indoor plate
inner plate of electric door (type A)
inner plate of electric door (type B)12 clips
ten clips
four sets of bolt and nut
Vehicle Body
Front Car Door
12 clips
6. Tear down the outer auchi
Loosen the clip along the edge of paneling to tear down the
outer
7. Tear down the door and window glass;
(a) Tear down the fixing bolts in the two glass sliding-
grooves.
(b) Pull up the glass to take it down.
8. Tear down the glass groove on car door.

B0-7
Change of Glass
(Dr SF)
1. Tear down the glass bracket with screwdriver or similar
tool;
2. Coat the black glue on the inside of glass bracket liner;
3. Tap the glass bracket with rubber hammer to encase it in.
(SL SK SY SJ)
1. Tear down the bolts on gear plate with pliers or similar
tool;
2. Tear down the bolts of glass bracket of car door to take
out the glass. Vehicle Body
Front Car Door170mm
Dr. SF
SL. SK. SY. SJ
9. Tear down t the lower rear glass guide track:
Tear down the bolts and guide track.
10. Tear down the lower front glass guide track;
Tear down the bolts and guide track.
11. Tear down the glass elevator:
(a) Tear down the two fixing bolts of small sliding track;
(b) Tear down the fixing bolts of three elevators (manually
operated)
Tear down the fixing bolts of four elevators. (electric)
(c) Tear down the elevator through the auxiliary hole.
12. Tear down the lock ring inside the vehicle;
Disconnect the control lever to tear down the lock ring inside
the vehicle.
13. Tear down the door lock and outdoor handle with lock
barrel;
(a) Disconnect the control lever from the outdoor handle
with lock barrel.
(b) Tear down the 3 bolts and door lock.
(c) Tear down the two bolts and outdoor handle with lock
barrel.
(d) Tear down the spring snapping ring and lock barrel.

B0-8
Assembly of Front Door
1. Coat the MP lubricant on the parts before mounting.
(a) Coat the MP lubricant on the sliding face and the gear of
glass elevator.
Notice: Do not plaster the MP lubricant on the spring of
glass elevator.
(b) Plaster the MP lubricant on the sliding face of door lock.
2. Mount the outdoor handle with lock barrel and the door
lock;
(a) Mount the lock barrel on the outdoor handle with spring
snapping ring;
(b) Use two bolts to mount the outdoor handle and the lock
barrel;
(c) Mount the door lock with three screws;
(d) Connect the outdoor handle to the control lever.
3. Mount the lock ring inside vehicle
Mount the lock ring inside of vehicle and connect the control
lever.
4. Mount the lower rear glass guide track,
5. Mount the lower front glass guide track;
6. Mount the glass elevator:
(a) Put in the elevator through the auxiliary hole;
(b) Mount on the three fixing bolts of elevator. (manually
operated)
Mount on the four fixing bolts of elevator (electric)
(c) Mount the small sliding track, and screw up the bolts of
small sliding track temporarily.
7. Mount the glass groove on car door;
8. Mount the car door and window glass;
Put the glass in the car door cavity, and then use two bolts to
fix the glass on the elevator. Vehicle Body
Front Door

B0-9
manual indoor plate
Electric indoor plate (Type A)
ten clips
12 clips
Vehicle Body
Front Door
12. Mount the interior trim panel of car door:

Dr)
(a) Connect the handle to the control lever first, then pull it
out from the indoor handle hole.
(b) Fix the clip by tapping to encase the interior trim plate of
car door in the corresponding hole of car door interior
panel.
(c) Use one screw to mount the inner clip.

Dr SF)
(a) Connect the handle to the control lever first, and then pull
it out from the indoor handle hole.
(b) Fix the clip by tapping to encase the interior trim panel in
the corresponding hole of car door interior panel
(c) Mount the inner clip with one screw; and
(d) Mount the electric switch and panel.

SL SK SY SJ)
(a) Connect the handle with the control lever first, then pull
out it from the indoor panel handle.
(b) Connect the plugging elements.
(c) Fix the clip by light tapping to encase the interior trim panel
of car door in the corresponding holes on indoor panel.
(d) Mount the inner clip with two bolts;
(e) Mount the four screws to fasten the interior trim panel of
car door, and cover the nuts.
(f) Mount the electric elevator switch.
13. Mount the indoor handle:
(a) Push the indoor handle into the car door paneling and
make it slide backward.
(b) Screw on the screws;
14. Mount the elevator handle (Dr)
Mount the paneling and elevator handle with spring snapping
ring under the condition the car doors and windows are closed
completely as shown in drawing.
12 clips
9. Adjust the car door and window glass;
Adjust the balance arm upwardly or downwardly until the
dimensions of A and B shown in drawing are equal, and then
fix the balance arm.
10. Mount the outer
Encase the claw of clip into the paneling seam and press the
outer on the paneling.
11. Mount the rear vision mirror
inner panel of electric door (type B)
four sets of bolt and nut
