2006 GREAT WALL DEER Service Manual

TF-23
5 4
3
1
6 2
Transfer Box
Transfer Box Assembly
1. transfer box rear body
2. flange
3. oil seal
4. gasket
5. nut
6. oil plug
13. Flange assembly
The parts mount process is as follows:
(a) Encase the two oil plugs in the rear cover.
(b) Encase the flange, sealing ring and gasket, and then
screw up the nuts.
Fastening torque
(203
244)N
m

TF-24Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Washing)
1. Washing
Notice: check the metal rag around the magnet first before washing, large granule or irregular metal
granule shows the disintegratation or similar damage. Small or fine metal granule shows the uneven
or serious wear. If the metal rag is founded, notice shall be taken on damage and wear inspection
during checking the rotating parts and the element matched with the rotating parts.
(a) Common washing
Wash the parts in cleaning agent to clean away the old lubricant and deposit. Clean away the deposit in oil hole
with brush. Take notice not to scrape the metal coupling face when washing the parts cannot be cleaned with
brush.
(b) Dry the washed parts by blowing
Dry the washed parts by blowing the low-pressure compressed air (max pressure is 137.9kPa), because cloth
thread may be left during cleaning the parts with cloth. The bearing shall be held by hand to prevent it from
rotating when blowing it.
(c) Bearing lubrication
The ball bearing and needle bearing shall be lubricated with the lubricant for transfer box after washing. As
the non-lubricated bearing may cause damage when be dry. Cover the lubricated bearing to prevent dust
entering in.
Washing, Inspection, Maintenance or Change

TF-25
(b) Normal gear grinding trace.
Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Checking)
Checking
1. Common Checking process
Check all parts by visual check to see whether there is damage
or serious or uneven wear (parts needed be substituted by new
parts such as O-ring, oil seal and etc. shall be excluded).
Abandon the damaged or weary parts that will affect on their
performance. The check items are as follows:

Burr: tips protruded from the material regionally

Rag: broken small blocks or particles

Crack: surface thread showing the material is partly or
completely separated.

Excessive abrasion
Refer to the serious or obvious abra-
sion beyond of application limit.

Reduction change
Material slip caused by the heavy
pressure on part of it.

adhesive bonding
Granules of the soft metal are dis-
persed and bonded on the hard metal surface.

Ditch trance: partial crack or trough that means the material
transfer instead of material loss.

Pitting corrosion
Damages to the metal surface caused by
pressure, which are displayed due to color change caused
by heat generated by metal friction.

Step wear
a weary step may be seen or felled between the
neighboring interface or between the non-touching face
due to the excessive wear.

Uneven wear: Partially, unevenly distributed wear, which
includes holes, bright spots, uneven polishing or other
visual drawbacks.
2. Gear or Chain sprocket tooth inspection
Check the gear and chain sprocket tooth according to the
following process:
(a) Normal gear shaving trace.
normal gear shaving trace
normal gear grinding trace

TF-26Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Checking)
(e) Unacceptable side deflective contact area that must be
changed.
(f) Acceptable side-deflective contact area
(g) Unacceptable side deflective contact area that must be
changed. (c) Ideal engagement contact area
(d) Acceptable side-deflective contact area

TF-27Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Checking)
(h) Acceptable contact area deflecting to the tooth top.
(i) Unacceptable contact area deflecting to the tooth top,
which must be changed.
(j) Acceptable contact area deflecting to tooth root.
(k) Unacceptable contact area deflecting to tooth root, which
must be changed.
4. Key tooth inspection
Check the broken or peeled spline teeth. The spline teeth may,
if only small part is peeled off, be repaired in the same way as
that for the gear teeth, and can be reused. In case the spline
tooth is broken, the spline must be abandoned. The contact
type of spline is not the same as that for gear; however, spline
that shows step sliding must be abandoned.

TF-28Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Maintenance or Change of Gear or Chain Sprocket Gear)
Maintenance or Change of Gear or Chain
Sprocket Gear
1. Maintenance principle
(a) Conduct the maintenance for the partial, small peel off
with the suitable manual high-speed grinding tool.
(b) Do not clear away the metal as can as possible when
grinding the matrix metal.
(c) All pointed angles and sides must be repaired as the slip-
pery contour line. Because the pointed angle or edges
may be peeled off again or developed into crack.
(d) Clear away the burr with the suitable grinding stone. Take
notice not to damage the matrix when clearing away the
projecting materials, and
(e) When substituting the non-repaired parts (such as
bearing), if the part is doubted in its re-application
capability, it must be changed.
2. Cases for gear or chain sprocket maintenance or substi-
tuting
(a) The gear, being peeled off at the two sides of tooth top in
contact face, may be repaired for reuse.
(b) The gear, being peeled off at the central tooth top of
contact face, may be repaired for reuse.
(c) The gear, being peeled off at one side of the non-contact
face, may be repaired for reuse.

TF-29Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Maintenance or Change of Gear or Chain Sprocket Gear)
(d) The gear, being peeled off at the center of one side of
contact face, may be repaired for reuse
(e) The gear, being peeled off in the center of contact area,
shall be changed.
(f) The gear, being peeled off at two sides of tooth top, shall
be changed.

TF-30Transfer Box
Washing, Checking, Up-Keeping and Exchanging (Attachment for Inspection Maintenance or Change of Parts)
Change the parts and fittings as requirement
Attachment for Inspection Maintenance or Change of Parts
Checking items
Acceptance/Refusal
Parts (items)
All parts (including
all springs)Crack inspection, distortion inspection and ero-
sion inspectionAll parts with crack, all parts that are bended,
distorted or poor in round bouncing are refused.
All threaded partsThread inspection for buckle missing or other
damageThose parts cannot be threaded or bottomed in
overlap manner shall be refused.
Flange and fork
flangePlease refer to the paragraph of
inspection
to
check the spline.Please refer to the
inspection paragraph
for
spline inspection.
Velocity sensor, mo-
tor assembly
Parts of electric clutch
systemPlease refer to the part of electric appliance
Sliding bearing Inside surface inspection for the sliding bearing In the case that the bearing has pitting corrosion
or other damage, refuse it.
Ball bearingCheck visually the ball and track of the ball
bearing to see whether there is damage such as
adhesive bonding, pitting corrosion, etc.
Ensure that the bearing are all lubricated, run the
outer race of the bearing while holding the inner
one to feel whether there is poor running or
corrosion, the bearing shall be run smoothly
without excessive clearance.Refuse to use the damaged bearing;
Refuse to use the damaged or loose bearing; or
Check the axial clearance to see whether it
exceeds 0.23mm.
Needle bearing Check the bearing needle roller and track to see
whether there is damage such as adhesive
bonding, pitting corrosion, etc.Refuse to use the damaged bearing.
The rear cover, front
body and front hous-
ing of transfer boxCheck to see whether there is burr on the cou-
pling face or other damage that impedes assem-
bling or sealing.Clear away the burr according to the paragraph
of
inspection
, otherwise, change the dam-
aged element
Rear cover of trans-
fer boxCheck the bearing holeRefuse to use the assembly that has pitting
corrosion
Odometer gear Check the gear teeth referring to the Inspection
ParagraphRefer to the gear or chain sprocket inspection in

inspection paragraph
.
Clutch shell, joint
outer gear sleeve and
joint coverCheck the spline according to the Inspection
paragraphRefer to the spline inspection of
inspection
paragraph

Locking sleeveCheck the wear or damage of the toggle fork
grooveRefuse the parts with step slipping or damage.
Shift guide shaft Check the deformation situation
Check the burr or other damage on outer race
Check the wear of outer raceRefuse to use the bend shaft; clear away the burr
according to the
inspection
paragraph, oth-
erwise refuse to use.
Refuse to use the shaft with step slipping or
other damage.
Shift toggle forkCheck whether there is wear or damage at the
location where the toggle fork combines with
the shifting cam and gear sleeve.If any step slipping or damage is found, refuse
to use it.
