2006 GREAT WALL DEER Service Manual

MT-46
4WD
Gearbox
Assembly of Gearbox
(f) Fasten the rear cover bolts of the four-gear driving
gearbox
Tightening moment:(30
45)N
m(Tang tooth)
(g) Mount and propel tightly the setting bolts of the gearshift
yoke block.
Tightening moment
(17
22)N
m
22. Mount the steel ball spring and plug
(a) Coat the sealing agent on the plug thread.
(b) Mount the steel ball, setting spring and setting spring
plug.
Tightening moment
(17
22)N
m
23. Check the following items after mounting the rear body
or gearbox
(a) Check the stability of the running input shaft and output
shaft.
(b) Check the gearshift stability of each speed
24. Mount the component elements of the locating mecha-
nism
(a) Mount the black component elements of the locating
mechanism on the side of the five-speed reverse gear.
(b) Mount another component element of locating mecha-
nism and propel it tightly.
Tightening moment
(30
40)N
m
25. Mount the gearshift cover of the gearbox.
(a) Mount the gearshift cover coated with sealing agent.
(b) Mount six bolts and then tighten them.
Tightening moment
(15
20)N
m

MT-47Gearbox
Assembly of Gearbox
26. Mount the clutch frame
(a) Mount the clutch frame.
(b) Coat the sealing agent on the bolt thread.
(c) Mount the nine bolts and then tighten them.
Tightening moment

Upper tooth
(60
70)N
m
Tang tooth
(30
45)N
m
27. Mount the back-up lamp switch.
Tightening moment
(20
40)N
m
28. Mount the driven gear of odometer
(a) Mount the driven gear of odometer.
(b) Mount the bolts and tighten them.
Tightening moment
(10
15)N
m

TF-1
page
Notice ........................................................................... TF-2
Troubleshooting ........................................................... TF-3
Product Description and Simple Maintenance ............. TF-5
Dismantle and Mount of Transfer Box .......................... TF-7
Disassembly of Transfer Box ....................................... TF-9
Assembly of Transfer Box ............................................ TF-14
Washing, Inspection, Maintenance and Change .......... TF-24
Washing ................................................................... TF-24
Inspection ................................................................ TF-25
Maintenance and Change of Gear and Chain gear .. TF-28
Attachment for Inspection, Maintenance and
Change of Parts ....................................................... TF-30
Transfer Box
TF

TF-2Transfer Box
Notice
Notice
Notice on transfer box disassembly and assembly
Notice shall be taken on the soft handling of the parts (coupling face in particular) during the process of
transfer box disassembly to avoid the collision; each parts shall put down in order so as to avoid of missing
or mistaking.
Notice shall, during assembly process, not only on the aforesaid items, but also on the following items:
1. Wash all parts and fittings before assembly (rubber element and washer excluded).
2. Oil seal, clip for shaft and spring pin of various kinds shall not be reused.
3. Lubricating oil is required to coat on the various friction surface and lubricant on lips of various oil seal.
4. Rolling body is not allowed to use for pressure transmission when mounting various bearings.
5. Lip-type oil seal is not allowed to mount slantwise.
6. The openness on the two sides of spring collar shall not be coupled face-to-face when assembling the
component elements of synchronizer. And
7. No parts is allowed the lubricant leakage and penetration when the transfer box locates at the working
location.

TF-3Transfer Box
Troubleshooting
Common troubles Causes Resolving approaches
Change the lubricant or supplement the
lubricant volume.
Guarantee the torque of all connecting
elements stand at the specified value.
Open the transfer case to check the
bearing and othe parts whether is weared
or daamaged,if this happened,change
the parts.
Difficulty in mechanic gearshift or
outplace gear engagement
Troubleshooting
Incorrect lubricant or insufficient
lubricant volume.
Looseness of connecting bolt or other
connecting element.
Noise from the transfer box bearing Noise, which is spreader by the transfer
box instead of clutch, engine, drive shaft
and other parts, occurs in each speed. No driving of front wheel in the four-
gear engagementDrive chain breakDisassemble and check the damage of
inner parts, and change the chain. Adjust or repair shift lever.Open the
transfer box to check the toggle fork and
guide shaft, and change the parts as
requirement.Open the transfer box to
check whether the parts is wearied or not,
and, if any, change the weary parts.Open
the transfer box to check whether the
parts is wearied or not, and, if any, change
the weary parts.Open the transfer box to
check whether the parts is wearied or not,
and, if any, change the weary parts. Overlarge loose fit clearance of the
shift toggle fork on the shift guide
shaft.
Wear of the shift toggle fork
assembly including pin and contact
roller.
Wear of the shift cam hub and the
liner.
Attainment of coupling gear Mechanic gearshift seizing at a certain
location Engagement failure of the mechanically
shift transfer boxDamage or unsuitable adjustment of
the shifting mechanism.
Damage or serious wear of the inner
shifting parts, or looseness or
attainment of the shift toggle fork
assembly on the guide shaft.
Unsuitable adjustment of shift lever.Adjust or repair the shift lever mechanism.
Change the seriously wearied parts.
Change the loose or weary parts. Refer to the vehicle manual for correct
operation.
Add the specified oil of given volume.
Open the rear cover of transfer box to check
and changer the damaged parts.
Open the rear cover of the transfer box to
check whether the sliding parts can slide
freely along the axle, if not, dismantle it and
change the damaged parts. Incorrect operation.
Lubricant of inferior quality or
insufficient volume.
Adhesive bonding of shift toggle fork.
Adhesive bonding of the sliding joint
cover, locking sleeve or gear. Mechanic gearshift failure under the
movement of shifting handleBreak or damage of the shift rocker
arm or shift lever.
Damage of the guide plate of shifting
cam;Change the damaged element.
Open the rear cover of the transfer box to
check the damaged element and change
it. Electric gearshift troubleDamage or failure of electrically
controlled element, electric module,
speed sensor, electric motor, electric
clutch, or built-in wire harness.
Damage or worn of shifting cam,
joint cover, locking sleeve, toggle
fork or shift guide axle.Adhesive
bonding shiftRefer to the vehicle usage manual to
diagnose the failure element and change
it as requirement.
Dismantle the weary or damaged parts
and change it as requirement.
Dismantle and check the free movement
of sliding element, and change it as
requirement

TF-4Transfer Box
Troubleshooting
Common troubles CausesResolving approaches
Unsuitable tire pressure.
Noise, which is spread by the transfer
box instead of the clutch, engine or other
parts, occurs at each speed.Gear noise.
Damage or wear of chain gear or
chain.Open to check whether there is weary
element or damaged element (including
the odometer gear) and, if any, change
them
Noise occurs in the high-speed or low-
speed four-gear driving.Open to check whether there is wear or
damage, and if any, adjust the tire pressure
to suitable value.
Oil leakage in transfer box. Frame Break of transfer box.
Oil leakage of other element.
Ventilation pipe block
Over-added lubricant or lubricant of
unsuitable brand
Looseness of the bolts on sealing
face.
Sealing glue of different brand or
unused sealing glue.
Oil seal wear or damage.Change the frame.
Check the leakage by wiping dry.
Open and clean it and, if necessary,
change it.
Use the specified lubricant and adjust the
lubricant to suitable volume.
Propel the bolts tightly as requirement.
Use the specified sealing glue and propel
the bolts tightly as required.

TF-5Transfer Box
Product Description and Simple Maintenance
Transfer Assembly NO. of Manufacturer
product assembly NO.
display
termnumber
displaythe last digit of the year
displaythe specific monthly
manufactuer data
displaythe month numnber
Example display:From January (A) to December (L)
Product instruction and simple maintenanceManufactuer data
Product instruction and simple mainte-
nance
1. Product Introduction
The transfer box adapted by our company is the transfer box
of 45-55 manufactured by Bogeguana, which is two-speed
and time driving, a set of planetary mechanism used is to
obtain the speed-reducing performance, while the driving
force is transmitted to the front driving gear by a highly precise
chain. The planetary gear train and rear output shaft element
of transfer box is lubricated initiatively through oil bath and oil
pump. This transfer box has four gears:

2H-stands for the two high gears
in which, only the two
rear wheel are driven, and the gear ratio of the transfer box
is 1:1


4H-stands for the four high gears, in which , all of the four
wheel are driven, and the gear ratio of the transfer box is
1:1


N- neutral location (this location only exists in the transfer
box of manual gearshift )
No driving force is transmitted
to the wheel when the input shaft and output shaft are
disconnected.

4L-stands for low gears, the four wheels are all driven, and
the gear ratio of transfer box is 2.48:1.
The gearshift of the mechanical gearshift transfer box is
obtained through the shifting-cam-type guide plate that is
operated by the shift rocker arm.
Sign board: which is fastened at the obvious external location
of transfer box, and on which the detailed data are marked.
borgwarner

TF-65D5D-Oil filling plug
5L-Oil drain plug5L2. Regular lubricant change
(a) The oil level of lubricant in transfer box shall be checked
when exchanging the engine lubricant or after the vehicle
covers 8000 kilometers, and the lubricant shall be added
as requirement.
(b) The lubricant shall be changed with the specified one
every year or after the vehicle covers 48000 kilometers.
3. Lubricant inspection approach
(a) Clean the oil filling plug and the around area.
(b) Open the oil-filling plug to check whether the lubricant
can flows out or not.
(c) if the lubricant can flow out, which means the real
lubricant volume is under the prescribed value, and the
specified lubricant shall be added into the transfer box
until the lubricant can flow from the oil filler hole.
(d) Propel the oil-filling plug tightly according to the given
Tightening moment.
Tightening moment
(19
30)N
m
Notice: The vehicle shall run for a certain time before
checking or exchanging the lubricant so that the
temperature of lubricant in transfer box may be a little
higher. Do not use hammer or other punching tools to
open or propel the oil drain plug or oil filling plug, otherwise,
the thread hole on the frame will be damaged
4. Lubricant change
(a) Clean the oil filling plug and oil drain plug and the around
area.
(b) Put down a oil container under the transfer box.
(c) Open the oil drain plug.
(d) Open the oil-filling plug.
(e) Drain the lubricant up.
(f) Mount the oil drain plug and screw it up according to the
given Tightening moment.
Tightening moment
(19
30)N
m
(g) Add the lubricant through the oil filler hole until the
lubricant overflows. Mount the oil-filling plug and tighten
it according to the Tightening moment.
Tightening moment : (19
30)N
m Transfer Box
lubricant grade: ATF--3Product Description and Simple Maintenance
