2005 NISSAN 350Z Navigation Manual

10 How do I use the voice guidance feature?About voice guidance ....................................................... 10-2
Basics of voice guidance ............................................ 10-2
Adjusting the guide volume ........................................ 10-2
Directions given and the distance to the road
points ................................................................................ 10-2
Notification of an intersection on an ordinary
road ................................................................................... 10-2
Notification of consecutive intersections on an
ordinary road ................................................................... 10-2
Notification of an entrance to a freeway ................. 10-2
Notification of a freeway junction .............................. 10-3
Notification of an exit from a freeway....................... 10-3
Notification of the vehicle approaching a
destination ....................................................................... 10-3
Requesting current voice information ............................ 10-3
Notes on the voice guidance ........................................... 10-4


04.7.6/Z33-N


WARNING
To operate the navigation system or to
use the screen functions, first park the
vehicle in a safe place and set the park-
ing brake. Using the system while driv-
ing can distract the driver and may re-
sult in a serious accident.BASICS OF VOICE GUIDANCEThe voice guidance will verbally tell you which
direction to turn when the vehicle approaches
the intersection in which you have to make a turn
to reach your destination.

There may be some cases in which the
voice guidance and the actual road con-
ditions do not correspond. This may
occur because of discrepancies be-
tween the actual road and the informa-
tion on the DVD or due to the vehicle’s
speed.

In case the content of the voice guid-
ance does not match the actual road
conditions, follow the information ob-
tained from traffic signs or notices on
the road.
ADJUSTING THE GUIDE VOLUME1. Press the SETTING button on the control
panel.
2. When turning on/off the voice guidance,
push the PUSH ENTER button. When the
Guidance Volume key is illuminated with a
green indicator, it is activated. When turning
up/down the voice guidance, touch theLouder or
Softer key. The voice will be-
come louder/softer.
DIRECTIONS GIVEN AND THE
DISTANCE TO THE ROAD POINTSDirections will differ, depending on the road
type.
INFO:
Distances may vary, depending on the vehicle
speed.NOTIFICATION OF AN
INTERSECTION ON AN ORDINARY
ROAD“In a quarter mile (400 meters), right (left) turn.”
“Right (left) turn ahead.”NOTIFICATION OF CONSECUTIVE
INTERSECTIONS ON AN
ORDINARY ROAD“In a quarter mile (400 meters), right (left) turn,
then left (right) turn.”
“Right (left) turn ahead, then left (right) turn.”NOTIFICATION OF AN ENTRANCE
TO A FREEWAY“In a quarter mile (400 meters) freeway entrance
on your right onto (road number and direction).”
INV1684
ABOUT VOICE GUIDANCE10-2
How do I use the voice guidance feature?


04.7.6/Z33-N


“Freeway entrance on your right onto (road
number and direction).”NOTIFICATION OF A FREEWAY
JUNCTION“In about one mile (1.6 kilometers), keep to the
right (left) onto (road number and direction), then
in a quarter of a mile keep to the left (right).”
“Keep to the right (left) onto (road number and
direction), then in a quarter mile (400 meters)
keep to the left (right) onto (road number and
direction).”
“Keep to the left (right) onto (road number and
direction).”NOTIFICATION OF AN EXIT FROM
A FREEWAY“In about one mile (1.6 kilometers), exit on your
right.”
“Take the second exit on your right.”NOTIFICATION OF THE VEHICLE
APPROACHING A DESTINATIONOrdinary road:
When the vehicle approaches a destination, the
voice will say, “You have arrived at your destina-
tion. Ending route guidance.” For the remainderof the way, please find your direction on the map
display.
Dark green road:
After passing the last turning point on a sug-
gested route, the voice will say, “En route to your
destination, some roads contain incomplete map
data. Turn guidance will not be provided in this
area.”
When approaching the end point of the sug-
gested road, the voice will say, “Entering the
road with incomplete map data. Please use the
direction arrow and distance information to pro-
ceed to your destination.”
This is available during route guidance, from the
time after the route calculation is completed until
the vehicle arrives at the destination.
Press the VOICE button.
The current condition will be announced.
INFO:

If you press the VOICE button when you are
off the suggested route and when the auto-
matic reroute function is off, the voice will
announce: “Proceed to the highlighted
route.”

If you press the VOICE button when you are
going in the wrong direction, the voice will
INV1685
REQUESTINGCURRENT VOICE
INFORMATION
How do I use the voice guidance feature?
10-3


04.7.6/Z33-N


announce: “Please make a legal U-turn if
possible.”
The voice guidance in this system should be
regarded as a supplementary function. When
driving your vehicle, check the route on the
map display and follow the actual road and all
traffic regulations.

The voice guidance is activated only for
junctions with certain conditions. In some
cases you may need to turn, even if there is
no voice guidance.

The content of the voice guidance may vary,
depending on the direction of the turn and
the type of junction with other roads.

The route guidance will be activated at vari-
ous times depending on the situation.

When the vehicle is off the suggested route,
route guidance is not available. The system
will not inform you of this; please refer to the
map display and request rerouting.

At freeway junctions, the road numbers and
directions may not accurately correspond
with the voice guidance.

At freeway exits, the street names may not
accurately correspond with the voice guid-
ance.

The displayed street names may sometimes
differ from the actual names or “UNKNOWN
STREET NAME” may be displayed.Please refer to “Automatic rerouting” on page
9-2.

When the green indicator on the
Guidance Volume key is not illuminated,
the voice guidance is not available.

The voice guidance will start when the vehicle
enters the suggested route. Before entering
the route, refer to the map display for the
direction.

When the vehicle approaches a waypoint, the
voice will say, “You have arrived at waypoint 1
(2, 3, 4,...).” The guidance will switch to the
next route section. While the voice guidance
is not available, please refer to the map
display for the direction.

In some cases, the voice guidance ends
before arrival at the destination. In such
cases, drive the vehicle by referring to the
destination icon displayed on the map
screen.

When the system can judge on which side
the destination (waypoint) is located, the
voice guidance will say “on the right” after
announcing the arrival at the destination.

Voice guidance may not operate as specified
or may not operate at all due to the angle of
roads at intersection entrances and exits.
NOTES ON THE VOICE
GUIDANCE
10-4
How do I use the voice guidance feature?


04.7.6/Z33-N


11 How do I adjust the display?Screen information — Planview display ........................ 11-2
Screen information — Birdview
TM
display .................... 11-2
Switching between BirdviewTM
and Planview
displays ............................................................................ 11-4
Zooming in and out of the map ....................................... 11-6
Changing the display direction
(in Planview display) ........................................................... 11-7
Scrolling the map ................................................................ 11-9
Displaying the complete route to the destination..... 11-10
Displaying turn list ............................................................ 11-11
Requesting the simulation drive to the
destination .......................................................................... 11-13
Cancel simulation ........................................................ 11-14
Displaying the track .......................................................... 11-15GPS information display ................................................. 11-17
Updating the current vehicle location and
the direction ...................................................................... 11-18
Setting automatic beep sound ...................................... 11-20
Setting the display mode ................................................ 11-21
Adjusting the display brightness ............................. 11-21
Adjusting the display contrast ................................. 11-22
Switching the display color ...................................... 11-24
How to use the
(day/night) button ............. 11-25
Display off ..................................................................... 11-26
Setting display duration............................................. 11-27
How to handle the display ............................................. 11-28
Characteristics of liquid crystal display ................. 11-28
Maintenance of the display....................................... 11-28


04.7.6/Z33-N


Direction key:
This indicates and sets the direction of the map
on the display.
Please refer to “Changing the display direction
(in Planview display)” on page 11-7.
Map scale:
This display indicates the scale on the current
map.
Vehicle icon:
This icon indicates your vehicle and the direction
of travel.
GPS indicator:
This will tell you the strength of the GPS signal
received.
Please refer to “Accuracy of positioning” on
page 2-2.
:
This will indicate the approximate distance of
route and traveling time to the destination. This
indicator will appear when you set the destina-
tion with the route guidance ON.
:
Press the MAP or PREVIOUS button to show
the enlarged intersection display.
Map scale:
This display indicates the scale on the current
map.
By using the ZOOM IN / ZOOM OUT but-
tons, you can change the scale of the map.
Height and distance on the Birdview
TM
display is
shown in the table on page 11-3.
INV1686
INV1687
SCREEN INFORMATION —
PLANVIEW DISPLAYSCREEN INFORMATION —
Birdview
TM
DISPLAY
11-2
How do I adjust the display?


04.7.6/Z33-N


Height of viewDistance
between gridsDepth of distance
512,000 feet
(160,000 m)160miles
(256 km)approx. 2,240miles
(approx. 1,792 km)
128,000 feet
(40,000 m)40miles
(64 km)approx. 560miles
(approx. 896 km)
64,000 feet
(20,000 m)20miles
(32 km)approx. 280miles
(approx. 448 km)
32,000 feet
(10,000 m)10miles
(16 km)approx. 140miles
(approx. 224 km)
16,000 feet
(4,800 m)4.0miles
(8 km)approx. 70miles
(approx. 112 km)
8,000 feet
(2,400 m)2.0miles
(4 km)approx. 35 miles
(approx. 56 km)
4,000 feet
(1,200 m)1.0mile
(2 km)approx. 17-1/2
miles
(approx. 28 km)
2,000 feet
(600 m)1/2 mile
(1 km)approx. 8-3/4 miles
(approx. 14 km)
1,000 feet
(300 m)1/4 mile
(500 m)approx. 4-3/8 miles
(approx. 7 km)
Height of view: 1,000 feet (300 m) Height of view: 16,000 feet
(4,800 m)
INV1688
INV1689
How do I adjust the display?
11-3


04.7.6/Z33-N


SWITCHING BETWEEN Birdview
TM
and PLANVIEW DISPLAYSThe Birdview
TM
mode displays the view from
above, looking down toward the direction the
vehicle is traveling. This combines the detailed
display close to the vehicle and the long dis-
tance view in one screen.
To change between the Birdview
TM
and Plan-
view, proceed as follows:
1. Press the SETTING button.
INV1690
INV1691
INI0036
11-4
How do I adjust the display?


04.7.6/Z33-N
