2005 NISSAN 350Z Navigation Manual

You can simulate driving the entire suggested
route to the destination on the screen.
1. Press the ROUTE button.
Keys will be displayed on the screen.
2. Select the
Route Info key. 3. Select the
Route Simulation key.
INV1704
INV1711
REQUESTINGTHE SIMULATION
DRIVE TO THE DESTINATION
How do I adjust the display?
11-13


04.7.6/Z33-N


The screen will display a simulated drive with
voice guidance on the suggested route to the
destination.
4. When the CANCEL or DEST button is
pressed, or the vehicle starts to run, the route
simulation will be canceled.INFO:
Route simulation is not available for dark green
roads on your route. Therefore, if the start point
is on a dark green road, the vehicle icon will jump
from the start point to the suggested road when
starting the route simulation.
Also, if the destination is on a dark green road,
the vehicle icon will jump from the end point of
the suggested route to the destination in the
route simulation.
CANCEL SIMULATION1. Press the ROUTE button during simulation.
Select the
Route Info key.
INV1712
INV1713
11-14
How do I adjust the display?


04.7.6/Z33-N


2. The [ROUTE INFO.] screen will be displayed.
Select the
Cancel Simulation key.
INFO:
When the CANCEL or DEST button is
pressed, or the vehicle starts to run, the route
simulation will be canceled.
INFO:
If you select the
Pause key, simulation is
paused. If you select the key again, the simula-
tion will restart.You can have the system track the road you have
taken, and display it with indication marks ().
1. Press the SETTING button.
2. Select the
Navigation key on the [SET-
TINGS] screen.
INV1714
INV1466
DISPLAYINGTHE TRACK
How do I adjust the display?
11-15


04.7.6/Z33-N


3. Select the
Tracking On/Off key. 4. Select the
On key. 5. Press the MAP button.
The location of the vehicle will be displayed.
INFO:

You can select the
On key to display the
indication marks (), and the
Off key to
stop displaying them.

The indication marks () may be spaced
differently, according to the scale of the map.

If you reset the current vehicle location, the
indication marks () will be cleared.
INV1716
INV1717
INV1718
11-16
How do I adjust the display?


04.7.6/Z33-N


The following GPS information will be displayed
on the screen: latitude, longitude, altitude, signal
reception, and satellite locations.
1. Press the SETTING button.
2. Select the
Navigation key on the [SET-
TINGS] screen.3. Select the
GPS Information key.
GPS information will be displayed.
INV1466
INV1720
GPS INFORMATION DISPLAY
How do I adjust the display?
11-17


04.7.6/Z33-N


INFO:

The satellite with a strong enough signal will
be indicated in green.

The display will read, [3-dimensional posi-
tioning], [2-dimensional positioning], or [po-
sitioning not possible], depending on the
signal strength. (Elevation will not be dis-
played in 2-dimensional positioning.)

When the MAP button is pressed, the
[CURRENT LOCATION] screen will appear.
When the PREVIOUS button is pressed,
the [NAVIGATION SETTINGS] screen will
appear.If the vehicle icon does not indicate the correct
location or the direction does not match the
actual road, you can adjust them on the map
screen.
1. Press the SETTING button.
2. Select the
Navigation key on the
[SETTINGS] screen.
INV1721
INV1466
UPDATINGTHE CURRENT
VEHICLE LOCATION AND THE
DIRECTION
11-18
How do I adjust the display?


04.7.6/Z33-N


3. Select the
Adjust Current Location key on
the [NAVIGATION SETTINGS] screen.4. Align the correct location to the cross point
on the map using the joystick, and select the
Set key. The current location will be cor-
rected, and the direction adjustment screen
will appear.5. Adjust the direction using the
and
keys.
The arrow on the display shows the direction of
the vehicle icon.
6. Select the
Set key.
INV2461
INV1724
INV1725
How do I adjust the display?
11-19


04.7.6/Z33-N


INFO:

It is not possible to update the vehicle loca-
tion when the vehicle is moving.

Depending on the driving conditions, the
vehicle icon may not exactly correspond to
the actual location of the vehicle. To verify
position, refer to map books or check actual
landmarks.

If you notice that the system is displaying a
different road from the one the vehicle is
actually traveling, and the vehicle icon does
not go back to the right road after traveling
approximately 6-1/4 miles (10km), update
the vehicle location.You can set the automatic beep sound. (Acti-
vated during automatic rerouting, etc.)
1. Press the SETTING button.
The [SETTINGS] screen will be displayed.
Select the
Navigation key.2. The [NAVIGATION SETTINGS] screen will
be displayed.
Select the
Button Tone/Beep Response key.
INV1726
INV1466
INV1728
SETTINGAUTOMATIC BEEP
SOUND
11-20
How do I adjust the display?


04.7.6/Z33-N
