2005 NISSAN 350Z Navigation Manual

4. The display shows the [AVOID AREA SET-
TING] screen.
Select a key which is not set as an “avoid area”.
INFO:
It is possible to set up to 10areas to avoid.5. The display shows categories which can be
used to set an “avoid area”.
For example, use the
Map key to set an “avoid
area”.
Select the
Map key.
INFO:
For setting with other categories, please refer to
“Expert mode categories” on page 5-2.6. The display shows the map which centers the
area to be set as an “avoid area”.
Use the ZOOM IN or ZOOM OUT button to
adjust the map reduction scale.
INV2449
INV2345
INV1655
How do I use the avoid area feature?
8-3


04.7.6/Z33-N


7. Use the joystick to adjust the location.
INFO:
Area size: Max.5x5miles (8x8km)8. The display shows the keys on the right of the
screen.
Select the
Set key.
INFO:

If you want to avoid the freeway in that area,
select the
key to turn on the green
indicator on the key. (Indicator ON: avoid,
OFF: do not avoid)

When altering the size of the “avoid area”,
select the
Area key. The area size is in-
creased or decreased by three scales.9. The “avoid area” is set, and the grid will be
displayed on the screen.
INFO:
The grid color will be displayed in green or blue.
(Avoid Freeway ON: green, OFF: blue)
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INV1656
INV1657
INV1658
8-4
How do I use the avoid area feature?


04.7.6/Z33-N


10. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.When the stored “avoid area” is selected, it can
be renamed or deleted.
RENAMING THE AVOID AREAS1. Press the SETTING button.
2. Select the
Navigation key.
INV2450
INV1466
SETTINGWITH THE SELECTED
LOCATION KEY
How do I use the avoid area feature?
8-5


04.7.6/Z33-N


3. The display shows the [NAVIGATION SET-
TINGS] screen.
Select the
Avoid Area Setting key.4. The display shows the [AVOID AREA SET-
TING] screen.
Select a key which is set as an “avoid area”.5. Select the
Rename key.
INV2448
INV2451
INV2452
8-6
How do I use the avoid area feature?


04.7.6/Z33-N


6. The display shows the keyboard.
Enter the area name using the keyboard.
When the
Set key is selected, the “avoid area”
is renamed, and the screen returns to the previ-
ous screen.
INFO:
When theBack Space key is selected, the
cursor moves back to the previous letter. When
the
Space key is selected, the cursor proceeds
to make one space.
DELETING THE AVOID AREAS1. Select the
Delete key on the screen in step
5 under “Renaming the avoid areas”.2. Select the
Yes key.
The “avoid area” is deleted.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INFO:
When the
No key is selected, the “avoid area”
will not be deleted, and the screen returns to the
previous screen.
INV2453
INV2454
INV2455
How do I use the avoid area feature?
8-7


04.7.6/Z33-N


3. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.
SETTING WITH THE
Map
KEY
When the stored “avoid area” is selected, it can
be adjusted or deleted.
Press the SETTING button.
Adjusting the stored avoid areas1. Select the
Navigation key.
INV2456
INV1466
8-8
How do I use the avoid area feature?


04.7.6/Z33-N


2. The display shows the [NAVIGATION SET-
TINGS] screen.
Select the
Avoid Area Setting key.3. The display shows the [AVOID AREA SET-
TING] screen.
Select the
Map key of stored “avoid areas”.4. Use the joystick to adjust the location.
INV2448
INV2457
INV1671
How do I use the avoid area feature?
8-9


04.7.6/Z33-N


5. Press the PUSH ENTER button.
The display shows the keys on the right of the
screen.
Select the
Set key.
INFO:

If you want to avoid the freeway in that area,
select the
key to turn on the green
indicator on the key. (Indicator ON: avoid,
OFF: do not avoid)

When altering the size of the avoid area,
select the
Area key. The area size is in-
creased or decreased by three scales.6. The “avoid area” is set, and the grid is
displayed on the screen.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.7. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.
INV1672
INV1673
INV2456
8-10
How do I use the avoid area feature?


04.7.6/Z33-N
