2005 NISSAN 350Z engine

When you use this system, make sure the engine
is running.
NOTE:
If you use the system with the engine not
running (ignition ON or ACC position) for
long periods of time, this may drain the
battery, making it difficult to start the en-
gine.HOW TO OPEN THE LC DISPLAY
CAUTION

Do not place any objects on the in-
strument panel. If you drop any ob-
jects onto the instrument panel or
spill liquid on it, it may result in
system malfunction.

To protect the liquid crystal display,
close it when it is not used.
The liquid crystal display opens when:

the liquid crystal display was open when the
ignition key was turned to OFF position, then
the next time the ignition key is turned to ON
or ACC position.

the button on the cover of the liquid crystaldisplay is pressed with the ignition key in ON
or ACC position.
INFO:
The liquid crystal display may not open if the
power supply had been interrupted due to dis-
connecting the vehicle battery etc.
HOW TO CLOSE THE LC DISPLAYThe liquid crystal display closes when:

the ignition key is turned to OFF position.

the button on the cover of the liquid crystal
display is pressed with the ignition key in ON
or ACC position.
The voice guidance cannot be heard when the
cover is closed.
INI0088
OPENING/CLOSING THE LIQUID
CRYSTAL (LC) DISPLAY4-2
How do I operate the NISSAN Navigation System?


04.7.6/Z33-N


When you turn the ignition key to ACC, the
above warning is displayed on the screen. Read
the warning and select the
I AGREE (English)
or
ENTER (Franc¸ ais) key.
INFO:
If you do not press the PUSH ENTER button, the
system will not proceed to the next step display.
CONFIRMATION OF DESTINATION
OR WAYPOINTWhen the engine is turned off during route
calculation and then turned on, the [CONFIR-
MATION OF DEST./WAYPOINT] screen will be
displayed after the start-up screen.
In the [CONFIRMATION OF DEST./ WAY-
POINT] screen, the following four keys are dis-
played.

To All Destinations

From Next Waypoint

Cancel Guidance

Change (only in Expert Mode)
INFO:
When the PREVIOUS or MAP button is
pressed in this screen, the [Turn by turn] screen
will be displayed.
INV2317
INV1459
START-UP SCREEN
How do I operate the NISSAN Navigation System?
4-17


04.7.6/Z33-N


stretch of straight road or series of curves
with a large radius.
— When the vehicle is traveling in an area with
a grid road system.
— When the vehicle is making consecutive S
curves.
— When the vehicle is at a large Y-shaped
junction.
— When the vehicle is on a loop bridge.
— When the vehicle is on a snow-covered or
unpaved road.
— When the vehicle has made several consecu-
tive turns or zigzags.
— When the vehicle is rotated on a parking lot
turntable while the ignition switch is OFF.
— Immediately after the vehicle is driven out of a
parking garage or underground parking lot.
— When the vehicle has different sizes of tires
or tire chains.
— When the vehicle is moved immediately after
the engine is started.
4-26
How do I operate the NISSAN Navigation System?


04.7.6/Z33-N


1. Press the INFO button.
2. The [MAINTENANCE INFO.] screen will be
displayed.
3. To set the maintenance information for the
Engine Oil or Oil Filter, choose an item using
the joystick and press the PUSH ENTER
button.4. The [ENGINE OIL] screen will be displayed.
5. To reset, select the
RESET key.
6. Set the distance of the maintenance sched-
ule.
To determine the maintenance interval, refer to
the vehicle’s Owner’s Manual.
To automatically display the [MAINTENANCE
INFO.] screen when setting trip distance is
reached, select theDisplay Maintenance Notification
key and press the PUSH ENTER button.
INV1756
INV1750
MAINTENANCE INFORMATION12-2
How do I use the vehicle information?


04.7.6/Z33-N
