2005 NISSAN 350Z Navigation Manual

3. The [BUTTON TONE/BEEP RESPONSE]
screen will be displayed.
When turning on/off the beep sound, select theOn or
Off key.
When the PUSH ENTER button is pressed, the
selected key will be illuminated.
INFO:
Press the MAP button to return to the map.You can alter the display mode.
ADJUSTING THE DISPLAY
BRIGHTNESSYou can choose the best brightness for the
display.
1. Press the SETTING button.
2. Select the
Display key.
INV1729
INV1730
SETTINGTHE DISPLAY MODE
How do I adjust the display?
11-21


04.7.6/Z33-N


3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Brightness/Contrast/Map Background
key.4. Select the
Brightness key.
When the joystick is tilted to the right, the screen
will brighten, and darken when tilted to the left.
INFO:
The screen displayed before pressing the
SETTING button will be displayed as a sample
screen on the [DISPLAY SETTINGS] screen.
ADJUSTING THE DISPLAY
CONTRASTYou can choose the best contrast for the dis-
play.
1. Press the SETTING button.
INV1731
INV1732
11-22
How do I adjust the display?


04.7.6/Z33-N


2. Select the
Display key. 3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Brightness/Contrast/Map Background
key.4. Select the
Contrast key.
When the joystick is tilted to the right, contrast of
the screen will be higher, and will be lower when
tilted to the left.
INV1730
INV1731
INV1735
How do I adjust the display?
11-23


04.7.6/Z33-N


SWITCHING THE DISPLAY COLOR1. Press the SETTING button.
2. Select the
Display key. 3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Brightness/Contrast/Map Background
key.
INV1730
INV1731
11-24
How do I adjust the display?


04.7.6/Z33-N


4. Select the
Map Background key.
The display brightness will be altered.
HOW TO USE THE
(DAY/
NIGHT) BUTTON
1. Press the
button.
2. When the
button is pressed, the
screen will repeatedly switch between normal
lighting and dimmer lighting independently of
turning on or off of illumination.
INV1738
INV1739
How do I adjust the display?
11-25


04.7.6/Z33-N


DISPLAY OFFThe display can be turned off with the following
procedure.
1. Press the SETTING button.
2. Select the
Display key. 3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Display Off key.
The indicator of the [DISPLAY OFF] will turn
green.
INV1730
INV1741
11-26
How do I adjust the display?


04.7.6/Z33-N


4. A comment will be displayed for 5 seconds
and the display will turn off.
To restart the display, press the SETTING
button and select the
Display Off key again.
INFO:

When the INFO and MAP buttons are
pressed with the display turned off, the
screen shows normally, then the display turns
off again.

When the
button is pressed with the
display turned off, the display brightness is
changed when the screen is re-displayed.
SETTING DISPLAY DURATIONYou can set the display duration time.
1. Press the SETTING button.
2. Select the
Display key.
INV1742
INV1730
How do I adjust the display?
11-27


04.7.6/Z33-N


3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Setting Display Duration key.
INFO:
When you finish setting the display duration
time, the display will return to the previous
display automatically.The display uses liquid crystal and should be
handled with care.
WARNING
Never disassemble the display. It has
some areas with extreme high voltage.
Touching it may result in serious per-
sonal injury.CHARACTERISTICS OF LIQUID
CRYSTAL DISPLAY
If the temperature inside the vehicle is espe-
cially low, the display will stay relatively dim or
the movement of the images may be slow.
These conditions are normal; when the tem-
perature rises, the display will function nor-
mally.

You may notice darker or brighter dots in
parts of the display; this is inherent in monitor
displays and is not a malfunction.

You may also notice a remnant of the previ-
ous display image on the screen. This after-
image is inherent in displays and is not
abnormal.INFO:
The screen may become distorted by strong
magnetic fields.
MAINTENANCE OF THE DISPLAY
CAUTION

To clean the display, never use a
rough cloth, alcohol, benzine, thin-
ner, any kind of solvent, or paper
towel with chemical cleaning agent.
They will scratch or deteriorate the
panel.

Do not splash any liquid such as
water or car fragrance on the display.
Contact with liquid will cause the
system to malfunction.
If you need to clean the display screen, use a dry
soft cloth. If additional cleaning is necessary, use
a small amount of neutral detergent with a soft
cloth. Never soak the exterior with water or
detergent.
INV1744
HOW TO HANDLE THE DISPLAY
11-28
How do I adjust the display?


04.7.6/Z33-N
