2005 NISSAN 350Z sat nav

2 How does the NISSAN Navigation System
work?What is a navigation system? ............................................ 2-2
About the navigation system ....................................... 2-2
What is GPS (Global Positioning System)? ................. 2-2
Accuracy of positioning .................................................. 2-2
Positioning adjustment.................................................... 2-3
Receiving signals from GPS satellites ...................... 2-3
Display of GPS information ........................................... 2-3
Detailed map coverage areas (MCA) for the navigation
system ....................................................................................... 2-3
When a gray road or dark green road is displayed on
the map ............................................................................. 2-4


04.7.6/Z33-N


ABOUT THE NAVIGATION SYSTEMThis navigation system combines the data ob-
tained from the vehicle (by gyro sensor) and from
GPS (Global Positioning System) satellites to
calculate the current location of the vehicle. This
position is then displayed on the screen, allow-
ing route guidance to a destination.GPS is a system developed and operated by the
U.S. Government, covering the entire planet.
This navigation system receives three or more
different radio signals from NAVSTAR (GPS
satellites), orbiting the earth 13,049 miles
(21,000 km) above ground. The data from dif-
ferent sets of signals will be trigonometrically
calculated to obtain the position of the vehicle.
INFO:
The tracking center in the U.S. controls signals
transmitted from GPS satellites. This control
sometimes results in reduced accuracy or no
signal received at all in accordance with govern-
ment requirements.
ACCURACY OF POSITIONINGThe color of the GPS Indicator
on the upper
left corner of the screen indicates positioning as
follows:

Green: positioning is possible and accurate

Yellow: positioning is possible but accuracy
is minimal.

Gray: positioning is not possible
INV1441
WHAT IS A NAVIGATION
SYSTEM?WHAT IS GPS (GLOBAL
POSITIONINGSYSTEM)?2-2
How does the NISSAN Navigation System work?


04.7.6/Z33-N


INFO:
For approximately 3 or 4 minutes after system
startup, the GPS indicator
remains gray,
even if accurate positioning is possible.
POSITIONING ADJUSTMENTWhen the system judges that the vehicle posi-
tion information is not accurate based on vehicle
speed and gyro sensor data calculations, the
system will adjust the vehicle position informa-
tion using GPS signals.RECEIVING SIGNALS FROM GPS
SATELLITESSometimes, satellite reception is weak. The fol-
lowing are places where signals tend to be
weak:

Inside tunnels and parking garages

Areas with numerous tall buildings

Under multi-layered highways

In a dense forest
Vehicles in these areas may not receive GPS
signals (Indicator color: gray).INFO:
The antenna for GPS is located on the instru-
ment panel inside the vehicle.Do not place any
objects, especially mobile phones or trans-
ceivers, on the instrument panel. Because
the strength of the GPS signal is approximately
one billionth of that of TV waves; phones and
transceivers will decrease the strength or may
totally disrupt the signals.
DISPLAY OF GPS INFORMATIONThis system displays GPS information.
Please refer to “GPS information display” on
page 11-17.
NOTE:
Directional guidance provided by the navi-
gation system does not take carpool lane
driving into consideration, especially when
carpool lanes are separated from other
road lanes.This system is designed to help you reach your
destination, and also performs other functions as
outlined in this manual. However, you, the driver,
must use the system safely and properly. Infor-
mation concerning road conditions, traffic signs
and the availability of services may not always be
up-to-date. The system is not a substitute for
safe, proper, and legal driving.
Map data covers select metropolitan areas in the
United States.
Map data is available on map DVD-ROM. For
information about map DVD-ROMs, contact a
NISSAN dealer or call the NISSAN NAVIGA-
TION SYSTEM HELPDESK at 1-800-
NISSAN-1 (1-800-647-7261) for U.S., and at
1-800-777-0325 for CANADA.
Map data includes 2 types of areas: “Detailed
coverage areas” providing all detailed road data
and other areas showing “Main roads only”.
NOTE:
Detailed map data is not available in many
areas and is generally limited to select
major metropolitan areas.
For information on which metropolitan areas are
in detailed coverage areas, please refer to the
NISSAN Navigation System Software Booklet
(included). When you purchase an updated map
DETAILED MAP COVERAGE
AREAS (MCA) FOR THE
NAVIGATION SYSTEM
How does the NISSAN Navigation System work?
2-3


04.7.6/Z33-N


The main feature of the NISSAN Navigation
System is Visual and Audio Route Guidance in
selected detailed map coverage areas. Utilizing
a network of GPS (Global Positioning System)
satellites, the NISSAN Navigation System tracks
your location on the map and directs you where
you want to go.
Once you program a destination covered by a
detailed map, the NISSAN Navigation System
will determine a route from your current location
to your destination. The moving map display and
turn-by-turn voice commands help the driver
determine upcoming turns.
This feature can be especially helpful in finding
unfamiliar locations or businesses. The system
may be unable to set a destination and/or cal-
culate distance when a destination is outside a
detailed map coverage area. Additionally, audio
route guidance may not be available if the des-
tination is outside a detailed map coverage area.
For more information on how to program a
destination, please refer to section 5.The NISSAN Navigation System offers an exten-
sive Point of Interest directory in detailed map
coverage areas. This directory includes a wide
variety of destinations ranging from gas stations,
ATMs, and restaurants to casinos, ski resorts,
shopping centers and businesses. By accessing
the Point of Interest directory, you can search for
addresses and phone numbers for a destination,
and with a press of a button, the NISSAN
Navigation System will calculate a route to the
destination.
The Point of Interest directory offers many uses.
For example, the directory can be sorted by the
various types of restaurants near your current
location. If you need an ATM or gas station, the
NISSAN Navigation System can point you to the
closest one or the closest one of your favorite
brand.
For more information on how to use the Point of
Interest directory, please refer to section 6.Using the Address Book feature, you will have
the ability to store up to 50locations in detailed
map coverage areas into a personal directory.
This is especially useful for frequently visited
locations, such as your clients, relatives, or
friends. The Address Book feature will provide
you with easy access to frequently visited loca-
tions when setting them as your destination.
For more information on how to use your Ad-
dress Book, please refer to section 7.ROUTE GUIDANCE
POINT OF INTEREST (POI)
DIRECTORYADDRESS BOOK3-2
What features are available on the NISSAN Navigation System?


04.7.6/Z33-N


The following GPS information will be displayed
on the screen: latitude, longitude, altitude, signal
reception, and satellite locations.
1. Press the SETTING button.
2. Select the
Navigation key on the [SET-
TINGS] screen.3. Select the
GPS Information key.
GPS information will be displayed.
INV1466
INV1720
GPS INFORMATION DISPLAY
How do I adjust the display?
11-17


04.7.6/Z33-N


INFO:

The satellite with a strong enough signal will
be indicated in green.

The display will read, [3-dimensional posi-
tioning], [2-dimensional positioning], or [po-
sitioning not possible], depending on the
signal strength. (Elevation will not be dis-
played in 2-dimensional positioning.)

When the MAP button is pressed, the
[CURRENT LOCATION] screen will appear.
When the PREVIOUS button is pressed,
the [NAVIGATION SETTINGS] screen will
appear.If the vehicle icon does not indicate the correct
location or the direction does not match the
actual road, you can adjust them on the map
screen.
1. Press the SETTING button.
2. Select the
Navigation key on the
[SETTINGS] screen.
INV1721
INV1466
UPDATINGTHE CURRENT
VEHICLE LOCATION AND THE
DIRECTION
11-18
How do I adjust the display?


04.7.6/Z33-N
