Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf)

d. w/ Smart key system:
Connect the connector.
Fig. 121: Connecting Connector

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
30.INSTALL REAR DOOR INSIDE HANDLE COVER
a. Install the cover with the bolt.
Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf)

Part No. 08833-00070, THREE BOND 1324 or equivalent
c. w/o Door closer:
Using a T30 Torx° wrench, install the door lock with the 3 screws.
Torque: 5.5 N.m (56 kgf.cm, 44 in..lbf)
d. w/ Door closer:
Using a T30 Torx° wrench, install the door lock with the 4 screws.
Torque: 5.5 N.m (56 kgf.cm, 44 in..lbf)
e. Connect the door lock connector.

b. Install the quarter window glass in the direction indicated by the arrow mark in the illustration.
Fig. 125: Installing Quarter Window Glass

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
33.INSTALL REAR DOOR WINDOW GUIDE SUB-ASSY FRONT LH
a. Instal the guide with the 2 bolts.
Torque: 8.0 N.m (82 kgf.cm, 71 in..lbf)

Fig. 127: Installing Power Window Regulator Motor Assy LH Rear
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
b. Using a T25 Torx° driver, install the motor with the 3 screws.
Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf)

<0029004c004a0011000300140015001c001d0003002c0051005600570044004f004f004c0051004a00030035004800440055000300270052005200550003003a004c005100470052005a000300350048004a0058004f004400570052005500030036005800
45[-Assy LH
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
b. Install the window regulator with the 4 bolts.
Torque: 8.0 N.m (82 kgf.cm, 71 in..lbf)
c. Connect the window regulator connector.

Fig. 130: Connecting Window Regulator Connector
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
36.INSTALL REAR DOOR GLASS SUB-ASSY LH
a. Install the glass with the 2 nuts.
Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf)

Fig. 136: Installing Rivet
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
38.INSTALL REAR DOOR WINDOW DIVISION BAR SUB-ASSY LH
a. Install the division bar with the 2 nuts and bolt.
Torque: 8.0 N.m (82 kgf.cm, 71 in..lbf)
