2003 FIAT PALIO India Version Owners Manual

Specially designed for petrol and diesel en-
gines, the
VS MAXproducts guarantee fast,
complete engine lubrication and excellent
protection from wear.
GENERAL
PERFORMANCE
DETERIORATION
STANDARD OIL
IDEAL OIL
DISTANCE TRAVELLED
VS MAX
GENERAL PERFORMANCE
DETERIORATIONYOUR CAR
HAS CHOSEN VS
MAX
VS MAXis the result of combining tradition
with the experience of the A
FL Group lab-
oratories, which has been built up over the
years by experimental research on the
VS
line products. Its formula places it at the top
of the mineral. multi-grade oil classification.
Multi-purpose additives combined with se-
lect mineral bases ensure complete engine
protection and limit the oxidation processes
on the lubricant, and wear on the more del-
icate mechanical parts of the engine.
These characteristics are particularly im-
portant when driving the vehicle around
town where the lubricant is constantly un-
der stress due to continual stopping and
starting.
P4E02076
144-152 03/03/2003 07:30 PM Page 152

FUEL CAPACITY (litres)
COLD TYRES PRESSURE [bar (kg/cm2) / lb/sq. in (P.S.I)]
ENGINE OIL CAPACITY
Print no.AS/STA 50167-03/2003 - 4thedition - Printed in India
Coordinamento Editoriale Satiz - Torino
24 HOURS SERVICE CALL - 9628 290 260
This single response number is available in 9 cities.*
AHMEDABAD - BANGALORE - KOLKATA - CHENNAI - DELHI - HYDERABAD - MUMBAI -
PUNE - LUCKNOW
* If you are not in, but near any of the above cities; Dial city code followed by the single response number
For further information about Fiat Service Network please refer 24 Hours Service AssistanceBooklet provided.
1.21.6 1.9-
litres kg litres kg litres kg
Oil sump and filter 3.05 2.75 3.88 3.5 4 3.3
Do not disperse used oil in the environment
1.21.6 1.9
Fuel tank 47 47 47
Reserve 5.5 - 7.5 5.5 - 7.5 5.5 - 7.5
Fill petrol run cars only with unleaded petrol with a minimum octane number of 87.
Tyre Average load Full load Spare
Front Rear Front Rear wheel
1.2EL-ELX165/80 R13 1.93/28.00 1.93/28.00 2.24/32.49 2.24/32.49 2.24/32.49
1.6 GTX175/65 R14 1.93/28.00 1.93/28.00 2.24/32.49 2.24/32.49 2.24/32.49
1.9 DEL-ELX165/80 R13 2.1 1.9 2.2 2.2 2.2
0.3 bar should be added to the values given if the pressure is measured while the tyre is hot.
