2002 JEEP LIBERTY Workshop Manual

Fig. 34 RIGHT FRONT BODY, LHD
8Wa - 91 - 46 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 35 LEFT FRONT BODY, LHD
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-47
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 36 RIGHT FRONT BODY, LHD
8Wa - 91 - 48 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 37 INSTRUMENT PANEL, RHD
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-49
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 38 LEFT FRONT BODY, RHD
Fig. 39 RIGHT FRONT BODY, RHD
8Wa - 91 - 50 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 40 RIGHT FRONT BODY, RHD
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-51
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 41 FRONT DOORS
8Wa - 91 - 52 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 42 REAR DOOR
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-53
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
