EXTERIOR HANDLE
REMOVAL
(1) Remove the trim panel and waterdam. (Refer
to 23 - BODY/SWING GATE/TRIM PANEL -
REMOVAL)
(2) Disconnect the lock switch and flip-up glass
release electrical connectors.
(3) Unclip the threaded clips and disconnect the
actuator rods. (Fig. 2)
(4) Remove the screws.
(5) Remove the nuts and remove the handle.
INSTALLATION
(1) Install the handle and hold tightly against the
gate and support bracket.
(2) Install the nuts and tighten to 6 N´m (55 in.
lbs.).
(3) Install the screws.
(4) Connect the actuator rods and electrical con-
nectors.
(5) Install the trim panel and waterdam. (Refer to
23 - BODY/SWING GATE/TRIM PANEL - INSTAL-
LATION)
FLIP-UP GLASS
REMOVAL
(1) Open the flip-up glass and disconnect the elec-
trical connectors.(2) Remove the support cylinders. (Refer to 23 -
BODY/SWING GATE/FLIP-UP GLASS SUPPORT
CYLINDER - REMOVAL)
(3) Open the glass to the full travel with the sup-
port cylinders off.
(4) Remove the bolts and remove the glass. (Fig. 3)
INSTALLATION
(1) Install the flip-up glass and install the hinge
bolts.
(2) Install the support cylinders. (Refer to 23 -
BODY/SWING GATE/FLIP-UP GLASS SUPPORT
CYLINDER - INSTALLATION)
(3) Connect the electrical connectors.
(4) Adjust flip-up glass fit if necessary and tighten
the hinge bolts to 7 N´m (60 in. lbs.). (Refer to 23 -
BODY/BODY STRUCTURE/GAP AND FLUSH -
SPECIFICATIONS)
FLIP-UP GLASS LATCH
REMOVAL
(1) Remove the trim panel. (Refer to 23 - BODY/
SWING GATE/TRIM PANEL - REMOVAL)
(2) Disconnect the electrical connectors. (Fig. 4)
(3) Using a trim stick C-4755 or equivalent, mark
the location of the latch assembly for installation.
(4) Remove the nuts and remove the latch assem-
bly.
INSTALLATION
(1) Install the latch assembly.
Fig. 2 EXTERIOR HANDLE
1 - LOCK CYLINDER SCREW
2 - LATCH ACTUATOR ROD CONNECTOR
3 - EXTERIOR HANDLE
4 - NUTS (2)
5 - SCREWS (2)
Fig. 3 FLIP-UP GLASS
1 - BOLTS (4)
2 - HINGE MOUNTING HOLES
3 - DEFROSTER WIRE HARNESS
4 - DEFROSTER ELECTRICAL CONNECTOR
5 - FLIPPER GLASS
23 - 136 SWING GATEKJ

(2) Install the nuts and tighten to 12 N´m (9 ft.
lbs.).
(3) Connect the electrical connectors.
(4) Install the trim panel. (Refer to 23 - BODY/
SWING GATE/TRIM PANEL - INSTALLATION)
(5) Adjust the latch to achieve the best glass fit.
(Refer to 23 - BODY/BODY STRUCTURE/GAP AND
FLUSH - SPECIFICATIONS)
HINGE
REMOVAL
(1) Remove the swing gate. (Refer to 23 - BODY/
SWING GATE/SWING GATE - REMOVAL)
(2) Remove the bolts and remove the hinges.
INSTALLATION
(1) Install the hinges.
(2) Install the bolts and tighten to 31 N´m (23 ft.
lbs.).
(3) Install the swing gate. (Refer to 23 - BODY/
SWING GATE/ SWING GATE - INSTALLATION)
LATCH
REMOVAL
(1) Remove the trim panel and waterdam. (Refer
to 23 - BODY/SWING GATE/TRIM PANEL -
REMOVAL)
(2) Disconnect the electrical connector and actua-
tor rod at the threaded clip. (Fig. 5)(3) Remove the screws and remove the latch.
INSTALLATION
(1) Connect the electrical connector and install the
latch.
(2) Install the screws and tighten to 11 N´m (8 ft.
lbs.).
(3) Connect the actuator rod.
(4) Install the trim panel and waterdam. (Refer to
23 - BODY/SWING GATE/TRIM PANEL - INSTAL-
LATION)
LATCH STRIKER
REMOVAL
(1) Open the gate and remove the screws attaching
the striker to the d-pillar.
INSTALLATION
(1) Install the striker and install the nuts.
(2) Tighten the nuts to 28 N´m (21 ft. lbs.).
(3) Adjust the swing gate as necessary. (Refer to
23 - BODY/BODY STRUCTURE/GAP AND FLUSH -
SPECIFICATIONS)
LOCK CYLINDER
REMOVAL
(1) Remove the exterior handle. (Refer to 23 -
BODY/SWING GATE/EXTERIOR HANDLE -
REMOVAL)
Fig. 4 FLIP-UP GLASS LATCH
1 - NUTS (2)
2 - ELECTRICAL CONNECTOR
3 - SWING GATE
4 - ELECTRICAL CONNECTOR
5 - FLIP-UP GLASS LATCHFig. 5 LATCH
1 - SWING GATE
2 - LATCH ASSEMBLY
3 - ELECTRICAL CONNECTOR
4 - SCREWS
KJSWING GATE 23 - 137
FLIP-UP GLASS LATCH (Continued)

(2) Remove the clip and remove the lock cylinder
switch.
(3) Remove the screw and remove the lock cylin-
der. (Fig. 6)
INSTALLATION
(1) Install the lock cylinder.
(2) Install the screw and tighten to 6 N´m (50 in.
lbs.).
(3) Install the lock cylinder switch and retaining
clip.
(4) Install the exterior handle. (Refer to 23 -
BODY/SWING GATE/EXTERIOR HANDLE -
INSTALLATION)
SWING GATE
REMOVAL
(1) Remove the spare tire. (Refer to 22 - TIRES/
WHEELS/TIRES/SPARE TIRE - REMOVAL)
(2) Remove the quarter trim panel. (Refer to 23 -
BODY/INTERIOR/QUARTER TRIM PANEL -
REMOVAL)
(3) Support the swing gate with a suitable lifting
device.
(4) Disconnect the wire harness.(5) Disconnect the check strap from the d-pillar.
(Refer to 23 - BODY/SWING GATE/CHECK STRAP -
REMOVAL)
(6) Remove the bolts and remove the swing gate.
INSTALLATION
(1) Install the swing gate and install the bolts.
(2) Tighten the bolts to 31 N´m (23 ft. lbs.).
(3) Adjust the swing gate as needed adding 4 mm
on the right side to compensate for sag after the
spare tire is installed. (Refer to 23 - BODY/BODY
STRUCTURE/GAP AND FLUSH - SPECIFICA-
TIONS)
(4) Connect the wire harness electrical connector.
(5) Connect the check strap. (Refer to 23 - BODY/
SWING GATE/CHECK STRAP - INSTALLATION)
(6) Install the quarter trim panel. (Refer to 23 -
BODY/INTERIOR/QUARTER TRIM PANEL -
INSTALLATION)
(7) Install the spare tire. (Refer to 22 - TIRES/
WHEELS/TIRES/SPARE TIRE - INSTALLATION)
TRIM PANEL
REMOVAL
(1) Using a trim stick C-4755 or equivalent,
release the push pin fasteners. (Fig. 7)
(2) Lift trim panel up off of the upper trim panel
clips
INSTALLATION
(1) Position the trim panel and seat the upper
clips.
(2) Fully seat the lower trim panel clips
Fig. 6 LOCK CYLINDER
1 - SCREW
2 - LOCK CYLINDER
3 - EXTERIOR HANDLE
Fig. 7 SWING GATE TRIM PANEL
1 - TRIM PANEL
2 - UPPER TRIM PANEL CLIPS
3 - UPPER TRIM CLIP HOLES
4 - TRIM PANEL LOCATOR HOLES
5 - SWING GATE LOCATOR PINS
6 - PUSH IN FASTENERS
23 - 138 SWING GATEKJ
LOCK CYLINDER (Continued)

LATCH - ACCESS PANEL
DESCRIPTION
This panel provides access to the gate latch if gate
power fails. The gate can be unlocked by reaching in
and pushing the lock lever down.
REMOVAL
(1) Using a trim stick C-4755 or equivalent,
remove the access panel.
INSTALLATION
(1) Position and install the access panel.
FLIP-UP GLASS SUPPORT
CYLINDER
REMOVAL
(1) Open the flip-up glass and support.
(2) Release the upper and lower clips.
(3) Remove the support cylinder.
INSTALLATION
(1) Install the support cylinder over the ball studs
with the thin end connected to the glass.
(2) Install the retaining clips and remove the sup-
port from the flip-up glass.
KJSWING GATE 23 - 139
