2002 JEEP LIBERTY Workshop Manual

(3) Place the strands of wire overlapping each
other inside of the splice clip (Fig. 14).
(4) Using crimping tool, Mopar p/n 05019912AA,
crimp the splice clip and wires together (Fig. 15).
(5) Solder the connection together using rosin core
type solder only (Fig. 16).CAUTION: DO NOT USE ACID CORE SOLDER.
(6) Center the heat shrink tubing over the joint
and heat using a heat gun. Heat the joint until the
tubing is tightly sealed and sealant comes out of both
ends of the tubing (Fig. 17).
Fig. 14 SPLICE BAND
1 - SPLICE BAND
Fig. 15 CRIMPING TOOL
1 - CRIMPING TOOL
Fig. 16 SOLDER SPLICE
1 - SOLDER
2 - SPLICE BAND
3 - SOLDERING IRON
Fig. 17 HEAT SHRINK TUBE
1 - SEALANT
2 - HEAT SHRINK TUBE
8Wa - 01 - 14 8W-01 WIRING DIAGRAM INFORMATIONKJ
WIRE (Continued)

8W-02 COMPONENT INDEX
Component Page
A/C Compressor Clutch Relay........... 8Wa-42
A/C Compressor Clutch................ 8Wa-42
A/C-Heater Control................... 8Wa-42
A/C High Pressure Switch.............. 8Wa-42
A/C Low Pressure Switch............... 8Wa-42
A/C Pressure Transducer............... 8Wa-42
Accelerator Pedal Position Sensor........ 8Wa-30
Airbag Control Module................. 8Wa-43
Ambient Temperature Sensor............ 8Wa-45
Antenna Module...................... 8Wa-47
Antenna............................ 8Wa-47
Ash Receiver Lamp................... 8Wa-44
Auto Shut Down Relay................. 8Wa-30
Back-Up Lamp Switch................. 8Wa-31
Battery Temperature Sensor......... 8Wa-20, 30
Battery............................. 8Wa-20
Blend Door Actuator................... 8Wa-42
Blower Motor Relay................... 8Wa-42
Blower Motor Resistor Block............ 8Wa-42
Blower Motor........................ 8Wa-42
Body Control Module.................. 8Wa-45
Boost Pressure Sensor................. 8Wa-30
Brake Lamp Switch................... 8Wa-33
Brake Pressure Switch................. 8Wa-35
Cabin Heater Relay................... 8Wa-42
Cabin Heater........................ 8Wa-42
Camshaft Position Sensor.............. 8Wa-30
Capacitor........................... 8Wa-30
Cargo Lamp......................... 8Wa-44
CD Changer......................... 8Wa-47
Center High Mounted Stop Lamp........ 8Wa-51
Cigar Lighter........................ 8Wa-41
Circuit Breakers...................... 8Wa-12
Clockspring................. 8Wa-33, 41, 43, 47
Clutch Interlock Switch................ 8Wa-21
Clutch Switch Override Relay........... 8Wa-21
Coil On Plugs........................ 8Wa-30
Coil Rail............................ 8Wa-30
Compass Mini-Trip Computer........... 8Wa-49
Controller Antilock Brake.............. 8Wa-35
Courtesy Lamps...................... 8Wa-44
Crankshaft Position Sensor............. 8Wa-30
Curtain Airbags...................... 8Wa-43
Cylinder Lock Switches................ 8Wa-61
Data Link Connector.................. 8Wa-18
Daytime Running Lamp Relay........... 8Wa-50
Defogger Relay....................... 8Wa-48
Diagnostic Junction Port............... 8Wa-18
Dome Lamp......................... 8Wa-44
Door Ajar Switches.................... 8Wa-45
Door Lock Motor/Ajar Switches.......... 8Wa-61
Door Lock Relay...................... 8Wa-61Component Page
Door Lock Switches................... 8Wa-61
Door Speakers....................... 8Wa-47
Driver Airbag Squib 1................. 8Wa-43
Driver Airbag Squib 2................. 8Wa-43
Driver Door Unlock Relay.............. 8Wa-61
Driver Seat Belt Switch................ 8Wa-40
Driver Seat Belt Tensioner.............. 8Wa-43
EGR Solenoid........................ 8Wa-30
Electric Brake Provision................ 8Wa-54
Engine Control Module................ 8Wa-30
Engine Coolant Level Sensor............ 8Wa-40
Engine Coolant Temperature Sensor...... 8Wa-30
Engine Oil Pressure Sensor............. 8Wa-30
EVAP/Purge Solenoid.................. 8Wa-30
Flip-Up Glass Release Motor............ 8Wa-61
Flip-Up Glass Release Switch........... 8Wa-61
Fog Lamps.......................... 8Wa-50
Front Fog Lamp Relay................. 8Wa-50
Front Wiper Motor.................... 8Wa-53
Fuel Heater Relay.................... 8Wa-30
Fuel Heater......................... 8Wa-30
Fuel Injectors........................ 8Wa-30
Fuel Pressure Sensor.................. 8Wa-30
Fuel Pressure Solenoid................. 8Wa-30
Fuel Pump Module.................... 8Wa-30
Fuel Pump Relay..................... 8Wa-30
Fuses........................... 8Wa-10, 12
Fusible Link......................... 8Wa-20
Grounds............................ 8Wa-15
Generator........................... 8Wa-20
Glow Plugs.......................... 8Wa-30
Hazard Switch/Combination Flasher...... 8Wa-52
Headlamp Leveling Switch.............. 8Wa-50
Headlamps.......................... 8Wa-50
Heated Seats........................ 8Wa-63
High Beam Relay..................... 8Wa-50
Horns.............................. 8Wa-41
Hood Ajar Switch..................... 8Wa-45
Idle Air Control Motor................. 8Wa-30
Ignition Switch....................... 8Wa-10
Impact Sensors....................... 8Wa-43
Input Speed Sensor................... 8Wa-31
Instrument Cluster................... 8Wa-40
Instrument Panel Speakers............. 8Wa-47
Intake Air Temperature Sensor.......... 8Wa-30
Intrusion Sensor..................... 8Wa-49
Junction Block....................... 8Wa-12
Knock Sensor........................ 8Wa-30
Leak Detection Pump.................. 8Wa-30
Leveling Motors...................... 8Wa-50
License Lamp........................ 8Wa-51
Line Pressure Sensor.................. 8Wa-31
KJ8W-02 COMPONENT INDEX8Wa-02-1

Component Page
Low Beam Relay..................... 8Wa-50
Manifold Absolute Pressure Sensor....... 8Wa-30
Multi-Function Switch........... 8Wa-50, 52, 53
Output Speed Sensor.................. 8Wa-31
Overhead Map/Reading Lamp........... 8Wa-44
Oxygen Sensors...................... 8Wa-30
Oxygen Sensor Downstream Relay........ 8Wa-30
Park Brake Switch.................... 8Wa-40
Park Lamp Relay..................... 8Wa-50
Park/Turn Signal Lamps............ 8Wa-50, 52
Passenger Airbag..................... 8Wa-43
Passenger Door Unlock Relay........... 8Wa-61
Passenger Seat Belt Switch............. 8Wa-40
Position Lamps...................... 8Wa-50
Power Distribution Center.............. 8Wa-10
Power Mirrors....................... 8Wa-62
Power Outlet........................ 8Wa-41
Power Seats......................... 8Wa-63
Power Steering Pressure Switch......... 8Wa-30
Power Windows...................... 8Wa-60
Powertrain Control Module............. 8Wa-30
Radiator Fans....................... 8Wa-30
Radio Choke......................... 8Wa-47
Radio.............................. 8Wa-47
Rear Fog Lamp Relay................. 8Wa-51
Rear Power Outlet.................... 8Wa-41
Rear Power Window Switch............. 8Wa-60
Rear Wheel Speed Sensor.............. 8Wa-35
Rear Window Defogger................. 8Wa-48
Rear Wiper Motor.................... 8Wa-53
Red Brake Warning Indicator Switch...... 8Wa-40Component Page
Remote Keyless Entry Module........... 8Wa-45
Remote Radio Switches................ 8Wa-47
Splices............................. 8Wa-10
Sentry Key Immobilizer Module.......... 8Wa-39
Shifter Assembly..................... 8Wa-31
Side Impact Airbag Control Modules...... 8Wa-43
Side Marker Lamps................ 8Wa-50, 52
Side Repeater Lamps............... 8Wa-50, 52
Siren.............................. 8Wa-49
Speed Control Servo................... 8Wa-33
Speed Control Switches................ 8Wa-33
Starter Motor Relay................... 8Wa-21
Starter Motor........................ 8Wa-21
Sunroof............................ 8Wa-64
Tail/Stop Lamps...................... 8Wa-51
Tailgate Cylinder Lock Switch........... 8Wa-61
Tailgate Flip-Up Ajar Switch............ 8Wa-61
Tailgate Lock Motor/Ajar Switch......... 8Wa-61
Throttle Position Sensor................ 8Wa-30
Trailer Tow.......................... 8Wa-54
Transfer Case Position Sensor........ 8Wa-30, 31
Transmission Control Module........... 8Wa-31
Transmission Control Relay............. 8Wa-31
Transmission Solenoid/TRS Assembly..... 8Wa-31
Visor/Vanity Lamps................... 8Wa-44
Washer Fluid Level Switch............. 8Wa-53
Washer Pump........................ 8Wa-53
Water In Fuel Sensor.................. 8Wa-30
Wheel Speed Sensors.................. 8Wa-35
Wiper High/Low Relay................. 8Wa-53
KJ8W-02 COMPONENT INDEX8Wa-02-1

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch Relay . . . 8Wa-10-11, 13, 22,
26
A/C Compressor Clutch.............. 8Wa-10-26
Auto Shut Down Relay...... 8Wa-10-10, 12, 19, 22
Battery....................... 8Wa-10-10, 12
Blower Motor Relay........... 8Wa-10-10, 12, 14
Blower Motor..................... 8Wa-10-14
Body Control Module................ 8Wa-10-23
Cabin Heater Relay........... 8Wa-10-13, 22, 26
Cabin Heater...................... 8Wa-10-26
Camshaft Position Sensor............ 8Wa-10-22
Capacitor...................... 8Wa-10-19, 21
Circuit Breaker No. 1............... 8Wa-10-16
Circuit Breaker No. 3 (JB)........... 8Wa-10-27
Clutch Interlock Switch.............. 8Wa-10-28
Clutch Switch Override Relay......... 8Wa-10-28
Coil On Plug No. 1................. 8Wa-10-21
Coil On Plug No. 2................. 8Wa-10-21
Coil On Plug No. 3................. 8Wa-10-21
Coil On Plug No. 4................. 8Wa-10-21
Coil On Plug No. 5................. 8Wa-10-21
Coil On Plug No. 6................. 8Wa-10-21
Coil Rail......................... 8Wa-10-19
Controller Antilock Brake . 8Wa-10-10, 11, 12, 13, 14
Daytime Running Lamp Relay........ 8Wa-10-16
Defogger Relay.................... 8Wa-10-24
EGR Solenoid..................... 8Wa-10-22
Engine Control Module.............. 8Wa-10-22
Fuel Heater Relay............... 8Wa-10-13, 18
Fuel Heater....................... 8Wa-10-18
Fuel Injector No. 1................. 8Wa-10-20
Fuel Injector No. 2................. 8Wa-10-20
Fuel Injector No. 3................. 8Wa-10-20
Fuel Injector No. 4................. 8Wa-10-20
Fuel Injector No. 5................. 8Wa-10-20
Fuel Injector No. 6................. 8Wa-10-20
Fuel Pressure Solenoid.............. 8Wa-10-22
Fuel Pump Module................. 8Wa-10-26
Fuel Pump Relay................ 8Wa-10-11, 26
Fuse 1.................. 8Wa-10-10, 12, 14, 25
Fuse 2.................. 8Wa-10-10, 12, 14, 15
Fuse 3.................. 8Wa-10-10, 12, 16, 25
Fuse 4..................... 8Wa-10-10, 12, 14
Fuse 5.................. 8Wa-10-10, 12, 17, 18
Fuse 6............... 8Wa-10-10, 12, 19, 22, 24
Fuse 7..................... 8Wa-10-10, 12, 15
Fuse 8..................... 8Wa-10-10, 12, 23
Fuse 9.................. 8Wa-10-10, 12, 13, 24
Fuse 10.............. 8Wa-10-10, 12, 13, 15, 18
Fuse 11.................... 8Wa-10-13, 15, 18
Fuse 12............ 8Wa-10-10, 11, 13, 15, 17, 18
Fuse 13............... 8Wa-10-10, 11, 13, 23, 27
Fuse 14.................... 8Wa-10-11, 13, 23
Fuse 15................. 8Wa-10-11, 13, 25, 27Component Page
Fuse 16................. 8Wa-10-19, 20, 22, 24
Fuse 17.......................... 8Wa-10-24
Fuse 18.......................... 8Wa-10-24
Fuse 19.................... 8Wa-10-11, 13, 24
Fuse 20.......................... 8Wa-10-27
Fuse 21.................... 8Wa-10-11, 13, 26
Fuse 22.......................... 8Wa-10-27
Fuse 24.................... 8Wa-10-11, 26, 29
Fuse 25................. 8Wa-10-11, 13, 14, 29
Fuse 26................. 8Wa-10-12, 19, 20, 22
Fuse 28.......................... 8Wa-10-28
Fuse 29.......................... 8Wa-10-15
Fuse 30.......................... 8Wa-10-24
Fuse 31.......................... 8Wa-10-27
Fuse 32.......................... 8Wa-10-27
Fuse 33.......................... 8Wa-10-16
Fuse 34.......................... 8Wa-10-15
Fuse 36.......................... 8Wa-10-27
Fuse 37.......................... 8Wa-10-29
Fuse 38.......................... 8Wa-10-29
Fuse 39.......................... 8Wa-10-29
Fusible Link................... 8Wa-10-10, 12
G202............................ 8Wa-10-23
Generator.................. 8Wa-10-10, 12, 22
Glow Plug Assembly................ 8Wa-10-18
Glow Plug Relay No. 1......... 8Wa-10-13, 18, 22
Glow Plug Relay No. 2......... 8Wa-10-13, 18, 22
High Beam Relay.................. 8Wa-10-16
Horn Relay....................... 8Wa-10-25
Ignition Switch . . . 8Wa-10-10, 11, 12, 13, 23, 27, 29
Junction Block . . . 8Wa-10-10, 11, 12, 13, 15, 16, 24,
25, 27, 29
Low Beam Relay................... 8Wa-10-25
Oxygen Sensor 1/1 Upstream......... 8Wa-10-19
Oxygen Sensor 1/2 Downstream.... 8Wa-10-19, 20
Oxygen Sensor 2/1 Upstream......... 8Wa-10-19
Oxygen Sensor 2/2 Downstream....... 8Wa-10-20
Oxygen Sensor Downstream Relay . . 8Wa-10-19, 20
Park Lamp Relay.................. 8Wa-10-16
Power Distribution Center . 8Wa-10-2, 3, 10, 11, 12,
13, 14, 15, 16, 17, 18, 19, 22, 23, 24, 25, 26, 27, 28
Power Window Master Switch......... 8Wa-10-29
Powertrain Control Module . . 8Wa-10-11, 19, 26, 28
Radiator Fan Relay.............. 8Wa-10-10, 14
Starter Motor Relay.............. 8Wa-10-23, 28
Starter Motor..................... 8Wa-10-23
Trailer Tow Circuit Breaker..... 8Wa-10-10, 12, 15
Trailer Tow Circuit Breaker.......... 8Wa-10-15
Trailer Tow Connector............... 8Wa-10-15
Trailer Tow Relay.................. 8Wa-10-15
Transmission Control Module . . . 8Wa-10-10, 17, 28
Transmission Control Relay........ 8Wa-10-10, 17
Transmission Solenoid/TRS Assembly . . . 8Wa-10-17
KJ8W-10 POWER DISTRIBUTION8Wa-10-1
