2001 TOYOTA AVALON torque

RS0LP-01
H11910
LH Side:
RH Side: RS-66
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY (Floor Shift)
1586 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
NOTICE:

Never use SRS parts from another vehicle. When re-
placing parts, replace them with new parts.

Never reuse the airbag sensor assembly involved in
a collision when the airbag has deployed.

Never repair a sensor in order to reuse it.
HINT:
For step 2 to 9, refer to page BO-97.
1. INSTALL AIRBAG SENSOR ASSEMBLY
(a) Using a torx wrench, install the airbag sensor assembly
with the 4 screws.
Torx wrench: T40 (Part No.09042-00020 or locally
manufactured tool)
Torque: 20 N´m (205 kgf´cm, 15 ft´lbf)
(b) Connect the airbag sensor connectors.
NOTICE:

Connection of the connector is done after the sensor
assembly has been installed.

Make sure the sensor assembly is installed with the
specified torque.

If the sensor assembly has been dropped, or there are
cracks, dents or other defects in the case, bracket or
connector, replace the sensor assembly with a new
one.

When installing the senor assembly, take care that
the SRS wiring does not interfere with other parts and
is not pinched between other parts.

After installing, shake the sensor assembly to check
that there is no looseness.
2. INSTALL FRONT CONSOLE
3. INSTALL REAR CONSOLE BOX
4. INSTALL UPPER CONSOLE PANEL
5. INSTALL LOWER PANEL
6. INSTALL NO. 2 UNDER COVER
7. INSTALL NO. 1 LOWER PANEL
8. INSTALL COWL SIDE TRIM LH
9. INSTALL FRONT DOOR SCUFF PLATE LH

RS0ER-02
H11911
N´m (kgf´cm, ft´lbf): Specified torqueFront Airbag Sensor RH
Front Airbag Sensor LH
Head Light RH
Head Light LH
20 (205, 15)
20 (205, 15)
20 (205, 15)
20 (205, 15)
RS-72
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1592 Author
: Date
:
2001 AVALON (RM808U)
FRONT AIRBAG SENSOR
COMPONENTS

H11912H11913H11907
LH:
RH:
RS0LW-01
H11914
LH:
RH: RS-76
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1596 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
1. INSTALL FRONT AIRBAG SENSOR LH AND RH
(a) Install the front airbag sensors with the 4 bolts.
Torque: 20 N´m (205 kgf´cm, 15 ft´lbf)
NOTICE:

Connection of the connector is done after the sensor
assembly has been installed.

Make sure the sensor is installed with the specified
torque.

If the sensor has been dropped, or there are cracks,
dents or other defects in the case, brackets or con-
nector, replace the removed sensor with a new one.

The front sensor is equipped with an electrical con-
nection check mechanism. Be sure to lock this mech-
anism securely when connecting the connector. If the
connector is not securely locked, a malfunction code
will be detected by the diagnostic system.
HINT:
Install the front airbag sensor with the arrow on the sensor fac-
ing toward the front of the vehicle.
(b) Connect the front airbag sensor connector.
2. INSTALL HEAD LIGHT
Install head lights with the 4 bolts and 2 screws (See page
BE-23).

RS014-32
H11896N´m (kgf´cm, ft´lbf) : Specified torqueInstrument Panel
No. 4 Heater To Resister Duct
Center BracketGlove Box Lamp
No. 5 Heater To Resister Duct
Front Passenger Airbag Assembly
No. 3 Resister
No. 1 Safety Pad
20 (205, 15)
20 (205, 15)
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS-27
1547 Author
: Date
:
2001 AVALON (RM808U)
FRONT PASSENGER AIRBAG ASSEMBLY
COMPONENTS

H11906
H12008
RS-40
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
1560 Author
: Date
:
2001 AVALON (RM808U)
3. INSTALL INSTRUMENT PANEL (See page BO-97)
(a) Install the bolt for connecting the front passenger airbag
assembly to the center bracket.
Torque: 20 N´m (205 kgf´cm, 15 ft´lbf)
(b) Install the 2 bolts for mounting the front passenger airbag
assembly to the instrument panel reinforcement.
Torque: 20 N´m (205 kgf´cm, 15 ft´lbf)
4. CONNECT AIRBAG CONNECTOR
(a) Connect the airbag connector.
(b) Set the connector on the glove compartment door finish
plate.
(c) Install the glove compartment door finish plate to the low-
er panel.

RS0LF-01
H11926
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
Seatback Frame Headrest
Headrest Support
Seatback Cover (w/ Pad)
Hog Ring

37 (375, 27)
43 (440, 32)
Front Seat Cushion Shield

Non-reusable partInner Front Seat Cushion Shield
Reclining adjuster
Release Handle
37 (375, 27)
Side Airbag
Assembly
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-55
1575 Author
: Date
:
2001 AVALON (RM808U)
SIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
COMPONENTS

RS0LK-01
H11929
H11928
H11930
RS-60
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1580 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
NOTICE:
Never use airbag parts from another vehicle. When replac-
ing parts, replace them with new parts.
1. INSTALL SEATBACK ASSEMBLY
(a) Install the 4 bolts.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
NOTICE:

Make sure that the seatback assembly is installed
with the specified torque.

If the seatback assembly has been dropped, or there
are cracks, dents or other defects in the case or con-
nector, replace the seatback assembly with a new
one.

When installing the seatback assembly, take care it is
not pinched between other parts.
(b) Install 3 new hog rings as shown in the illustration.
HINT:
When installing the hog rings, take care to prevent wrinkles as
little as possible.
(c) Install the wire harness of the side airbag assembly to the
seat cushion assembly.
2. INSTALL INNER FRONT SEAT CUSHION SHIELD
Install the inner front seat cushion shield with the 2 screws.
3. INSTALL FRONT SEAT CUSHION SHIELD
Install the front seat cushion shield with the 2 screws.
4. INSTALL RECLINING ADJUSTER KNOBS
5. INSTALL HEADREST

- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-61
1581 Author
: Date
:
2001 AVALON (RM808U)
6. INSTALL FRONT SEAT
NOTICE:
When mounting the seat to the vehicle, take care not to
damage the airbag wire harness.
(a) Connect the side airbag connector.
(b) Slide the front seat to the most front position.
NOTICE:
Make sure that seat adjuster locks.
(c) Without holding the seat track handle, mount the seat to
the vehicle.
HINT:
If holding the seat track handle, the adjusted rearmost position
slip off.
(d) Tighten the bolts on the front side temporarily, from the
bolt on the inner side tighten them completely.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
(e) Slide the seat to the most front position to install the bolts
on the rear side.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
