2001 TOYOTA AVALON torque

SF105-02
B09136
Passenger's Seat
Heated Oxygen Sensor
Connector
(Bank 1 Sensor 2) Connector
for Seat
37 (375, 27)
Heated Oxygen Sensor
(Bank 1 Sensor 2)
Grommet
44 (450, 32)
: Specified torqueN´m (kgf´cm, ft´lbf)
Bench Seat TypeExcept Bench Seat Type
37 (375, 27)
SF-80
- SFIHEATED OXYGEN SENSOR
1189 Author
: Date
:
2001 AVALON (RM808U)
HEATED OXYGEN SENSOR
COMPONENTS

B09137
Ohmmeter
+BHT
SF106-02
- SFIHEATED OXYGEN SENSOR
SF-81
1190 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
INSPECT HEATER RESISTANCE OF HEATED OXYGEN
SENSOR (Bank 1 Sensor 2)
(a) Remove the passenger's seat.
(b) Disconnect the oxygen sensor connector.
(c) Using an ohmmeter, measure the resistance between the
terminals +B and HT.
Resistance:
At 20°C (68°F)11 - 16 W
At 800°C (1,472°F)23 - 32 W
If the resistance is not as specified, replace the sensor.
Torque: 44 N´m (450 kgf´cm, 32 ft´lbf)
(d) Reconnect the oxygen sensor connector.
(e) Reinstall the passenger's seat.

SF067-05
B09118

Gasket
Throttle Body
Water Bypass
HoseAir Assist
Hose
N´m (kgf´cm, ft´lbf)

Non-reusable part: Specified torque
29 (300, 22)
Air Cleaner Hose
w/ Resonator Vacuum Hose
Accelerator Cable
IAC Valve
GasketThrottle BodyThrottle Body
Bracket
Throttle
Position
Sensor
Connector
IAC Valve
Connector V-Bank Cover
Vacuum Hose
19.5 (200, 14)
Brake Booster
Vacuum Hose
Fuel Vapor
Feed Hose
Throttle Cable
SF-44
- SFIIDLE AIR CONTROL (IAC) VALVE
1153 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

B01020
B06618
Align
B09079
B09076
Fuel Hose
Clamp
B06613
SF-26
- SFIINJECTOR
1135 Author
: Date
:
2001 AVALON (RM808U)
(m) Tighten the 4 bolts holding the delivery pipes to the intake
manifold.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
(n) Tighten the bolt holding the No.1 fuel pipe to the intake
manifold.
Torque: 19.5 N´m (200 kgf´cm, 14 ft´lbf)
2. CONNECT NO.1 FUEL PIPE
(a) Align the alignment marks (white paint) on the No.1 fuel
pipe.
(b) Connect the No.1 fuel pipe (fuel tube connector) to the
fuel filter.
CAUTION:
Perform connecting operations of the fuel tube connector
(quick type) after observing the precautions.
(c) Surely install the fuel hose clamp to the fuel filter with
ºclickº sound.
(d) After installing the clamp, check that the clamp is fixed by
pulling up the clamp.
3. INSTALL AIR ASSIST HOSES AND PIPE
4. CONNECT INJECTOR CONNECTORS
5. INSTALL AIR INTAKE CHAMBER ASSEMBLY
(See page EM-59)
6. INSTALL AIR CLEANER HOSE WITH RESONATOR
7. INSTALL V-BANK COVER
(a) Using 5 mm hexagon wrench, install the V-bank cover
with the 3 cap nuts.
(b) Press down the V-bank cover fastener.
8. CHECK FOR FUEL LEAKS

SF06S-03
B09135
Ground Cable
PCV Hose
Air Intake Chamber
Assembly
ECT Sensor
Connector ECT Sender
Gauge Connector
IAC Valve
Connector
VSV Connector for No.2 ACIS
Engine Coolant
Reservoir HoseThrottle Position
Sensor Connector Brake Booster
Vacuum Hose Throttle Body Bracket
Water Outlet PS Pressure Tube
19.5 (200, 14)
39 (400, 19)
15 (150, 11)
43 (440, 32)
Ground Strap
DLC1
Gasket
15 (150, 11)
Grand Strap
Connector

Gasket
39 (400, 29)
V-Bank Cover
Accelerator CableAir Cleaner Hose
w/ Resonator
Purge Hose
Vacuum Hose
Fuel Hose
Clamp
Heater Hose
Intake Manifold Assembly
Injector Connector x 9
Knock Sensor
Connector
Upper Radiator
Hose

Gasket
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)

Retainer
Knock Sensor
Water Bypass
Hose
VSV Connector for
EVAP
No.1 Engine
Hanger
VSV Connector
for No.1 ACIS
Throttle Cable
Ground Cable
SF-76
- SFIKNOCK SENSOR
1185 Author
: Date
:
2001 AVALON (RM808U)
KNOCK SENSOR
COMPONENTS

SF102-02
A10518
5 mm
Hexagon
Wrench
P20115
SSTKnock Sensor 1
Knock Sensor 2
P01630
Ohmmeter
- SFIKNOCK SENSOR
SF-77
1186 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. REMOVE V-BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 3 cap nuts.
(b) Loosen the V-bank cover fastener counterclockwise.
(c) Remove the V-bank cover.
2. REMOVE AIR CLEANER HOSE WITH RESONATOR
3. REMOVE INTAKE MANIFOLD ASSEMBLY AND WA-
TER OUTLET (See page EM-31)
4. REMOVE KNOCK SENSORS
(a) Disconnect the knock sensor connector.
(b) Using SST, remove the knock sensor.
SST 09817-1601 1
5. INSPECT KNOCK SENSORS
Using an ohmmeter, check that there is no continuity between
the terminal and body.
If there is continuity, replace the sensor.
6. REINSTALL KNOCK SENSORS
(a) Using SST, install the knock sensor.
SST 09817-1601 1
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
(b) Connect the knock sensor connector.
7. REINSTALL WATER OUTLET AND INTAKE MAN-
IFOLD ASSEMBLY (See page EM-59)
8. REINSTALL AIR CLEANER HOSE WITH RESONATOR
9. REINSTALL V-BANK COVER
(a) Using 5 mm hexagon wrench, install the V-bank cover
with the 3 cap nuts.
(b) Press down the V-bank cover fastener.

S05054
New Gasket
FI1654
Fulcrum Length
30 cm
SST
FI6372
CORRECT New O-Ring
Delivery Pipe
Injector Grommet
WRONG
B05295
O-Ring
Grommet
Spacer InsulatorDelivery Pipe
O-Ring
- SFISFI SYSTEM
SF-3
111 2 Author
: Date
:
2001 AVALON (RM808U)
(b) When connecting the union bolt on the high pressure pipe
union, observe the following procedures:
(1) Always use 2 new gaskets.
(2) Tighten the union bolt by hand.
(3) Tighten the union bolt to the specified torque.
Torque: 29 N´m (300 kgf´cm, 21 ft´lbf)
(c) When connecting the flare nut on the high pressure pipe
union, observe the following procedures:
(1) Apply a light coat of engine oil to the flare nut, and
tighten the flare nut by hand.
(2) Using SST, tighten the flare nut to specified torque.
SST 09023-12700
NOTICE:
Do not rotate the fuel pipe, when tightening the flare nut.
Torque: 28 N´m (285 kgf´cm, 21 ft´lbf)
HINT:
Use a torque wrench with a fulcrum length of 30 cm (11.81 in.).
(d) Observe the following precautions when removing and
installing the injectors.
(1) Never reuse the O-ring.
(2) When placing a new O-ring on the injector, take
care not to damage it in any way.
(3) Coat a new O-ring with spindle oil or gasoline be-
fore installing-never use engine, gear or brake oil.
(e) Install the injector to the delivery pipe and intake manifold
as shown in the illustration.
(f) Observe these precautions when disconnecting the fuel
tube connector (quick type).
(1) Check if there is any dirt like mud on the pipe and
around the connector before disconnecting them
and clean the dirt away.
(2) Be sure to disconnect with hands.

SF0ZS-03
B09088

Gasket
Throttle Body
Water Bypass
HoseAir Assist
Hose
29 (300, 22)
19.5 (200, 14)
Air Cleaner Hose
w/ Resonator Vacuum Hose
Accelerator CableThrottle Body
Bracket
V-Bank Cover
IAC Valve
ConnectorThrottle
Position
Sensor
Connector
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)
Vacuum Hose
Brake Booster
Vacuum Hose
Fuel Vapor
Feed Hose
Throttle Cable
SF-34
- SFITHROTTLE BODY
1143 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS
