2001 TOYOTA AVALON torque

SS0ES-01
- SERVICE SPECIFICATIONSSTARTING
SS-21
137 Author
: Date
:
2001 AVALON (RM808U)
TORQUE SPECIFICATION
Part tightenedN´mkgf´cmft´lbf
End cover x Field frame1.51513 in.´lbf
Starter housing x Magnetic switch5.96052 in.´lbf
Field frame x Armature assembly5.96052 in.´lbf
Lead wire x Terminal C of starter5.96052 in.´lbf
Starter mounting bolt3940029
Terminal nut x Terminal C of starter1717312
Terminal nut x Terminal 30 of starter1717312
Magnetic switch end cover x Magnetic switch housing2.52522 in.´lbf

SS0ZT-01
SS-2
- SERVICE SPECIFICATIONSSTANDARD BOLT
11 8 Author
: Date
:
2001 AVALON (RM808U)
SPECIFIED TORQUE FOR STANDARD BOLTS
Specified torque
ClassDiameter
mm
Pitch
mmHexagon head boltHexagon flange boltClassmmmmN´mkgf´cmft´lbfN´mkgf´cmft´lbf
4T
6
8
10
12
14
161
1.25
1.25
1.25
1.5
1.55
12.5
26
47
74
11 555
130
260
480
760
1,15048 in.´lbf
9
19
35
55
836
14
29
53
84
-60
145
290
540
850
-52 in.´lbf
10
21
39
61
-
5T
6
8
10
12
14
161
1.25
1.25
1.25
1.5
1.56.5
15.5
32
59
91
14065
160
330
600
930
1,40056 in.´lbf
12
24
43
67
1017.5
17.5
36
65
100
-75
175
360
670
1,050
-65 in.´lbf
13
26
48
76
-
6T
6
8
10
12
14
161
1.25
1.25
1.25
1.5
1.58
19
39
71
11 0
17080
195
400
730
1,100
1,75069 in.´lbf
14
29
53
80
1279
21
44
80
125
-90
210
440
810
1,250
-78 in.´lbf
15
32
59
90
-
7T
6
8
10
12
14
161
1.25
1.25
1.25
1.5
1.510.5
25
52
95
145
23011 0
260
530
970
1,500
2,3008
19
38
70
108
16612
28
58
105
165
-120
290
590
1,050
1,700
-9
21
43
76
123
-
8T
8
10
121.25
1.25
1.2529
61
11 0300
620
1,10022
45
8033
68
120330
690
1,25024
50
90
9T
8
10
121.25
1.25
1.2534
70
125340
710
1,30025
51
9437
78
140380
790
1,45027
57
105
10T
8
10
121.25
1.25
1.2538
78
140390
800
1,45028
58
10542
88
155430
890
1,60031
64
11 6
11 T
8
10
121.25
1.25
1.2542
87
155430
890
1,60031
64
11 647
97
175480
990
1,80035
72
130

SF0ZZ-02
B09088

Gasket
Throttle Body
Water Bypass
HoseAir Assist
Hose
19.5 (200, 14)
19.5 (200, 14)
Air Cleaner Hose
w/ Resonator Vacuum Hose
Accelerator CableAir Intake
Chamber Stay
V-Bank Cover
IAC Valve
ConnectorThrottle
Position
Sensor
Connector
: Specified torque

Non-reusable part
N´m (kgf´cm, ft´lbf)
Vacuum Hose
Brake Booster
Vacuum Hose No.1
Fuel Vapor
Feed Hose
Throttle Cable
SF-54
- SFIACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
1163 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

B09124
Protector

O-Ring

Gasket

O-RingNo.1 Throttle
Body
6.9 (70, 61 in.´lbf)
N´m (kgf´cm, ft´lbf)

Non-reusable part: Specified torque No.1 Intake Air Control Valve

Gasket
6.9 (70, 61 in.´lbf)
No.1
No.2 Throttle Body
- SFIACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
SF-55
1164 Author
: Date
:
2001 AVALON (RM808U)

B06500
No.2 Intake Air Control Valve
Gasket
Actuator Vacuum Hose
Ground Strap
Ground Cable
: Specified torque

Non-reusable part
14.5 (145, 10)
N´m (kgf´cm, ft´lbf)
DLC1 Bracket
DLC1
No.2
SF-56
- SFIACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
1165 Author
: Date
:
2001 AVALON (RM808U)

SF06F-03
B04803
New Gasket
S05052
Seal
Packing
Rubber Seal
Packing
- SFIACOUSTIC CONTROL INDUCTION SYSTEM (ACIS)
SF-59
1168 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
1. INSTALL NO.1 INTAKE AIR CONTROL VALVE
(See pages SF-40 and SF-42)
2. INSTALL NO.2 INTAKE AIR CONTROL VALVE
(a) Install the No.2 intake air control valve.
(1) Install a new gasket to the air intake chamber.
(2) Apply a light coat of engine oil to the rubber por-
tions.
(3) Apply seal packing to the positions of the intake air
control valve shown in the illustration.
Seal packing: Part No. 08826-00080 or equivalent
(4) Install the intake air control valve, DLC1 bracket,
ground strap and cable with the 4 nuts.
Torque: 14.5 N´m (145 kgf´cm, 10 ft´lbf)
(b) Connect the DLC1.
(c) Connect the actuator vacuum hose.

SF103-01
B06683
A/F Sensor Connector A/F Sensor
N´m (kgf´cm, ft´lbf) : Specified torque Bank 1 Sensor 1
44 (450, 32)
B06681
A/F Sensor Connector
A/F Sensor
N´m (kgf´cm, ft´lbf) : Specified torque Bank 2 Sensor 1
44 (450, 32)
LH Exhaust Manifold
Heat Insulator
SF-78
- SFIAIR-FUEL RATIO (A/F) SENSOR
1187 Author
: Date
:
2001 AVALON (RM808U)
AIR-FUEL RATIO (A/F) SENSOR
COMPONENTS

B06682
Bank 1 Sensor 1
Bank 2 Sensor 1
Ohmmeter +B
HT
+BHT Ohmmeter
SF104-01
- SFIAIR-FUEL RATIO (A/F) SENSOR
SF-79
1188 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
INSPECT HEATER RESISTANCE OF A/F SENSORS
(Bank 1 sensor 1, Bank 2 Sensor 1)
(a) Disconnect the A/F sensor connector.
(b) Using an ohmmeter measure the resistance between ter-
minals +B and HT.
Resistance:
At 20°C (68°F)0.8 - 1.4 W
At 800°C (1,472°F)1.8 - 3.2 W
If the resistance is not as specified, replace the sensor.
Torque: 44 N´m (450 kgf´cm, 32 ft´lbf)
(c) Reconnect the A/F sensor connector.
