2001 TOYOTA AVALON torque

F09723
BR-36
- BRAKEREAR BRAKE PAD
1435 Author
: Date
:
2001 AVALON (RM808U)
(c) Install the caliper.
(d) Install the installation bolt.
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
10. INSTALL REAR WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
11. DEPRESS BRAKE PEDAL SEVERAL TIMES
12. CHECK THAT FLUID LEVEL IS AT MAX LINE

BR0LX-03
F09740
Rear Speed Sensor
N´m (kgf´cm, ft´lbf) : Specified torque
5.4 (55 48 in.´lbf)
8.0 (82, 71 in.´lbf)
BR-62
- BRAKEREAR SPEED SENSOR
1461 Author
: Date
:
2001 AVALON (RM808U)
REAR SPEED SENSOR
COMPONENTS

BR0LY-03
R00330
R00331
- BRAKEREAR SPEED SENSOR
BR-63
1462 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. DISCONNECT SPEED SENSOR CONNECTOR
(a) Remove the seat cushion and seatback.
(b) Disconnect the speed sensor connector, and pull out the
sensor wire harness with the grommet.
2. REMOVE SPEED SENSOR
(a) Remove the bolt and speed sensor from the axle carrier.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
(b) Remove the 2 clamp bolts holding the sensor wire har-
ness to the body and shock absorber.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)

CH03X-01
P20102
P14233
Plate Terminal
P14234
P20103
P10835
SST (B)Turn
SST (A)
- CHARGINGGENERATOR
CH-7
1280 Author
: Date
:
2001 AVALON (RM808U)
DISASSEMBLY
1. REMOVE REAR END COVER
(a) Remove the nut and terminal insulator.
(b) Remove the screw, 3 nuts, plate terminal and end cover.
2. REMOVE BRUSH HOLDER AND VOLTAGE REGULA-
TOR
(a) Remove the brush holder cover from the brush holder.
(b) Remove the 5 screws, brush holder and voltage regulator.
3. REMOVE RECTIFIER HOLDER
(a) Remove the 4 screws and rectifier holder.
(b) Remove the 4 rubber insulators.
(c) Remove the seal plate.
4. REMOVE PULLEY
(a) Hold SST (A) with a torque wrench, and tighten SST (B)
clockwise to the specified torque.
SST 09820-63010
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
(b) Check that SST (A) is secured to the rotor shaft.

P01364
Pulley
CH040-02
P00427
P01763
29 mm
Socket
Wrench
P19942
A
AB
A
P10835
SST (B)Turn
SST (A)
- CHARGINGGENERATOR
CH-13
1286 Author
: Date
:
2001 AVALON (RM808U)
REASSEMBLY
1. INSTALL ROTOR TO DRIVE END FRAME
(a) Place the rectifier end frame on the pulley.
(b) Install the rotor to the rectifier end frame.
2. INSTALL RECTIFIER END FRAME
(a) Place the thrust washer on the rotor.
(b) Using a 29 mm socket wrench and press, slowly press in
the rectifier end frame.
(c) NUT A:
Install the cord clip and 4 nuts.
Torque: 4.5 N´m (46 kgf´cm, 40 in.´lbf)
(d) NUT B:
Install the cord clip and 4 nuts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(e) Install the wire clamp.
3. INSTALL PULLEY
(a) Install the pulley to the rotor shaft by tightening the pulley
nut by hand.
(b) Hold SST (A) with a torque wrench, and tighten SST (B)
clockwise to the specified torque.
SST 09820-63010
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
(c) Check that SST (A) is secured to the pulley shaft.

P10834
SST (A)
SST (C)Insert
P10829
SST (C)
SST (A)
Turn
P10836
SST (A) Turn
SST (B)
P00428
P00645
CH-14
- CHARGINGGENERATOR
1287 Author
: Date
:
2001 AVALON (RM808U)
(d) Mount SST (C) in a vise.
(e) Insert SST (B) into SST (C), and attach the pulley nut to
SST (C).
(f) To torque the pulley nut, turn SST (A) in the direction
shown in the illustration.
Torque: 110.5 N´m (1,125 kgf´cm, 81 ft´lbf)
(g) Remove the generator from SST (C).
(h) Turn SST (B), and remove SST (A and B).
4. INSTALL RECTIFIER HOLDER
(a) Place the seal plate on the rectifier end frame.
(b) Install the 4 rubber insulators on the lead wires.

P20103
S05460
Upward
P14235
P14233
Plate Terminal
P20102
- CHARGINGGENERATOR
CH-15
1288 Author
: Date
:
2001 AVALON (RM808U)
(c) Install the rectifier holder with the 4 screws.
Torque: 2.9 N´m (30 kgf´cm, 26 in.´lbf)
5. INSTALL VOLTAGE REGULATOR AND BRUSH
HOLDER
(a) Place the voltage regulator and brush holder on the recti-
fier end frame.
NOTICE:
Be careful of the holder installation direction.
(b) Install the 5 screws.
Torque: 2.0 N´m (20 kgf´cm, 18 in.´lbf)
(c) Place the brush holder cover on the brush holder.
6. INSTALL REAR END COVER
(a) Install the end cover and plate terminal with the 3 nuts and
screw.
Torque:
Screw: 3.9 N´m (39 kgf´cm, 35 in.´lbf)
Nut: 4.4 N´m (45 kgf´cm, 39 in.´lbf)
(b) Install the terminal insulator with the nut.
Torque: 4.1 N´m (41.5 kgf´cm, 36 in.´lbf)
7. CHECK THAT ROTOR ROTATES SMOOTHLY

CH03W-02
P19938
P19978
CH-6
- CHARGINGGENERATOR
1279 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE DRIVE BELT
Loosen the pivot bolt, adjusting lock bolt and adjusting bolt, and
remove the drive belt.
Torque:
Lock bolt: 18 N´m (180 kgf´cm, 13 ft´lbf)
Pivot bolt: 56 N´m (570 kgf´cm, 41 ft´lbf)
2. REMOVE GENERATOR
(a) Disconnect the generator connector.
(b) Remove the nut, and disconnect the generator wire.
Torque: 9.8 N´m (100 kgf´cm, 86 in.´lbf)
(c) Disconnect the wire harness from the clip.
(d) Remove the pivot bolt, plate washer, adjusting lock bolt
and generator.
