2001 TOYOTA AVALON torque

BO2QI-01
H12221
Lower Center Pillar Garnish
Front Seat
Inner Belt
Front Seat Center Belt Front Seat
Front Seat Adjustable Anchor
Center Pillar Garnish
Front Door Scuff
Inside Plate
Manual seat:
Front Seat
Inner Belt
Front Seat Outer Belt
Lap Belt Outer
Anchor Cover
Bench type:
Front Seat Inner Belt
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
Front Seat Inner Belt
7.5 (76, 66 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf) BO-124
- BODYSEAT BELT
1909 Author
: Date
:
2001 AVALON (RM808U)
SEAT BELT
COMPONENTS

H12222
Rear Seatback Assembly LH Rear Inner with
Center Belt Roof Side Inner Garnishw/o Speaker:
High-mounted Stop Light
RH Rear Seat
Inner with Center Beltw/ Speaker:
High-mounted Stop Light
Package Tray TrimRear Seat
Outer Belt
Rear Seat Outer Belt
Seat Belt
Retractor Cover
Rear Seat Cushion AssemblyRoof Side Inner Garnish
N´m (kgf´cm, ft´lbf): Specified torque
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
18 (185, 13)
18 (185, 13)
41 (420, 30)
- BODYSEAT BELT
BO-125
1910 Author
: Date
:
2001 AVALON (RM808U)

BO2PO-01
H12167
Sliding Roof Glass
Drive Cable
Side Garnish
Rear Roof Drip Channel
Guide Block Guide CashingWindow Deflector Panel
Drive Gear
Map Light Bracket
Sliding Roof Panel StopperSliding Roof Housing
Sunshade Trim
Rear Frame
Sliding Roof Bracket
Sliding Roof Bracket
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
4.0 (41, 35 in.´lbf)
N´m (kgf´cm, ft´lbf)
: Specified torque Drain Hose
BO-78
- BODYSLIDING ROOF
1863 Author
: Date
:
2001 AVALON (RM808U)
COMPONENTS

BO2PP-01
H12168
- BODYSLIDING ROOF
BO-79
1864 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE ROOF HEADLINING (See page BO-99)
2. REMOVE SIDE GARNISH
(a) Using a screwdriver, remove the garnish.
HINT:
Tape the screwdriver tip before use.
(b) Employ the same manner described above to the other
side.
3. REMOVE SLIDING ROOF GLASS ASSEMBLY
(a) Using a torx wrench, remove the 4 nuts.
Torque: 4.0 N´m (41 kgf´cm, 35 in.´lbf)
(b) Pull the glass upward to remove it.
4. REMOVE DRIVE GEAR
NOTICE:
Remove the drive gear with the sliding roof fully closed.
(a) Disconnect the connector.
(b) Remove the 2 bolts an drive gear.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(c) Remove the 2 screws and map light bracket from the drive
gear.

H12169
BO-80
- BODYSLIDING ROOF
1865 Author
: Date
:
2001 AVALON (RM808U)
5. REMOVE SLIDING ROOF HOUSING
(a) Disconnect the 4 drain hoses from the housing.
(b) Remove the 8 bolts and 4 brackets.
Torque: 5.4 (55 kgf´cm, 48 in.´lbf)
(c) Remove the 6 nuts, then remove the sliding roof housing.
Torque: 5.4 (55 kgf´cm, 48 in.´lbf)

BO2PE-01
H12155
: Specified torqueN´m (kgf´cm, ft´lbf)

Non-reusable partHood To Cowl Top Seal Cowl Top Ventilator LouverWiper Arm Windshield Upper Moulding
Windshield GlassFront Door
Opening Trim Front Pillar Garnish
24 (248, 18)
Roof Headlining
Assist Grip
DamInner Rear View Mirror
Sun Visor
Holder Sun Visor
Inner Rear View
Mirror Cover
Holder
Roof Console Box Front Pillar Garnish
Front Door
Opening Trim
Retainer
24 (248, 18)

No. 1 Stopper

No. 2 Stopper

No. 2
Stopper
w/ Sliding roof:
Sliding Roof
Opening Trim




Dam

Lens

No. 1 Stopper
- BODYWINDSHIELD
BO-55
1840 Author
: Date
:
2001 AVALON (RM808U)
WINDSHIELD
COMPONENTS

H12134
A
BC
B
- BODYWINDSHIELD
BO-63
1848 Author
: Date
:
2001 AVALON (RM808U)
(c) Adjust the installation position of the wiper arms to the
position as shown in the illustration.
A: 52 mm (2.05 in.)
B: 30 ± 10 mm (1.18 ± 0.39 in.)
C: 21.3 mm (0.839 in.)
(d) Torque the 2 nuts.
Torque: 24 N´m (248 kgf´cm, 18 ft´lbf)
(e) Install the 2 wiper arm head caps.
19. INSTALL FRONT PILLAR GARNISH
20. INSTALL FRONT DOOR OPENING TRIMS
21. INSTALL ROOF CONSOLE BOX
22. INSTALL SUN VISORS AND HOLDERS
23. INSTALL INNER REAR VIEW MIRROR

BR0LL-05
F09731
ABS Actuator
Actuator Bracket
N´m (kgf´cm, ft´lbf) : Specified torqueCushion
CushionHolder
15 (155, 11)
15 (155, 11)
13 (130, 9)
Holder
19 (195, 14)
19 (195, 14)
Air Cleaner Assembly
W03328
ECU
Spring Plate
Actuator

N´m (kgf´cm, ft´lbf)
: Specified torque

Non-reusable part
3.0 (31, 27 in.´lbf)
- BRAKEABS ACTUATOR
BR-47
1446 Author
: Date
:
2001 AVALON (RM808U)
ABS ACTUATOR
COMPONENTS
