2001 TOYOTA AVALON fog light bulb

I12825
34 4017 18
BE0IG-03
I12826
34
17 18
40
ON
ON
W/ Mirror Heater:
W/O Mirror Heater:
I057411
2 34
4 321
I13308
3
6
I13307
5
10
- BODY ELECTRICALDEFOGGER SYSTEM
BE-67
1671 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. A/C control panel assembly:
INSPECT DEFOGGER SWITCH OPERATION
(a) Connect the positive (+) lead from the battery to terminal
17, 18 and negative (-) lead to terminal 40.
(b) Connect the positive (+) lead from the battery to terminal
24 through a 1.4 W test bulb.
(c) Turn the defogger switch ON and check that the test bulb
and indicator light turn ON, then turn OFF after about 15
minutes.
If operation is not as specified, proceed to the next inspection.
2. INSPECT DEFOGGER RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant3 - 4Continuity
Apply B+ between
terminals 3 and 4.1 - 2Continuity
If continuity is not as specified, replace the relay.
3. W/ Mirror defogger:
INSPECT MIRROR DEFOGGER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 6.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If the mirror does not become warm, replace the mirror assem-
bly.
4. W/ Mirror defogger and driving position memory:
INSPECT MIRROR DEFOGGER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (-) lead to terminal 10.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If the mirror does not become warm, replace the mirror assem-
bly.

BE04Q-06
BE-2
- BODY ELECTRICALTROUBLESHOOTING
1606 Author
: Date
:
2001 AVALON (RM808U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
POWER OUTLET
SymptomSuspect AreaSee page
Electric power source cannot be taken out of the power outlet11. PWR OUTLET No. 1, 2 Fuse
12.Wire Harness-
-
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
HEADLIGHT AND TAILLIGHT SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
FOG LIGHT SYSTEM:
SymptomSuspect AreaSee page
Fog light does not light with light control SW HEAD.
(Headlight is normal)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness-
BE-26
BE-26
-
Fog light does not light with light control SW HEAD.
(Headlight does not light)1. Other Parts*1
2. Wire Harness
-
-
Only one light does not light.1. Bulb
2. Wire Harness-
-
*1: Inspect Headlight System.
TURN SIGNAL AND HAZARD WARNING SYSTEM:
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE-29
BE-29
-
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Hazard warning light does not light up.
(Turn is normal.)1. HAZ Fuse
2. Wire Harness-
-
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE-29
-
*1Turn signal does not light up.
1. Ignition Switch
2. TURN Fuse
3. Turn Signal Switch
4. Wire HarnessBE-16
-
BE-29
-
*2Turn signal does not light up.
1. TURN Fuse
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE-29
-
Only one bulb does not light up.1. Bulb
2. Wire Harness-
-
*1: Combination Meter, Wiper and Washer do not operate.
*
2: Combination Meter, Wiper and Washer are normal.

BE-6
- BODY ELECTRICALTROUBLESHOOTING
1610 Author
: Date
:
2001 AVALON (RM808U) Shift indicator lights do not light up.
1. Bulb
2. Park/Neutral Position Switch
3. Meter Circuit Plate
4. Wire Harness-
DI-199
BE-43
-
Only one shift indicator does not light up.1. Bulb
2. Meter Circuit Plate-
BE-43
Malfunction indicator light does not light up.
1. Bulb
2. ECM
3. Meter Circuit Plate
4. Wire Harness-
DI-1
BE-43
-
SLIP indicator light does not light up.
1. Bulb
2. ABS & TRAC ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-250
BE-43
-
TRAC OFF indicator light does not light up.
1. Bulb
2. ABS & TRAC ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-250
BE-43
-
Security indicator light does not light up.
1. LED
2. Theft Deterrent ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-517
BE-43
-
Indicator lights do not light up. (Except Turn, Hi-beam and
security)1. GAUGE Fuse
2. Wire Harness-
-
DEFOGGER SYSTEM:
SymptomSuspect AreaSee page
All defogger systems do not operate.
1. SEAT HEATER Fuse
2. DEF Fuse
3. Defogger Relay
4. Defogger Switch
5. Wire Harness-
-
BE-67
DI-1
-
Rear window defogger does not operate.
1. Defogger Wire
2. Choke Coil
3. Wire HarnessBE-67
-
-
Mirror defogger does not operate.
1. MIR/HTR Fuse
2. Mirror Defogger
3. Wire Harness-
BE-67
-
POWER WINDOW CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
POWER DOOR LOCK CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.

PP0B4-01
- PREPARATIONBODY ELECTRICAL
PP-55
105 Author
: Date
:
2001 AVALON (RM808U)
EQUIPMENT
Voltmeter
Ammeter
Ohmmeter
Test lead
ThermometerEngine oil level warning switch, Seat heater
SyphonBrake fluid level warning switch
Oil bathEngine oil level warning switch
Bulb (3 W)Fuel sender gauge
Bulb (3.4 W)Seat belt warning relay
Bulb (21 W)Turn signal flasher relay
Dry cell batteryFuel sender gauge
Heat lightSeat heater
Torque wrench
Masking tapeRear window defogger wire
Tin foilRear window defogger wire
