1997 FORD MUSTANG Owners Manual

128
*
[SS25001( ALL)03/96]
If any of these things happen, even
intermittently, have the Air Bag Supplemental
Restraint System serviced at your Ford or
Lincoln-Mercury dealer immediately. Unless
serviced, the system may not function properly
in the event of a collision.
*
[SS25101( ALL)03/96]
Disposal of Air Bags and Air Bag
Equipped Vehicles
*
[SS25201( ALL)03/96]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bags MUST BE disposed of by
qualified personnel.
%
*
[SS26300( ALL)01/96]
Safety Restraints for Children
*
[SS26400( ALL)01/96]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SS26500( ALL)02/96]
WARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SS26600( ALL)01/96]
WARNING
Cargo should always be secured to
prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

129
*
[SS26700( ALL)01/96]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
*
[SS26800( ALL)03/96]
WARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SS26900( ALL)01/96]
WARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SS27000( ALL)03/96]
WARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
%*
[SS27100( ALL)03/96]
WARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. Never
secure rear-facing infant seats in the front
seat.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

130 %
*
[SS27200( ALL)01/96]
Safety Seats for Children
*
[SS27300( ALL)01/96]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SS27500( ALL)01/96]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle. For a shoulder/lap belt
combination with a sliding tongue, make sure
the retractor is in the automatic locking mode.
*
[SS27600( ALL)03/96]
Children weighing less than 40 lbs. (18 kg)
should use child or infant seats. Forward facing
child seats must have the passenger seat moved
as far back from the instrument panel as
possible.
*
[SS27700( ALL)03/96]
WARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
*
[SS27800( ALL)01/96]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
*
[SS27900( ALL)03/96]
WARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

131
*
[SS28000( ALL)03/96]
WARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SS28100(MBC )03/96]
WARNING
Always keep the buckle release button
pointing upward and away from the child
seat, with the tongue between the child
seat and the release button as shown in
the following illustration.
% [SS28200(M )12/95]
Installing Safety Seats in the Front Seat Ð
Convertible
[SS28300(M )12/95]
Your Mustang Convertible is equipped with a
dual locking mode retractor on the lap belt
portion of the lap/shoulder belt at the front
passenger seat.
[SS28400(M )04/96]
The automatic locking modemust be usedwhen
installing a child seat in the front passenger seat.
*
[SS28500(M )03/96]
WARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

132 [SS28600(M )12/95]If you choose to install a child safety seat in the
front seat:
[SS28700(M )12/95]
1. Position the child seat in the front passenger
seat of the vehicle.
[SS28800(M )12/95]
2. Pull up on the lap belt, Figure 1.
[SS28900(M )12/95]
half page art:0011246-AFile:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

133 [SS29000(M )12/95]
3. Following the child seat manufacturer's
instructions, route the lap/shoulder belt
through the child seat or infant carrier and
insert the belt tongue into the buckle until
you hear and feel the latch engage, Figure 2.
[SS29100(M )12/95]
half page art:0010626-D
Routing the lap/shoulder belt
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

134 [SS29200(M )12/95]4. Grasp the lap portion of the belt below the
child seat label. Pull upward until all of the
belt is extracted and a click is heard. At this
time, the lap belt retractor is in the
automatic locking mode (child seat restraint
mode), Figure 3.
[SS29300(M )12/95]
half page art:0010628-D
Pull the lap belt out completely to set the automatic
locking mode
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

135 [SS29400(M )12/95]
5. Allow the belt to retract. A clicking sound
will be heard as the belt retracts. This
indicates the retractor is in the automatic
locking mode, Figure 4.
[SS29500(M )12/95]
half page art:0011236-A
Allowing belt to retract
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997
