1997 FORD MUSTANG Owners Manual

144
*
[SS32200( ALL)01/96]
7. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place. See Figure 7.
*
[SS32300( ALL)04/96]
half page art:0011244-B
Checking that the seat is secure
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

145
*
[SS32400( ALL)01/96]
8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode. See
Figure 8.
*
[SS32500( ALL)04/96]
half page art:0011245-C
Checking the retractor
*
[SS32600( ALL)01/96]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SS32700(M )01/96]
To remove the retractor from automatic lock
mode, allow webbing to retract fully to its
stowed position and the retractor will
automatically switch back to the vehicle sensitive
locking mode for normal adult usage.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

146 [SS35320( ALL)04/96]Attaching Safety Seats with Tether Straps
*
[SS35340( ALL)04/96]
Some manufacturers make safety seats that
include a tether strap that goes over the back of
the vehicle seat and attaches to an anchoring
point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of
your child safety seat for information about
ordering a tether strap.
%*
[SS35360( ALL)04/96]
Tether anchorage hardware
[SS35380( ALL)04/96]
Attachment holes (at each rear seating position)
have been provided in your vehicle to attach
anchor hardware, if required. Tether anchor
hardware kits (Part Number 613D74), including
instructions, may be obtained at no charge from
any Ford or Lincoln-Mercury dealer. All vehicles
built for sale in Canada include a tether anchor
hardware kit.
%*
[SS35400( ALL)01/96]
Safety Belts for Children
*
[SS35500( ALL)01/96]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SS35600( ALL)01/96]
WARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SS35700( ALL)01/96]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

147
*
[SS36000( ALL)01/96]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
*
[SS36100( ALL)01/96]
WARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SS36200( ALL)01/96]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SS36300( ALL)02/96]
WARNING
Children should always ride with the
seatback in the fully upright position.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

149
Starting
%*
[TO00200( ALL)01/96]
Fuel-Injected Engines
*
[TO00300( ALL)01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[TO00400( ALL)01/96]
Starting Your Vehicle
%*
[TO00500( ALL)01/96]
Preparing to Start Your Vehicle
*
[TO00600( ALL)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO00700( ALL)01/96]
Before you start your vehicle, do the following:
*
[TO00800( ALL)01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO00900( ALL)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
File:08rctom.ex
Update:Thu Apr 3 07:46:27 1997

150 [TO01000(M )12/95]3.If you have an automatic transmission,
make sure that the gearshift is in P (Park)
and the parking brake is set before you turn
the key.
[TO01100(M )12/95]
If you have a manual transmission, make
sure that the parking brake is fully set, push
the clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.The starter will operate only if the
clutch pedal is pushed in all the way.
*
[TO01300( ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO01400( ALL)01/96]
Starting Your Engine
*
[TO01500( ALL)01/96]
To start your engine:
*
[TO01600( ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO01700( ALL)01/96]
2. Turn the ignition key to the ON position.
*
[TO01800( ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO01900( ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO02000( ALL)01/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
File:08rctom.ex
Update:Thu Apr 3 07:46:27 1997

151 %
*
[TO02100( ALL)01/96]
For a cold engine:
*
[TO02200( ALL)01/96]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[TO02300( ALL)01/96]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
%*
[TO02400( ALL)01/96]
For a warm engine:
*
[TO02500( ALL)01/96]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[TO02600( ALL)01/96]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[TO02700( ALL)01/96]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
*
[TO02800( ALL)12/95]
NOTE: Your vehicle has an interlock that
prevents you from shifting out of P
(Park) unless your foot is on the brake
pedal.
File:08rctom.ex
Update:Thu Apr 3 07:46:27 1997

152 %
*
[TO02900( ALL)01/96]
If the engine does not start after two attempts:
*
[TO03000( ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[TO03100( ALL)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO03200( ALL)01/96]
3. Turn the ignition key to the START position.
*
[TO03300( ALL)01/96]
4. Release the ignition key when the engine
starts.
*
[TO03400( ALL)03/96]
5. Release the accelerator gradually as the
engine speeds up.
[TO03500( ALL)03/96]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the Index.
*
[TO03600( ALL)01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs higher than when it's
warmed up. These faster engine speeds will
make your vehicle move slightly faster than its
normal idle speed. It should, however, slow
down after a short time. If it does not, have the
idle speed checked.
*
[TO03700( ALL)01/96]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[TO03800( ALL)01/96]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
File:08rctom.ex
Update:Thu Apr 3 07:46:27 1997
