1997 FORD MUSTANG Owners Manual

95
*
[CF56400(MBC )03/96]
Triggering the Alarm System
*
[CF56500(MBC )01/96]
The armed system will be triggered if:
[CF56600(MBC )12/95]
q
any door is opened without disarming the
system first (see previous paragraphs)
*
[CF56700(MBC )05/96]
q
the trunk lock cylinder is removed
*
[CF56800(MBC )05/96]
NOTE: You can open the trunk with your key
without setting off the alarm.
%*
[CF57200(MBC )03/96]
Disarming a Triggered System
*
[CF57300(MBC )01/96]
The alarm can be disarmed by:
*
[CF57400(MBC )12/95]
q
unlocking a front door with the key
*
[CF57500(MBC )04/96]
q
using the UNLOCK control on the remote
entry transmitter
*
[CF57600(MBC )01/96]
NOTE: The flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs. However, the
starter circuit remains disabled until
the system is disarmed.
*
[CF57700(M )05/96]
Coded Key Anti-Theft System
[CF57800(M )05/96]
Your vehicle is equipped with the coded key
anti-theft system, you can only use an
electronically coded key to start the vehicle.
During each vehicle start sequence, the coded
key is read by the anti-theft system. If the key's
ID code matches that in the anti-theft system,
the vehicle is enabled to start. If the key's ID
code does not match the anti-theft system, or if
no coded key is detected, then the vehicle is not
able to start. Your vehicle was equipped with
two electronically coded keys. The coded
ignition key is larger than normal due to the
electronics located in the head of the key.
Additional spare keys, maximum of 14, can be
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

96purchased either through your dealership or
selected retailers. Be sure to purchase only coded
keys with a Ford or Mercury logo on it to
ensure proper functionality. If both supplied
keys are lost or stolen, the vehicle must be
brought to the dealership for re-initialization.
[CF57900(M )05/96]
quarter page art:0011372-A*
[CF58000(M )05/96]
Theft Indicator
*
[CF58100(M )05/96]
The indicator provides system proveout and
operating status. The system activates the
indicator when the ignition switch is placed in
the ON or START position. This indicator helps
to determine possible fault conditions and/or
normal operating proveout. The system will
illuminate the indicator for two (2) seconds then
go out to acknowledge normal operating
conditions. If the indicator does not illuminate at
key ON or flashes, have the system serviced.
*
[CF58200(M )05/96]
Spare Key Programming Procedure
*
[CF58300(M )05/96]
Two electronically coded keys were supplied
with your vehicle, use one of these with the
procedure below:
*
[CF58400(M )05/96]
q
Using a coded key that you can start your
engine with, turn the ignition from the ON to
the OFF position.
*
[CF58500(M )05/96]
q
Within 15 seconds, insert a new key into the
ignition and turn it to ON or START. The
vehicle does not have to be started.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

97
*
[CF58600(M )05/96]
If the key has been coded, the theft indicator
will illuminate for two seconds. The key can
then be used to start the vehicle.
*
[CF58700(M )05/96]
Repeat until all chosen keys have been coded
(max=16).
*
[CF58800(M )05/96]
If the key coding failed, the theft indicator will
flash and the vehicle cannot be started. One of 3
causes are possible:
*
[CF58900(M )05/96]
q
The new key was not inserted within 15
seconds or
*
[CF59000(M )05/96]
q
All 16 key codes have been stored or
*
[CF59100(M GV)03/96]
q
The key does not have an electronic code
*
[CF65000( ALL)05/96]
Remote Entry System
(If equipped)
*
[CF65100( ALL)05/96]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The controls for
the system are located on the hand held
remote(s) that came with your vehicle.
*
[CF65200( ALL)05/96]
The system will work with up to four remotes.
Your vehicle came with two remotes. Additional
remotes can be ordered from your dealer.
*
[CF65300(MBC )01/96]
The remote entry features only operate with the
ignition in the OFF position.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

98 [CF65500(MBC )05/96]
one third page art:0001000-ARemote
%*
[CF65700( ALL)02/96]
Unlocking the doors and opening the
trunk
*
[CF65800( ALL)04/96]
To unlock the driver's door, press the UNLOCK
control.
*
[CF65900( ALL)04/96]
To unlock the other doors, press the UNLOCK
control a second time within five seconds of
unlocking the driver's door.
*
[CF66000( ALL)05/96]
To open the trunk, press the TRUNK control.
*
[CF66200( ALL)04/96]
Locking the doors
*
[CF66300( ALL)04/96]
To lock all the doors, press the LOCK control.
*
[CF66400(MBC )05/96]
If you would like a signal that the doors are
being locked, press the LOCK control again
within five seconds. The doors will lock again
and the horn will beep.
%*
[CF67200( ALL)03/96]
Activating the remote personal alarm
*
[CF67300( ALL)04/96]
If you wish to activate the remote personal
alarm, press the PANIC control. This will honk
the horn and flash the parking lamps and tail
lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC control again or by turning
the ignition key to the RUN position.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

99 [CF67400( ALL)05/96]
When you use the remote entry UNLOCK,
TRUNK or PANIC controls, the illuminated
entry system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK control or by turning the ignition to the
RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[CF67500(M )03/96]
Arming and Disarming the Alarm System
[CF67600(M )12/95]
If your vehicle is equipped with the optional
factory installed anti-theft system, the remote
entry system will automatically arm it when the
doors are locked with the remote entry LOCK
button. The remote entry UNLOCK button will
disarm or reset a triggered anti-theft alarm.
*
[CF67700(M )12/95]
The remote entry system is designed to work
with the factory installed anti-theft system. It
may not work with other anti-theft systems.
% [CF67800(M )03/96]
Using the Illuminated Entry System
[CF67900(M )05/96]
If your vehicle has this option, the interior lights
turn on when you press UNLOCK, TRUNK, or
PANIC on a programmed remote if your vehicle
is equipped with remote entry.
[CF68000(M )05/96]
These lights automatically turn off after 25
seconds or when you turn the ignition key to
ON or ACC. The inside lights will not turn off if
you have turned them on manually or if a door
is opened.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

100 % [CF68100(M )03/96]Battery Saver (With Remote Entry)
*
[CF68200(M )05/96]
When the ignition is turned off, the vehicle will
turn off battery voltage to the interior lights
after 45 minutes.
[CF68300(M )12/95]
This will prevent draining of the battery if those
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the outside
front door handles are lifted, the Remote Entry
transmitter is used to unlock the doors, activate
the personal alarm or open the trunk, or the
ignition key is turned on again.
%*
[CF68400( ALL)03/96]
Replacing the Batteries
*
[CF68500(MBC )05/96]
The remote is powered by two coin type
three-volt lithium 2016 batteries (included) that
should last for several years of normal use. If
you notice a significant decrease in operating
range, the batteries should be replaced.
Replacement batteries can be purchased at most
pharmacies, watch stores or at your Ford or
Lincoln-Mercury dealer.
*
[CF68700( ALL)01/96]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

101
*
[CF68800(MBC )01/96]
quarter page art:0020790-A
Replacing the batteries
*
[CF68900(MBC )05/96]
The remote can be snapped apart to replace the
batteries by twisting a thin coin between the two
halves of the remote. DO NOT TAKE THE
FRONT PART OF THE REMOTE APART. When
installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two
halves back together.
%*
[CF69000( ALL)05/96]
Replacement/additional remotes
*
[CF69100(MBC )05/96]
In the event a remote is lost, return the
remaining remotes to your dealer for
reprogramming of your remote entry system.
This is necessary to prevent further unauthorized
use of the lost remote.
*
[CF69600(MBC )05/96]
Additional remotes may be purchased from your
dealer (remote entry system will work with up
to four remotes). Return your existing remotes to
your dealer so the remote entry system can be
reprogrammed with your new and existing
remotes.
*
[CF70000( ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
File:05rccfm.ex
Update:Thu Apr 3 07:41:31 1997

103
Seating and Safety
Restraints
%*
[SS00200( ALL)01/96]
Seats
%*
[SS00300( ALL)02/96]
Head Restraints
*
[SS00400( ALL)01/96]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[SS00500( ALL)01/96]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[SS00600( ALL)12/95]
Standard head restraints
*
[SS00700( ALL)12/95]
You can adjust the head restraints for your
comfort and protection.
[SS00800( ALL)12/95]
one third page art:0010048-C
Adjusting the head restraint
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997
