1997 FORD MUSTANG Owners Manual

*
[PI00425( ALL)05/95]
Table of ContentsIntroduction ....................................................1
Instrumentation ..............................................7
Audio ..............................................................25
Controls and Features ................................55
Seating and Safety Restraints ................103
Starting .........................................................149
Driving .........................................................157
Roadside Emergencies ..............................181
Maintenance and Care .............................209
Capacities and Specifications .................265
Reporting Safety Defects
(U.S. Only) ..................................................273
Customer Assistance .................................275
Accessories ..................................................287
Quick Index ................................................297
Index .............................................................309
Service Station Information ....................332
File:01rcpim.ex
Update:Thu Apr 3 07:37:35 1997

7
Instrumentation
[IS00200(M )12/95]
full page art:0010099-L
Mustang instrument panel
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

8 %
*
[IS00600( ALL)01/96]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[IS00700(M )01/96]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

9 % [IS01200(M )04/96]
full page art:0010106-L
Mustang GT instrument cluster
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

10 % [IS01300(M )12/95]
full page art:0011226-DMustang instrument cluster
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

11
[IS03100(ALL)12/95] Thisligh tcome son whe ntheparkin gbrak eis
WARNING
Th eBRAK Eligh tindicate stha tth ebrakes

12 % [IS03300( ALL)04/96]Anti-Lock Brake System Light
(If equipped)
[IS03400( ALL)12/95]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
*
[IS03500( ALL)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS03600( ALL)04/96]
one inch art:0011194-B
The anti-lock brake system light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

13
WARNING
If th eanti-loc kbrak esyste mwarning
