Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[MC02000( ALL)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC02100( ALL)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC02200(MBC )01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
*
[MC02300( ALL)01/96]
Working with the engine off:
[MC02400(M )12/95]
1. Set the parking brake fully, block the wheels,
and make sure that the gearshift is securely
latched in P (Park) (automatic transmission)
or 1 (First) (manual transmission).
*
[MC02600( ALL)01/96]
2. Remove the key from the ignition after you
turn the engine off.
*
[MC02700( ALL)01/96]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02800( ALL)01/96]
Working with the engine on:
[MC02900(M )12/95]
1. Set the parking brake fully, and make sure
that the gearshift is securely latched in P
(Park) (automatic transmission) or Neutral
(manual transmission).
*
[MC03100( ALL)01/96]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC03200( ALL)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

212 %
*
[MC03300( ALL)02/96]
Opening the Hood
[MC03400( ALL)12/95]
1. Inside the vehicle, pull the hood release
located under the lower left corner of the
instrument panel.
[MC03600( ALL)12/95]
2. Go around to the front of the vehicle, and
release the auxiliary catch that is located
under the front edge of the hood at the
center of the vehicle.
[MC03900(M )12/95]
one third page art:0011350-A
The auxiliary catch under the front edge of the hood
[MC04000(M )12/95]
3. Lift the hood and secure it with the prop
rod using only the hole marked ªPROPº.
[MC04200(M )12/95]
Whenever you close the hood, make sure the
prop rod is secured in its retainer and that the
hood latches securely.
*
[MC04400( ALL)12/95]
NOTE: Apply lubricant to the hood latch at
six-month intervals to maintain smooth
and trouble-free operation.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

213
%*
[MC04500( ALL)03/96]
Engine Compartment
*
[MC04600(MBC )01/96]
Your vehicle has one of these types of engines:
[MC04800(MBC )02/96]
q
a 3.8 liter SFI engine
[MC04900(MBC )12/95]
q
a 4.6 liter SFI engine
*
[MC05000(MBC )03/96]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

214 [MC05100(M )04/96]
full page art:0010325-EA 3.8 Liter SFI engine
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

215 [MC05200(M )04/96]
full page art:0011343-B
A 4.6 Liter (2V) engine Ð GT models
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

216
%*
[MC05600( ALL)01/96]
Engine Oil Recommendations
*
[MC05700( ALL)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[MC05800( ALL)01/96]
one third page art:0060021-E
The API Certification Mark
*
[MC05900( ALL)01/96]
Neveruse:
*
[MC06000( ALL)01/96]
q
ªNon-Detergentº oils
*
[MC06100( ALL)02/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200( ALL)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[MC06300( ALL)01/96]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC06400( ALL)03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

217 %
*
[MC06500( ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600( ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700( ALL)01/96]
Checking the engine oil level:
*
[MC06800( ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC07000(M )01/96]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[MC07100( ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07200( ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07300( ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07450(M )03/96]
one inch art:0011386-B
Engine oil dipstick Ð 4.6 liter engine
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

218 [MC07600(MBC )12/95]
one inch art:0000970-BEngine oil dipstick Ð 3.8 liter engines
[MC07750(M )03/96]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line (3.8L)
or at the ªMINº mark (4.6L), add engine oil
as necessary. If the oil level is beyond the
letter ªFº in full (3.8L) or ªMAXº (4.6L)
mark, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[MC07800( ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
*
[MC07900( ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC08000( ALL)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:11rcmcm.ex
