1997 FORD MUSTANG Owners Manual

14 %
*
[IS06300( ALL)03/96]
Air Bag Readiness Light
*
[IS06400( ALL)04/96]
The air bag system uses a readiness light and a
tone to indicate the condition of the system. The
readiness light is in the instrument cluster. When
you turn the ignition key to the ON position,
this light will light up for six (6) seconds and
then turn off. This indicates that the system is
operating normally. NOTE: Regularly scheduled
maintenance of the air bag system is not
required.
*
[IS06500( ALL)04/96]
If the light fails to illuminate, continues to flash,
remains on, or you hear a beeping sound, have
the system serviced at your Ford or
Lincoln-Mercury dealer immediately.
[IS06600(M GV)04/96]
one inch art:0010514-A
The air bag readiness light
% [IS07100(M )04/96]
Low Coolant Warning Light (If equipped)
[IS07200(M )12/95]
This light tells you that the coolant is low inside
the coolant recovery bottle and that you should
add more coolant.
[IS07300(M )12/95]
This light comes on for a few seconds when
your ignition key is turned to start, but should
turn off when the engine starts. If this light stays
on, check the level of coolant inside the recovery
bottle. SeeEngine Coolantin the Index.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

15 [IS07400(M )04/96]
one inch art:0010579-B
The low coolant warning light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)01/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS07700( ALL)04/96]
one inch art:0010119-B
The charging system light
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
% [IS08500(M )01/96]
Overdrive Off Indicator (Automatic Only)
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

16
*
[IS08700( ALL)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the control will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
*
[IS08900( ALL)03/96]
NOTE: If the light does not come on when the
TCS is depressed or if the light flashes
when you are driving, have your
vehicle serviced at the first
opportunity. If this condition persists,
damage could occur to the
transmission.
%*
[IS09000( ALL)03/96]
High Beam Light
*
[IS09100( ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
[IS09200( ALL)04/96]
one inch art:0010125-B
The high beam light
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

17 %
*
[IS11000(M GV)03/96]
Check Engine Warning Light
%*
[IS11100(M BCGV)04/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11300(M GV)04/96]
one inch art:0010134-A
The check engine warning light
[IS12105(M )04/96]
Anti-Theft Alarm Light
[IS12150(MBC )04/96]
one inch art:0001389-A
Anti-theft alarm light
[IS12200(MBC )04/96]
This light is used when you set the anti-theft
alarm system. SeeAnti-Theft Systemin the
Controls and Featureschapter for more
information.
%*
[IS12300( ALL)03/96]
Turn Signal Indicator Lights
*
[IS12400( ALL)03/96]
The turn signal arrow will flash to indicate the
direction in which you are going to be turning.
[IS12500( ALL)04/96]
one inch art:0010525-A
The turn signal indicator light
File:03rcism.ex
Update:Thu May 30 15:36:44 1996

18 %
*
[IS14200( ALL)03/96]
Fuel Gauge
[IS14500(M )12/95]
one third page art:0011344-A
The fuel gauge
[IS14600( ALL)12/95]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON. For proper fuel gauge
indication after adding fuel, turn the ignition
switch OFF while refueling the vehicle.
[IS14700( ALL)12/95]
The fuel gauge indicator may vary slightly when
the vehicle is in motion. The most accurate
reading is obtained with the vehicle on level
ground.
*
[IS14800( ALL)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[IS15700( ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS15800( ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS15900(M )04/96]
The pointer moves from the C (cold) mark into
the NORMAL band as your engine coolant
warms up. Under normal driving conditions, the
pointer should stay in the NORMAL band. It is
acceptable for the pointer to fluctuate within the
NORMAL band under normal driving
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

19
conditions, and under certain driving conditions
such as, heavy stop and go traffic, or driving up
hills in hot weather, for the pointer to indicate at
the top of the NORMAL band.
*
[IS16000(M )04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
% [IS16100(M )12/95]
one third page art:0011143-B
The engine coolant temperature gauge
*
[IS16400( ALL)03/96]
If your engine overheats:
*
[IS16500( ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS16600( ALL)01/96]
2. Turn off the engine.
*
[IS16700( ALL)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS16800( ALL)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS16900( ALL)03/96]
If the coolant continues to overheat, have the
coolant system serviced.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

20 %
*
[IS18100( ALL)03/96]
Speedometer
[IS18300(M )04/96]
one third page art:0011345-A
The speedometer (GT similar)
*
[IS18350( ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS18900( ALL)03/96]
Odometer
*
[IS19000( ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS20400( ALL)01/96]
Trip Odometer
*
[IS20500( ALL)04/96]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset control firmly when beginning the distance
you wish to measure.
[IS20600( ALL)04/96]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

21 %
*
[IS20700(MBC )03/96]
Tachometer
[IS20900(M )04/96]
one third page art:0011346-A
The tachometer (GT similar)
*
[IS21000(MBC )01/96]
The tachometer displays the approximate engine
revolutions per minute (rpm), or how fast the
engine is running.
[IS21100(M )01/96]
The white zone shows the highest number of
engine revolutions per minute (rpm) at which
you should drive your car. Driving with the
pointer in the red zone may cause engine
damage.
% [IS21400(M GV)04/96]
Battery Voltage Gauge
*
[IS21500(M GV)04/96]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[IS21600(M )04/96]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[IS21700(M )04/96]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
