1997 FORD MUSTANG check oil

23
*
[IS22500(M GV)04/96]
If you lose engine oil pressure:
*
[IS22600(M GV)04/96]
1. Pull off the road as soon as safely possible.
*
[IS22700(M GV)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS22800(M GV)04/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, see theEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your car should be on level ground.
[IS22900(M )04/96]
4. If the level is low, add oil as necessary
before you start the engine again. Do not
overfill. Do not operate the engine if the
pointer in the oil pressure gauge is below
the NORMAL band, regardless of the oil
level. Contact your nearest dealer for further
service actions.
[IS23000(M GV)04/96]
For more information about adding oil, see
Engine Oil Recommendationsin the Index.
File:03rcism.ex
Update:Thu Apr 3 07:38:50 1997

217 %
*
[MC06500( ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600( ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700( ALL)01/96]
Checking the engine oil level:
*
[MC06800( ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC07000(M )01/96]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[MC07100( ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07200( ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07300( ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07450(M )03/96]
one inch art:0011386-B
Engine oil dipstick Ð 4.6 liter engine
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

218 [MC07600(MBC )12/95]
one inch art:0000970-BEngine oil dipstick Ð 3.8 liter engines
[MC07750(M )03/96]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line (3.8L)
or at the ªMINº mark (4.6L), add engine oil
as necessary. If the oil level is beyond the
letter ªFº in full (3.8L) or ªMAXº (4.6L)
mark, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[MC07800( ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
*
[MC07900( ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC08000( ALL)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

220
*
[MC08600( ALL)01/96]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[MC08700( ALL)01/96]
Protect your skin by washing with soap and
water.
%
*
[MC08800( ALL)05/96]
Brake Fluid
*
[MC08900( ALL)01/96]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[MC09100(M )04/96]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MAX fill mark and
3/8" below the MAX fill line.
*
[MC09200( ALL)01/96]
RWARNING
Brake fluid is toxic.
*
[MC09300( ALL)01/96]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
%*
[MC09400( ALL)03/96]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AB
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

252
*
[MC35700( ALL)12/95]
Self-Service Pointers
*
[MC35800( ALL)12/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[MC35900( ALL)12/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[MC36000( ALL)12/95]
q
Check the engine oil at every refueling stop
*
[MC36100( ALL)12/95]
q
Clean the windshield, outside mirrors and
headlights
*
[MC36200( ALL)12/95]
q
Check windshield washer fluid
*
[MC36300( ALL)12/95]
q
Check tires for excessive wear or worn edges
*
[MC36400( ALL)12/95]
q
Check the tire pressure at least monthly
%
*
[MC36500( ALL)01/96]
Emission Control System
*
[MC36600( ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC36700( ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

254
*
[MC37600( ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC37700( ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC37800( ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
*
[MC37900( ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC38000( ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC38100( ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997

314 Index
Cold engine starting........... 151
Combination lap and shoulder belts . . 111, 114
Compact disc player (see Electronic sound
system)................. 34
Console, description............ 83
Controls, mirrors............. 77
Convenience kit in cargo area...... 193
Convertible
cleaning................ 91
installation of the boot.......... 87
lowering the convertible top....... 85
raising the convertible top........ 90
Coolant (see Engine coolant)....... 224
checking and adding......... 224
drain and flush............ 228
preparing for storage......... 270
refill capacities............ 266
specifications............. 267
temperature gauge........... 18
warnings............... 224
Cooling fan............... 210
Crankcase emission filter......... 265
Customer Assistance Center, Ford (U.S.) . . 277
Customer Assistance Centre,
Ford of Canada..........277, 283
D
Daytime running light system....... 59
Defrost
rear window.............. 58
windshield............... 57
Dipstick................ 217
automatic transmission fluid....234, 236
engine oil.............. 217
power steering fluid.......... 231
Disabled vehicle (see Towing)...... 207
Dispute Settlement Board........ 278
File:rcixm.ex
Update:Thu Apr 3 07:52:02 1997

316 Index
Engine
check engine warning light....... 17
does not start...........152, 190
fuel injected engine, starting....149±150
fuel pump shut-off switch....... 190
preparing to start........... 149
refill capacities............ 266
service points............. 213
starting................ 150
starting after a collision........ 190
storing your vehicle........268±269
Engine block heater........... 153
Engine coolant............. 224
checking and adding......... 224
checking hoses............ 226
disposal...........210, 219, 236
drain and flush............ 228
low coolant warning light........ 14
preparing for storage......... 270
proper solution........210, 219, 236
recovery reservoir.........213, 224
refill capacities............ 266
specifications............. 267
temperature gauge........... 18
Engine coolant temperature gauge..... 18
description............... 18
mechanical.............18±19
Engine coolant temperature
guage:electronic............. 18
Engine fan............... 210
Engine oil............... 216
changing oil and oil filter.....217, 219
checking and adding......... 217
dipstick............... 217
disposal...........210, 219, 236
engine oil pressure gauge........ 22
filter, specifications.......... 265
refill capacities............ 266
specifications...........216, 267
synthetic oil............. 216
File:rcixm.ex
Update:Thu Apr 3 07:52:02 1997
