258vibration, or other indication that your vehicle
may need service. If you do notice something
unusual, see that your vehicle is serviced
promptly.
%
*
[MC01200(FM)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01300(FM)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[MC01400(FM)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[MC01500(FM)01/96]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[MC01600(FM)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC01700(FM)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC01800(FM)01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

259
*
[MC01900(FM)01/96]
Working with the engine off:
[MC02100(F )01/96]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
[MC02200(F )04/96]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
[MC02300(F )01/96]
3. Remove the key from the ignition after you
turn the engine off.
[MC02400(F )01/96]
4. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02500(FM)01/96]
Working with the engine on:
[MC02600(F )01/96]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
[MC02900(F )04/96]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[MC03000(FM)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

260 %
*
[MC03100(F )02/96]
Opening the Hood
*
[MC03200(F )01/96]
1. Pull the hood release handle, located next to
the parking brake pedal.
*
[MC03400(F )01/96]
2. While applying downward pressure on the
hood, push the hood latch handle located
behind the grille near the center front of the
vehicle to the left.
[MC03600(F )04/96]
3. As you open the hood to its fullest extent, a
clock spring will assist you and ªsnapº into
position. The clock spring lift secures the
hood at its fullest height.
[MC03700(F )04/96]
one third page art:0020333-A
Hood release handle
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

261 [MC03900(F )04/96]
half page art:0020337-E
Hood and support
[MC04000(F )04/96]
NOTE: Be sure to oil the hood latch every six
months to maintain smooth operation.
*
[MC04200(F )01/96]
Always attempt to lift the hood after closing to
be sure it is securely latched.
%
*
[MC04300(F )03/96]
Engine Compartment
*
[MC04400(F )03/96]
Your vehicle has one of the following types of
engines:
[MC04800(F )04/96]
q
A 5.8 Liter EFI, V-8 engine, or
[MC04900(F )04/96]
q
A 7.5 Liter EFI, V-8 engine.
[MC05000(F )04/96]
NOTE: Read the7.3L Diesel Engine Owner
Guide Supplementfor information
regarding correct service points for
your diesel-powered vehicle.
*
[MC05100(F )03/96]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

262 [MC05600(F )05/96]
full page art:0020345-I5.8L engine compartment service points
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

263 [MC05700(F )04/96]
full page art:0020526-H
7.5 EFI engine compartment service points
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

264
%*
[MC05750(FM)01/96]
Engine Oil Recommendations
*
[MC05775(FM)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
[MC05800(FM)04/96]
one third page art:0060020-D
The API Certification Mark
*
[MC05900(FM)01/96]
Neveruse:
*
[MC06000(FM)01/96]
q
ªNon-Detergentº oils
*
[MC06100(FM)02/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200(FM)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
[MC06300(F )05/96]
For vehicles with 5.8L engines
%*
[MC06400(F )03/96]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC06500(F )03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

265 [MC06600(F )04/96]
For vehicles with 7.5L engine
[MC06800(FM)01/96]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
S5ÊF (S20ÊC). SAE5W-30 engine oils may also
be used down toS15ÊF (S25ÊC).
%*
[MC06900(FM)03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
%*
[MC07000(FM)01/96]
Checking and Adding Engine Oil
*
[MC07100(FM)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC07200(FM)01/96]
Checking the engine oil level:
*
[MC07300(FM)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC07400(F )01/96]
2. Set the parking brake, making sure that the
gearshift is securely latched in P (Park)
(automatic transmission) or 1 (First) (manual
transmission).
*
[MC07600(FM)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07700(FM)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07800(FM)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
