1997 FORD F250 Owners Manual

242 [ER11400(F )04/96]
half page art:0020286-EJack and assembly location
*
[ER11700(F )01/96]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
*
[ER11800(F )01/96]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

243 %
*
[ER11900(F )01/96]
Removing and Replacing the Tire
[ER12100(F )01/96]
1. Insert the jack handle into the jack and use
the handle to slide the jack under the
vehicle.
*
[ER12200(F )05/96]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[ER12300(F )01/96]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[ER12400(F )01/96]
2. Positioning the jack
[ER13200(F )04/96]
a. To raise a front or rear wheel, place the
jack as shown in the illustration that
applies to your vehicle.
[ER13700(F )04/96]
one third page art:0020300-A
F-Series jacking points
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

244 [ER13800(F )04/96]
one third page art:0020301-AF-Series jacking points
[ER13900(F )05/96]
one third page art:0020302-B
Positioning the jack
[ER14000(F )04/96]
one third page art:0020303-A
Positioning the jack
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

245 [ER14100(F )04/96]
one third page art:0020306-A
Positioning the jack
[ER14200(F )04/96]
one third page art:0020307-A
Positioning the jack
[ER14300(F )04/96]
one third page art:0020308-B
Positioning the jack
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

246
*
[ER14500(F )01/96]
one third page art:0020939-B
[ER14600(F )04/96]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
[ER15300(F )01/96]
3. Remove the lug nuts with the lug nut
wrench.
[ER15400(F )01/96]
4. Replace the flat tire with the spare tire.
[ER15500(F )04/96]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[ER15700(F )01/96]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
[ER15800(F )04/96]
If your vehicle has dual rear wheels, thread the
two-element swiveling lug nut on the wheel
studs with the flange face toward the wheel. Use
the lug nut wrench to screw the lug nut snugly
against the wheel but do not tighten.
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

247
*
[ER15900(F )01/96]
quarter page art:0020310-A
Single rear wheel nut
[ER16100(FM)04/96]
quarter page art:0020311-A
Dual rear wheel nut
*
[ER16200(F )03/96]
5. Lower the vehicle by turning the jack handle
counterclockwise.
*
[ER16300(F )01/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
% [ER16500(F )04/96]
quarter page art:0020317-A
Lug nut tightening sequence
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

248 % [ER16600(FM)04/96]
quarter page art:0020319-CLug nut tightening sequence
*
[ER16700(F )01/96]
RWARNING
Never use wheels or lug nuts different
than the original equipment as this could
damage the wheel or mounting system.
This damage could allow the wheels to
come off while the vehicle is being
driven.
*
[ER16900(F )01/96]
7. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Make sure that
they are screwed or snapped into place.
[ER17100(F )01/96]
8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
*
[ER17400(F )03/96]
9. Unblock the wheels.
[ER17700(F )04/96]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

249
*
[ER17900(FM)01/96]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[ER18000(FM)01/96]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
% [ER18300(F )04/96]
twelve pica chart:0020320-B%*
[ER19300(FM)02/96]
Jump-Starting Your Vehicle
[ER19350(F )04/96]
NOTE: Read the7.3L Diesel Engine Owner's
Guide Supplementfor information on
jump-starting your diesel-powered light
truck.
*
[ER19400(FM)02/96]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start your vehicle with a
booster battery.
