1997 FORD F250 Owners Manual

23 %
*
[IS11100(FM)03/96]
Speedometer
*
[IS11200(FM)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[IS11300(F )03/96]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy.
*
[IS11500(F )03/96]
Some vehicles are equipped with a vehicle speed
(mph/km/h) limiting device that is contained
within the Powertrain Control Module (PCM).
The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle
speed limits may vary based on engine
displacement.)
*
[IS11600(F )03/96]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

24
*
[IS11700(F )03/96]
one third page art:0020871-C
Speedometer
%*
[IS11900(FM)01/96]
Odometer/Trip Odometer
*
[IS12000(FM)05/96]
The Liquid Crystal Display (LCD) odometer is a
combination trip odometer and total odometer.
The total odometer is normally displayed. To see
the trip odometer, press and release the SELECT
control on the upper right side of the
speedometer. To zero out the trip odometer,
press and release the RESET control on the
upper left side of the speedometer while the trip
odometer is displayed. If the trip odometer is
displayed, press and release the SELECT control
to return the display to the total odometer value.
% [IS12100(F )04/96]
Tachometer (If equipped)
*
[IS12200(F )03/96]
The tachometer will show you the engine's
speed measured in revolutions per minute
(RPM).
*
[IS12300(F )03/96]
The tachometer may move slightly when the key
is placed in the ACC or ON position, with the
engine off. This is normal and does not affect
the performance of the tachometer when the
engine is running.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

25
*
[IS12400(F )03/96]
Some vehicles are equipped with an engine
speed (RPM) limiting device contained within
the powertrain control module (PCM). The
purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. This
feature is only evident on automatic transmission
vehicles when shifting manually (1, 2, D) and on
all manual transmission units. (Engine speed
limits may vary based on engine displacement.)
*
[IS12500(F )03/96]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
[IS12600(F )04/96]
one third page art:0020869-C
Tachometer
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

27
Electronic Sound Systems
*
[AS01100(F )08/95]
full page art:0060648-B
Compact Disc Radio
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

28
%*
[AS01200(F )10/95]
Compact Disc Radio
*
[AS01250(F )10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(F )08/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(F )10/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01500(F )03/96]
How to turn the radio on and off
*
[AS01600(F )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(F )03/96]
How to adjust the volume
*
[AS01650(F )03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(F )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS01700(F )03/96]
Selecting the AM or FM frequency band
*
[AS01800(F )10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

29 %
*
[AS01900(F )03/96]
How to tune radio stations
*
[AS02000(F )10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02100(F )10/95]
q
Using the ªSCAN/TUNEº button to manually
tune
*
[AS02200(F )04/96]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top
aor bottom
bhalf of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªMº.
*
[AS02300(F )03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

30
*
[AS02400(F )04/96]
q
Using the ªSEEKº function
*
[AS02500(F )04/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the top
a
half of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the bottom
bhalf of the button to
select the next listenable station down the
frequency band. By pressing and holding the
button, listenable stations can be passed over
to reach the desired station.
*
[AS02600(F )02/96]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS02700(F )04/96]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top
ahalf of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom
bhalf of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS02800(F )03/96]
To stop the scan mode on the presently
sampled station, press the ªSCAN/TUNEº
button again.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

31
*
[AS03000(F )02/96]
q
Setting the Station Memory Preset buttons
%*
[AS03100(F )08/95]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
FM stations (5 in FM1 and 5 in FM2). Follow
the easy steps below to set these buttons to
the desired frequencies.
*
[AS03200(F )03/96]
1. Select a band, then select a frequency.
*
[AS03400(F )10/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS03500(F )10/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS03510(F )08/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS03520(F )10/95]
q
Using the Automatic Memory Load feature
*
[AS03530(F )08/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
